FAR-3210(-BB)/3220(-BB)/3310/3320
Model
SAFETY INSTRUCTIONS ........................i
SYSTEM CONFIGURATION ..................iii
EQUIPMENT LISTS................................vi
1. INSTALLATION...............................1-1
1.1 Antenna Unit .......................................1-1
1.2 Monitor Unit.........................................1-7
Unit .....................................................1-7
1.4 Power Supply Unit ............................1-10
1.5 Processor Unit ..................................1-11
1.6 Sensor Adapters (option) ..................1-12
1.7 Intelligent Hub (option)......................1-13
1.8 Switching Hub (option)......................1-14
1.9 Junction Box (option) ........................1-15
2. WIRING............................................2-1
2.1 Overview .............................................2-1
2.2 Antenna Unit .......................................2-4
2.3 Processor Unit ..................................2-14
2.4 Power Supply Unit ............................2-24
2.5 Monitor Unit.......................................2-28
2.6 Sensor Adapters (option) ..................2-30
2.8 Junction Box (option) ........................2-54
2.9 Intelligent HUB (option).....................2-56
(option)..............................................2-57
Menu...................................................3-1
3.2 How to Align the Heading ...................3-1
3.5 Dual Radar Display .............................3-3
3.6 Other Settings .....................................3-6
ECDIS and Radar .............................3-14
All brand and product names are trademarks, registered trademarks or service marks of their respective holders.
Installation Manual
CHART RADAR
3.12 Web Setting Menu ............................3-17
4. INPUT/OUTPUT DATA ...................4-1
4.1 Processor Unit ....................................4-1
4.2 IEC 61162 Sentences .........................4-2
PACKING LISTS ................................. A-1
OURLINE DRAWINGS........................ D-1
www.furuno.com
(
Product Name: Marine Radar)

Advertisement

Table of Contents
loading

Related Manuals for Furuno FAR-3210

Summary of Contents for Furuno FAR-3210

  • Page 1: Table Of Contents

    Installation Manual CHART RADAR FAR-3210(-BB)/3220(-BB)/3310/3320 Model Product Name: Marine Radar) SAFETY INSTRUCTIONS ......i 3.10 How to Change the Display Color for Sensor Data Based on Integrity ..3-16 SYSTEM CONFIGURATION ....iii 3.11 How to display the [Echo] page ..3-16 EQUIPMENT LISTS........vi 3.12 Web Setting Menu ......3-17...
  • Page 2 7KH SDSHU XVHG LQ WKLV PDQXDO LV HOHPHQWDO FKORULQH IUHH )85812 $XWKRUL]HG 'LVWULEXWRU'HDOHU  $VKLKDUDFKR 1LVKLQRPL\D  -$3$1 $  $35  3ULQWHG LQ -DSDQ $OO ULJKWV UHVHUYHG *  129    3XE 1R ,0(* $.08 )$5           ...

  • Page 3: Safety Instructions

    Model Transceiver Antenna* 100 W/m 50 W/m 10 W/m XN12CF 0.6 m 1.4 m 4.4 m FAR-3210(-BB) RTR-105 XN20CF 0.4 m 0.9 m 3.0 m FAR-3310 (12 kW) XN24CF 0.3 m 0.6 m 2.5 m XN12CF 1.3 m...
  • Page 4 SAFETY INSTRUCTIONS CAUTION WARNING Do not open the equipment Observe the following compass safe unless totally familiar with distances to prevent deviation of a electrical circuits and magnetic compass: service manual. ELECTRICAL Standard Steering Only qualified personnel compass compass SHOCK are allowed to work inside the HAZARD Antenna Unit...

  • Page 5: System Configuration

    EPFS meeting the requirements of the IMO resolution MSC.112(73). Gyrocompass meeting the requirements of the IMO resolution A.424(XI). SDME meeting the requirements of IMO resolution MSC.96(72). The radar may be interconnected via HUB-3000 to other FURUNO processing units having approved LAN ports. Standard connection Basic configuration is shown with solid line.
  • Page 6 SYSTEM CONFIGURATION Category of units: Antenna unit: Exposed to weather Other units: Protected from the weather Notes 1) The gyrocompass must be type approved for compliance with IMO resolution A.424(XI) (and/ or resolution A.821(19) for installation on HSC). The gyrocompass must also have an update rate that is adequate for the ship’s rate of turn.

