Siemens SIMOCODE pro Function Manual page 334

Tables, data records
3.6 EtherNet/IP data tables
Attribute ID Access
22 Get/ Set
23 Get/ Set
24 Get/ Set
25 Get/ Set
26 Get/ Set
27 Get/ Set
28 Get/ Set
29 Get/ Set
30 Get/ Set
31 Get/ Set
32 Get/ Set
33 Get/ Set
34 Get/ Set
35 Get/ Set
36 Get/ Set
37 Get/ Set
38 Get/ Set
1) Value range dependent on current range of the IM / UM and the conversion factor
334
Designation
TM1 - warning level T>
TM2 - trip level T>
TM2 - warning level T>
Trip level 0/4-20 mA> 1
Warning level 0/4-20 mA> 1
Trip level 0/4-20 mA< 1
Warning level 0/4-20 mA< 1
Trip level 0/4-20 mA> 2
Warning level 0/4-20 mA> 2
Trip level 0/4-20 mA< 2
Warning level 0/4-20 mA< 2
Limit level 1
Limit level 2
Limit level 3
Limit level 4
Limit level 5
Limit level 6
Data Range of values
type
DINT 0 .. 65535
DINT 0 .. 65535
DINT 0 .. 65535
INT 0 .. 255
INT 0 .. 255
INT 0 .. 255
INT 0 .. 255
INT 0 .. 255
INT 0 .. 255
INT 0 .. 255
INT 0 .. 255
DINT 0 .. 65535
DINT 0 .. 65535
DINT 0 .. 65535
DINT 0 .. 65535
DINT 0 .. 65535
DINT 0 .. 65535
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Unit
1 K
1 K
1 K
*128
*128
*128
*128
*128
*128
*128
*128
