Byte. Designation (PRM group)
Bit
8.7 Voltage measuring module
(UM)
9.0 Reserved
10.0 Control function (CF)
11.0 Reserved
12.0 Bit parameters (16)
12.0 No configuration fault due to OP Bit
12.1 Startup parameter block active
12.2 Test/Reset keys disabled
12.3 Bus and PLC/PCS - Reset
12.4 Reserved
12.5 Reserved
12.6 Reserved
12.7 Reserved
13.0 Diagnostics for process events
13.1 Diagnostics for process
warnings
13.2 Diagnostics for process faults
13.3 Diagnostics for device faults
13.4 Reserved
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Type Range Unit
Bit 0, 1
Byte 0x00
0x10
0x11
0x12
0x20
0x21
0x30
0x31
0x40
0x41
0x50
0x60
0x61
0x62
0x63
0x64
0x70
0x71
Bit[8]
0, 1
Bit 0, 1
Bit 0, 1
Bit 0, 1
Bit
Bit
Bit
Bit
Bit 0, 1
Bit 0, 1
Bit 0, 1
Bit 0, 1
Bit
3.4 Tables, PROFINET data records
Default Note
0x00 = Overload
0x10 = Direct starter
0x11 = Reversing starter
0x12 = 3VL molded case
circuit breaker (MCCB)
0x20 = Star-delta starter
0x21 = Star-delta reversing
starter
0x30 = Dahlander starter
0x31 = Dahlander reversing
starter
0x40 = Pole-changing starter
0x41 = Pole-changing
reversing starter
0x50 = Solenoid valve
0x60 = Positioner 1
0x61 = Positioner 2
0x62 = Positioner 3
0x63 = Positioner 4
0x64 = Positioner 5
0x70 = Soft starter
0x71 = Soft starter with
reversing contactor
0
1
0
0 0 = Manual
1 = Auto
0
0
0
0
0
1
1
1
0
Tables, data records