  • Page 7: Power Supply

    SYSTEM CONFIGURATION Interswitch connection When multiple radars are used, connect the units as shown in the figure below. This configuration lets each radar as a standalone radar in case of HUB malfunction. 100-115/220-230 VAC 100-115/220-230 VAC ANTENNA UNIT ANTENNA UNIT 1ø, 50-60 Hz (for de-icer) 1ø, 50-60 Hz (for de-icer) TRANSCEIVER UNIT...

  • Page 8: Equipment Lists

    EQUIPMENT LISTS Standard supply Name Type Code No. Remarks Antenna XN12CF-RSB-128-105 4 ft Unit XN12CF-RSB-128-106 XN20CF-RSB-128-105 6.5 ft Select XN20CF-RSB-128-106 XN24CF-RSB-128-105 8 ft XN24CF-RSB-128-106 Processor EC-3000 Unit Monitor Unit MU-190 For FAR-32x0 Select MU-231 For FAR-33x0 MU-270W Control Unit RCU-025 Standard type Select RCU-026...
  • Page 9 EQUIPMENT LISTS Console type Name Type Code No. Remarks RCN-303 FAR-3210/3220 Display Unit RCN-304 FAR-3310/3320 Optional supply Name Type Code No. Remarks Sensor MC-3000S Serial type Adapter MC-3010A Analog IN MC-3020D Digital IN MC-3030D Digital OUT LAN Signal Conv. OP03-223-3...
  • Page 10 EQUIPMENT LISTS Name Type Code No. Remarks AC/DC Power PR-240 000-013-632 Supply Unit Installation CP03-28900(10M) 000-082-658 LAN cable for sensor adapter Materials CP03-28910(20M) 000-082-659 CP03-28920(30M) 000-082-660 Installation CP24-02900(10M) 001-208-050 LAN cable for HUB-3000 Materials CP24-02910(20M) 001-208-060 LAN cable for HUB-3000 CP24-02920(30M) 001-208-040 LAN cable for HUB-3000...
  • Page 11 EQUIPMENT LISTS Name Type Code No. Remarks Antenna Rein- OP03-257 001-507-730 forcement Kit Operator’s Manual OME-36160-* English OMJ-36160-* Japanese Magnetron Re- E32-01306-* English placement Instruc- J32-01306-* Japanese tion Manual About the category sticker Comply with MSC.192(79) This radar meets the requirements in IEC62388 (Marine naviga- CAT 1HC CAT 1C tion and radiocommunication equipment and systems-Shipborne...
  • Page 12 EQUIPMENT LISTS This page is intentionally left blank.

  • Page 13: Installation

    INSTALLATION NOTICE Do not apply paint, anti-corrosive sealant or contact spray to coating or plastic parts of the equipment. Those items contain organic solvents that can damage coating and plastic parts, especially plastic connectors. Antenna Unit 1.1.1 Installation considerations • The antenna unit is generally installed either on top of the wheelhouse or on the ra- dar mast, on a suitable platform.
  • Page 14 1. INSTALLATION • Install the antenna unit away from interfer- ing high-power energy sources and TX ra- dio antennas. more than 20° • Keep the lower edge of the antenna unit above the safety rail by at least 500 mm. •...
  • Page 15 1. INSTALLATION 1.1.2 How to assemble the antenna unit The antenna unit consists of the antenna radiator and the antenna unit chassis, and they are packed separately. Fasten the antenna radiator to the antenna unit chassis as follows: 1. Coat the hatched area shown below with the supplied adhesive. Adhesive Radiator bracket...
  • Page 16 1. INSTALLATION 4. Fasten the antenna radiator to the radiator bracket with the six sets of hex bolts, flat washers (2 pcs.) and gaskets. Fasten the bolts in the order shown below. The torque must 15.0 N•m. Then, Coat the screws fixed at step 4 with the supplied adhesive as shown in the figure below.
  • Page 17 1. INSTALLATION 1. Construct a suitable mounting platform referring to the outline drawing at the end of this manual. Note: The mounting platform must be flat, level and firmly secured. • The diameter of the mast for fixing the antenna unit platform must be over 180 •...
  • Page 18 1. INSTALLATION Seal washer Antenna unit Antenna unit Insulation Sheet Platform Platform Flat washer Flat washer Two nuts M12×70 Adhesive (four places) How to fasten double nuts Seal washer Flat washer Nut1 Nut2 Nut1&2: Simultaneous work (Torque: 57 N•m) (Torque: 49 N•m) as below.

