Command and Response Table for SIS Commands

Symbol definitions
]
= CR/LF (carriage return with line feed) (hex 0D 0A)
}
= Carriage return (no line feed, hex 0D)
• = Space character
E
= Escape key (hex 1B)
X!
= Input number (for tie)
X@
= Output number
X#
= Mute
X$
= SFP number or reclockable output number
X%
= Output reclocking rate
X^
= Laser control
X& = Global preset number
X*
= Room number (for room presets)
NOTE: A room is a subset of operator selected outputs that relate to each other. The FOX matrix switcher supports up to 10 rooms, each of
which can consist of from 1 to 16 outputs.
X(
= Name
NOTE: The following characters are invalid or not recommended in the name: <space> ~ , @ = ' [ ] { } < > ' " ; : | \ and ?.
X1)
= Room preset number
NOTE: A room preset is a stored configuration with all of the outputs assigned to a single room. When a room preset is retrieved from
memory, it becomes the current configuration.
X1! = Connection status
X1@
= Input number
X1#
= Number (quantity) of inputs
X1$
= Number (quantity) of outputs
X1%
= Board installed
X1^
= I/O board slot number
X1&
= Transceiver module installed
X1*
= Transceiver module number
X1(
= Reclocking status
X2)
= Vendor or manufacturer name
X2!
= Transmit output power in milliwatts
X2@
= Receive optical power in milliwatts
X2#
= SFP temperature
X2$
= Firmware version number to second decimal place (x.xx)
X2%
= Verbose firmware version-description-upload date and time (see the Query firmware version (verbose) command on
X2^
= Voltage
X2& = Switcher temperature
X2*
= Fan speed (in RPM)
X2(
= Power supply status
* 01 is default for HDSDI boards, 04 is default for laser boards.
Legacy board, no longer manufactured, identified for completeness only.
✝
(| [Pipe] can be used interchangeably with the
W
( can be used interchangeably with the
000 – (maximum number of inputs for your configuration) (000 = untied)
001 – (maximum number of outputs for your configuration)
0 = not muted
000 – 320 (FOX Matrix 320x) or 144 (FOX Matrix 14400) (000 = global [SFP only])
00 = Bypass mode
01* = Auto (HDSDI boards) or N/A (laser boards) 03 = 2.125 Gbps (laser boards only)
02 = 1.250 Gbps (laser boards only)
0 = disable
00 – 64 (00 = current configuration for view only)
10 max. (each can have up to 10 presets (
12 characters maximum for input names, output names, global preset names, and
room preset names
Upper- and lower-case alphanumeric characters and _ / and spaces are valid.
10 maximum
0 = no input connected
001 – 320 (FOX Matrix 320x) or 144 (FOX Matrix 14400)
In sets of 16 (016, 032, 048, 064, and so on)
In sets of 16 (016, 032, 048, 064, and so on)
0 = No board installed
1 = Non-reclocking multimode board
2 = Non-reclocking singlemode board
3 = 3G, SDI, HD-SDI board
01 – 09 or 20
0 = No module installed
1 = Non-pathological multimode module
2 = Non-pathological singlemode module
001 – 320 (or maximum number of transceiver modules for your configuration)
0 = Signal reclocked
Degrees Celsius
Positive or negative voltage and magnitude
Degrees Fahrenheit
0 = Out of tolerance or failed
FOX Matrix 320x and FOX Matrix 14400 • Programming Guide
}
character)
E
character)
1 = muted
04* = 4.250 Gbps (laser boards only)
1 = enable (default) 2 = automatic
X1)
) assigned)
1 = input connected
4 = Non-pathological multimode board
5 = Non-pathological singlemode board
✝
6 = Pathological singlemode board
✝
x = Unknown board or mix of transceivers
3 = 3G-SDI, HD-SDI, SD-SDI module
4 = Pathological singlemode module
1 = Signal not reclocked
page
1 = Ok
31).
