Tables, data records
3.4 Tables, PROFINET data records
Byte.Bit Designation
29.5
30.0 Faults -
Miscellaneous
30.1
30.2
30.3
30.4
30.5
30.6
30.7
31.0
31.1
31.2
31.3
31.4
31.5
32.0 Faults -
Protection
extended
32.1
32.2
32.3
33.0 Faults - Level
monitoring
extended
33.1
33.2
34.0 Faults -
Miscellaneous
extended
34.1
35.0
36.0 Warnings -
Protection
extended
36.1
36.2
36.3
36.4
236
Reserved bit[3]
Fault - External fault 1
Fault - External fault 2
Fault - External fault 3
Fault - External fault 4
Fault - External fault 5
Fault - External fault 6
Fault - Dry running pump
Fault - Underfill protection -
Fault
Fault - AM1 open circuit
Fault - Test trip
Fault - DM-F safety-related
tripping
Fault - DM-F wiring
Fault - DM-FL cross circuit
Reserved bit[3]
Fault - TM2 trip T >
Fault - TM2 sensor fault
Fault - TM2 out of range
Reserved bit[5]
Fault - Trip 0/4-20mA >
Fault - Trip 0/4-20mA <
Reserved bit[6]
Fault - AM2 open circuit
Reserved bit[7]
Reserved bit[8]
Warning - TM2 warning T >
Reserved
Warning - TM2 sensor fault
Warning - TM2 out of range
Reserved bit[4]
Information PNIO
diagnostic
status **)
3
3
3
3
3
3
3
3
AM1 3
3
DM-F 3
DM-FL 3
DM-FL 3
TM2 3
TM2 3
TM2 3
AM2 3
AM2 3
AM2 3
TM2 2
TM2 2
TM2 2
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
PNIO error Error no.
number (channel
error type)
0x1070 56
0x1071 57
0x1072 58
0x1073 59
0x1074 60
0x1075 61
0x104D 62
0x104E 63
0x105B 64
0x1055 65
0x0019 66
0x1061 67
0x1062 68
0x102E
0x102F
0x1030
0x104A
0x104B
0x105C
0x102E
0x102F
0x1030