  • Page 19: Monitor Unit

    1. INSTALLATION Monitor Unit See the operator’s manual for MU-190 (OMC-44670), MU-231 (OMC-44690) or MU- 270W (OMC-44930) for the installation procedure. Keep in mind the following points when selecting a location. • Locate the monitor unit where no framing is installed immediately in front of the monitor.

  • Page 20: Desktop Installation

    1. INSTALLATION 1.3.1 Desktop installation How to mount the unit tilted Use the desk fixing plate to mount the unit tilted. 1. Fix the desk fixing plate to the bottom of the control unit. 2. Fix the control unit with self-tapping screws (local supply). Desk fixing plate RCU-026 RCU-025...
  • Page 21 1. INSTALLATION 1.3.2 Installation in a console Use the applicable optional flush mount kit to install the control unit in a console. Flush mount kit Control Unit Type Code RCU-025 OP24-24 001-171-790 RCU-026 OP24-27 001-171-820 1. Prepare a cutout in the location as shown in the figure as below. 170+2 170+2 110+2...

  • Page 22: Power Supply Unit

    1. INSTALLATION Power Supply Unit 1.4.1 Installation considerations The Power Supply Unit can be mounted on a bulkhead or deck. Keep in mind the fol- lowing points when selecting a location. • Locate the unit away from heat sources because of heat that can build up inside the cabinet.

  • Page 23: Processor Unit

    1. INSTALLATION Processor Unit 1.5.1 Installation considerations Keep in mind the following points when selecting a location. • Locate the processor unit away from heat sources because of heat that can build up inside the cabinet. • Select a location where the vibration is minimal. •...

  • Page 24: Sensor Adapters (Option)

    1. INSTALLATION 1.5.2 How to install the processor unit 1. Use 10 binding head screws (M4 8, supplied) to attach the chassis bases 1 and 2 to the processor unit. Note: For bulkhead mounting, attach the chassis base 2 so that the notches on it are facing the deck.

  • Page 25: Intelligent Hub (Option)

    1. INSTALLATION • Select the location considering the number of sensor adapters connected. A maximum of eight MC-3000S can be connected to a sensor network. A maximum of 10 sensor adapters (MC-3010A/3020D/3030D) can be connected to a MC-3000S. However, note that five MC-3010A can be connected. •...

  • Page 26: Switching Hub (Option)

    1. INSTALLATION • A magnetic compass will be affected if the hub is placed too close to the magnetic compass. Observe the compass safe distances in the SAFETY INSTRUCTIONS to prevent interference to a magnetic compass. How to install the Intelligent Hub 1.

  • Page 27: Junction Box (Option)

    1. INSTALLATION • Make sure that the ground wire is connected between the earth terminal on the hub and the ship’s earth. • Leave sufficient space at the sides and rear of the unit to facilitate maintenance. • A magnetic compass will be affected if the hub is placed too close to the compass. Observe the compass safe distances in the SAFETY INSTRUCTIONS to prevent compass malfunction.
  • Page 28 1. INSTALLATION This page is intentionally left blank. 1-16...

  • Page 29: Wiring

    WIRING Overview Cabling considerations To lessen the chance of picking up electrical interference, avoid where possible rout- ing the antenna cable (power and LAN lines) near other onboard electrical equipment (radars, TX radio antennas, etc.). Also avoid running the cable in parallel with power cables.

  • Page 30: Standard Wiring

    2. WIRING About wiring • Use the optional USB cable (type: OP24-32) to connect to the USB port on the control unit. • The length of the USB cable must be within 5 m to prevent equipment trouble. • The length of LAN cables must be within 50 m. •...
  • Page 31 Power Power Supply Unit DPYC-2.5 100-230 VAC PSU-014 LAN: DTI-C5E 350 VCV (10/20/30 m) MU-190 Serial: TTYCS-1Q Cat 5e LAN cable (for FAR-3210/3220) (local supply) MU-231/MU-270W (for FAR-3310/3320) DVI-D/D SINGLE LINK TTYCS-4 GYRO, AIS 5 m/10 m Monitor Unit DSUB9P-DSUB9P...

