2.1.2. Setting for OHP sheet printing f
(1) Symptom
When printing OHP, off-centering by 5mm, J-3101 or fusing wrapping jam occurs.
(2) Cause
(a) Off-centering by 5mm
Since OHP is transparent, centering sensor mis-detects the sheet position. Consequently,
the registration roller moves the maximum distance (5mm).
(b) J-3101
While forming registration loop, the sheet gets loosened and the registration sensor mis-
detects.
(c) Fusing wrapping jam
When the plain paper is set for paper type, wrapping jam tends to occur due to the relation
with the fusing temperature setting.
(3) Solution
(a) Off-centering by 5mm
Disable centering sensor.
Change DipSW1-0 from 0 (Default) to 1, to display expert adjustment in paper setting.
[Machine]→[Paper Setting]→[Change Set]→[Expert Adj.]→[Mis-centering Detect
JAM]→[Not Detect]
(b) J-3101
Change registration loop amount to prevent the sheet gets too loosened.
Set the registration loop amount to [-5.0mm].
[Machine]→[Paper Setting]→[Change Set]→[Both Sides Adj.]→[Registration Loop],
If the [-5.0mm] setting does not improve enough, change the setting by every [-0.5mm] and
see the result.
(c) Fusing wrapping jam
Change Paper type to [Fine] or [Color Specific]
[Machine]→[Paper Setting]→[Change Set]→[Paper Type]
Note:
After finishing OHP printing, return the set to the original value.
