DD9500 /DD9800 with HA

For an HA DD9500 /DD9800 pair:
Table 23 Primary node cabling instructions
String I/O - Port
(Loop)
1 I/O 6 - Port 0 A controller port 0 of shelf V1.1
1 I/O 2 - Port 1 B controller port 0 of the highest number shelf in V1
2 I/O 3 - Port 0 A controller port 0 of shelf V2.1
2 I/O 2 - Port 0 B controller port 0 of the highest number shelf in V2
3 I/O 2 - Port 2 A controller port 0 of shelf V3.1
3 I/O 3 - Port 2 B controller port 0 of the highest number shelf in V3
4 I/O 2 - Port 3 A controller port 0 of shelf V4.1
4 I/O 6 - Port 1 B controller port 0 of the highest number shelf in V4
5 I/O 6 - Port 3 A controller HOST
5 I/O 3 - Port 3 B controller HOST
a.
Cable lengths shown are designed for Data Domain racks. Longer cables (up to 5M) can be
used.
Table 24 Standby node cabling instructions
String I/O - Port
(Loop)
1 I/O 6 - Port 0 B controller port 2 of shelf V1.1
1 I/O 2 - Port 1 A controller port 2 of the highest number shelf in V1
2 I/O 3 - Port 0 B controller port 2 of shelf V2.1
2 I/O 2 - Port 0 A controller port 2 of the highest number shelf in V2
3 I/O 2 - Port 2 B controller port 2 of shelf V3.1
3 I/O 3 - Port 2 A controller port 2 of the highest number shelf in V3
4 I/O 2 - Port 3 B controller port 2 of shelf V4.1
4 I/O 6 - Port 1 A controller port 2 of the highest number shelf in V4
5 I/O 6 - Port 3
5 I/O 3 - Port 3
a.
Cable lengths shown are designed for Data Domain racks. Longer cables (up to 5M) can be
used.
Shelf Port
port of the SSD shelf
port of the SSD shelf
Shelf Port
A controller EXPANSION
B controller EXPANSION
Connect Cables and Power on
port of the SSD shelf
port of the SSD shelf
DD9500 /DD9800 with HA
a
Length
2M
2M
2M
2M
5M
5M
5M
5M
2M
2M
a
Length
2M
2M
2M
2M
5M
5M
5M
5M
2M
2M