  • Page 32: Antenna Unit

    2. WIRING Antenna Unit Three cables are connected to the antenna unit: antenna cable, cable for the sub mon- itor (option) and power cable for the deicer (option). The procedure shows how to con- nect all cables. Disregard the descriptions for the optional equipment if not applicable. 2.2.1 How to fabricate the cables Antenna cable RW-00135...
  • Page 33 2. WIRING Cable DPYCY-1.5 (for the optional deicer) • Before beginning any work on the antenna unit, turn off the breaker for the de-icer at the mains switchboard. (Turning off the display unit has no effect.) • The neck of the antenna unit becomes VERY HOT when the de-icer is working. (The de-icer turns on when ambient temperature goes down to 5°C and heats to 55°C.) Sheath...
  • Page 34 2. WIRING Note 2: If the deicer is to be installed, spread open the right and left heater ele- ments on the cover, then remove the front cover, being careful not to hit the ele- ments on the radiator or chassis. Note 3: If this a retrofit or foremast installation, a LAN Signal Converter is re- quired, in both the antenna unit and the power supply unit.
  • Page 35 2. WIRING 5. Unfasten four screws to open the cable entrance cover. Note: The orientation of the cable entrance assy. can be changed, in one of the three orientations shown in the figure below. No other orientation is allowed, to maintain watertight integrity.
  • Page 36 2. WIRING 6. Unfasten the four screws fixing the cable clamp plates (2 pcs.). Cable entrance Cable clamp plate Cable clamp for cable for sub plate for monitor, deicer antenna cable Cable for sub monitor Cable for deicer Antenna cable 7.
  • Page 37 2. WIRING 9. Pass the LAN cable through the locking wire saddle at the bottom of the transceiv- er unit. Locking wire saddle for LAN cable 10. Connect the antenna cable and the cable for the sub monitor as shown below. See the illustration on the next page for parts location.
  • Page 38 2. WIRING Connect shield of Connect shield of Connect shield of power line to screw on power line to screw on power line to screw on plate. plate. plate. Connect shield of Connect shield of Connect shield of cable for sub monitor to cable for sub monitor to cable for sub monitor to Coaxial cable...
  • Page 39 2. WIRING Note 1: A terminal opener is provided on the RF-TB Board. Note 2: For the antenna cable RW-9600, connect the crimp-on lug (that binds un- used wires) together with the shield of the power line. See *1 on page 2-8 for the location.
  • Page 40 2. WIRING 5) Coat the gasket (all brims) of the intake with the supplied oil compound. Be sure to coat the gasket completely. Intake Intake Hatch: Oil compound Brim Brim 6) Set the front cover to the antenna unit. Take care not to hit the heater ele- ments on the chassis or radiator.
  • Page 41 2. WIRING 13. Close the cable entrance cover as shown in the figure below. Cable entrance cover Adhesive Coat the hinge inside the Close cover then coat screw gasket with adhesive, to heads with adhesive. prevent water from leaking into the cover. 14.

  • Page 42: Processor Unit

    2. WIRING Processor Unit Note: The interface ports approved for interconnecting navigation equipment are shown in the figure below. For details, see section 2.3.3 "How to select the serial input/ output format". J3, J4 For IEC 61162-2 or IEC 61162-1 J5, J6, J7, J8, J9, J10 For IEC 61162-1 Top view of EC-3000...
  • Page 43 2. WIRING DVI3 (DVI3: BNCX5-L2000) Cable clamp COM2 DVI2 MU-190/231/270W (COM2: DSUB9P- LAN1 X2-L cable DVI2: DVI-D/D HUB-3000 S-LINK cable) (DTI-C5E350 VCV cable) Power cable (IEC60320-C13- L5M cable) Ground wire LAN2 USB1 (IV-2sq., HUB-100/MC-3000S RCU-025/026 local supply) (FR-FTPC-CY cable, (TS-20-071-1 cable) LAN3 within 50m) COM1...
  • Page 44 2. WIRING How to fabricate the LAN cable Fabricate the LAN cable (FR-FTPC-CY, DTI-C5E350 VCV), as shown below. (Wrap both edges of the armor with vinyl tape.) Make sure the shield of the cable contacts the shell of the modular plug. Note: For a locally supplied LAN cable, expose the armor and clamp the armor with the cable clamp.
  • Page 45 2. WIRING 2.3.2 How to connect cables inside the processor unit How to fabricate the cables Fabricate the JIS cables (see the Appendix for equivalent cables if not available local- ly) as shown below. Connect the cables to the WAGO connectors on the I/O Board (24P0124) inside the processor unit.
  • Page 46 2. WIRING How to connect the cables 1. Unfasten four screws (M4 8) to remove the top cover from the processor unit. 2. Unfasten the three bolts circled below to remove the upper plate of the cable clamp. Clamp holes (upper) Unfasten this bolt to use Unfasten this bolt to use...
  • Page 47 2. WIRING 4. Connect the WAGO connectors to the I/O Board, referring to the interconnection diagram. J12 (main control unit) For J13 and J14 (sub control units), see the figure at step 2 in this procedure. 5. Bind the cables to the fixing metal in the processor unit with the cable ties (sup- plied).
  • Page 48 2. WIRING 2.3.3 How to select the serial input/output format How to set the termination resistors Use the jumper blocks JP1 and JP2 on the I/O Board (24P0124) to set the termination resistor J3 and J4 ON or OFF. The default setting is ON. •...
  • Page 49 2. WIRING How to select the serial input/output format Use the connectors J3 and J4 to set the input/output format for serial CH1/CH2, from IEC-61162-1 or IEC-61162-2. For connectors J5 to J10, use the TTYCS-1Q or TTYCSLA-1Q cable. Connector J3 Pin# Signal In/Out...
  • Page 50 2. WIRING Connector J6 Pin# Signal In/Out Description Remarks TD4-A Serial CH4, output IEC61162-1 Use TTYCS(LA)-1Q, IEC 61162-1 only TD4-B Serial CH4, output IEC61162-1 RD4-H Serial CH4, input IEC61162-1 RD4-C Serial CH4, input IEC61162-1 Connector J7 Pin# Signal In/Out Description Remarks TD5-A Serial CH5, output IEC61162-1...
  • Page 51 2. WIRING How to set contact input/output The connector J11 can be used for the connection of contact input or voltage input. Refer to the figures shown below to make the wiring which complies with the input specification. Note: The input must not exceed the range of the input voltage, to prevent malfunc- tion.

  • Page 52: Power Supply Unit

    2. WIRING Power Supply Unit This procedure shows how to wire the power supply. For details see the interconnec- tion diagram. 1. Connect the ground wire between the ground terminal on the chassis and the ship’s earth. Note: Electrical shock can result if the ground wire is not connected properly. Ground terminal 2.
  • Page 53 2. WIRING 5. As shown below, fabricate the cables. For retrofit, the optional LAN Signal Con- verter kit. See section 2.7 for wiring. TTYCS(LA)-1Q Armor Drain wire Vinyl tape Crimp-on lug Sheath (Clamp here.) Pass the vinyl sheath (local supply) onto the drain wire, then attach the crimp-on lug (preattached to the earth clamp on the processor unit) to the wire.
  • Page 54 2. WIRING 7. Fabricate the antenna cable as shown below. RW-00135 See "How to fabricate the LAN cable" on page 2-16 for how to attach the LAN cable connector. Power line Armor Vinyl tape LAN cable Sheath Sheath Braided Crimp-on lug (M4) shield Crimp-on lug (M3) Wrap the shield of LAN cable...
  • Page 55 2. WIRING 10. Connect the power line and the LAN cable of the antenna cable as shown below. Connect LAN cable of Connect power line of Connect power line of antenna cable to J102 antenna cable to TB131 antenna cable to TB131 on PSU-CNTL Board.

  • Page 56: Monitor Unit

    2. WIRING 15. Pull up the plastic cover and connect the power cable. 16. Remount the connector cover for the power cable. 17. Reattach the cover of the power supply unit. Monitor Unit For the wiring of the monitor unit, see the operator’s manual supplied with the monitor unit.
  • Page 57 2. WIRING Slide switch Set the slide switch to "ON" (default setting). This setting automatically powers the monitor unit on or off according to the DVI signal input. The power switch of the mon- itor unit is inoperative. Note: The OFF position provides control of the monitor unit power with the power switch of the monitor unit.

  • Page 58: Sensor Adapters (Option)

    2. WIRING Sensor Adapters (option) A maximum of eight MC-3000S can be connected to a sensor network (for the redun- dant connection: 16). The MC-3000S (serial input/output, IEC61162-2/1, 4ch) can connect a maximum of 10 sensor adapters, using the MC1.5-W cables. The maximum number of MC-3010A units is five.
  • Page 59 2. WIRING 2.6.1 MC-3000S Use the LAN cable FR-FTPC-CY cable to connect the MC-3000S and the processor unit. With HUB-100, a maximum of eight MC-3000S can be connected. Fabrications TTYCS-1Q cable LAN cable (FR-FTPC-CY) (J8) (J8) (J9) (J9) #1 to 4: 110 #1 to 4: 110 #1 to 4: 100 #1 to 4: 100...
  • Page 60 2. WIRING TTYCSLA-1 cable TTYCS-1 cable Core: 6 Core: 6 Core: 6 Core: 6 Vinyl tape Vinyl tape Shield (fold back) Shield (fold back) Vinyl tape Vinyl tape (width: 10) (width: 10) (width: 10) (width: 10) See Note 1. See Note 1. TTYCS-4 cable TTYCSLA-4 cable J4/J6: 100...
  • Page 61 2. WIRING Connections Unfasten four screws to remove the cover. Pass the cables through the clamps and attach the cables to respective connectors. The shield (or drain wire) must lie in (con- nected to) the clamp. For TTYCSLA cables, attach a shrinking tube (local supply), to drain wire, then use these crimp-on lugs and screws to connect the drain wire here.
  • Page 62 2. WIRING How to set input specification (J4 to J9) For connectors J4 to J7, the connections are different depending on the input specifi- cations as shown below. Connector J4 Pin # Signal name In/Out Remarks IEC61162-2 IEC61162-1 TD1-A Serial CH1, out- TTYCS(LA)-4 TTYCS(LA)-4 put IEC61162-1/...
  • Page 63 2. WIRING Connector J6 Pin # Signal name In/Out Remarks IEC61162-2 IEC61162-1 TD3-A Serial CH3, output IEC61162-1/2 TTYCS(LA)-4 TTYCS(LA)-4 TD3-B Serial CH3, output IEC61162-1/2 RD3-A Serial CH3, input IEC61162-2 No connection RD3-B Serial CH3, input IEC61162-2 ISOGND3 Isolation, GND (CH3) RD3-H Serial CH3, input IEC61162-1 No connection TTYCS(LA)-4...
  • Page 64 2. WIRING Case gasket OP24-28 The optional kit OP24-28 protects the connectors on the MC-3000C to waterproofing standard IPX2. Case gasket (type: OP24-28, code no.: 001-169-970) Name Type Code No. Remarks Case gasket (serial) 24-014-2051 100-367-880-10 For MC-3000S 1. Unfasten four binding screws to remove the cover from the adapter. Binding screw Cover 2.
  • Page 65 2. WIRING 2.6.2 MC-3010A/3020D/3030D • MC-3010A: Inputs analog signal. To use MC-3010A as current input, connect short pins to each terminals. • MC-3020D: Inputs digital signal (8ch contact input). Contact or voltage input is se- lectable (contact input requires short pins). •...
  • Page 66 2. WIRING Connection For TTYCSLA cables, pass the drain wire through shrink tubing, then attach these crimp- on lugs and screws to connect drain wires to chassis. IV-1.25sq. (Local supply) IV-1.25sq. (Local supply) TTYCS-1/ TTYCS-1/ TTYCSLA-1 TTYCSLA-1 MC1.5-W-L cable MC1.5-W-L cable IV-1.25sq.
  • Page 67 2. WIRING • Power voltage: Input the amount of power voltage change to the operational ampli- fier. AN +15V +15V +VS1 AN-IN Voltage +VS2 source AN-GND Opeamp OutGnd CURR-JP1 - VS2 InGnd CURR-JP2 - VS1 Jumper: open 1kΩ 1% 0.5Wx2 Load - 15V AN GND AN - 15V...
  • Page 68 2. WIRING Connector J5 Pin # Signal name In/Out Description Power voltage Power current AN3_IN Analog 3 input TTYCS(LA)-1 AN3_GND Analog 3 GND CURR3_JP1 Analog 3 input, power current/ Pin #3-#4: open Pin #3-#4: short voltage setting jumper 1 CURR3_JP2 Analog 3 input, power current/ voltage setting jumper 1 How to set ACK input (MC-3020D)
  • Page 69 2. WIRING ACK1 ACK1 ACK2 ACK2 Pin # Signal name In/Out Remarks contact voltage contact voltage DC12V_OUT ACK2 In Pin #1-#2: No connec- short tion DIGI_IN2 MPYC-12 According to ACK2 input DIGI_RTN2 MPYC-12 No connec- (DC12V) tion Connector J4 ACK3 ACK3 ACK4 ACK4...
  • Page 70 2. WIRING Connector J6 ACK7 ACK7 ACK8 ACK8 Pin # Signal name In/Out Remarks contact voltage contact voltage DC12V_OUT ACK1 In Pin #1-#2: No connec- short tion DIGI_IN7 MPYC-12 According to ACK7 input DIGI_RTN7 MPYC-12 GND (DC12V) No connec- tion DC12V_OUT ACK2 In Pin #1-#2:...
  • Page 71 2. WIRING Connector J5 Signal Alarm5 Alarm5 Alarm6 Alarm6 Remarks name NO Out NC Out NO Out NC Out Alarm5 MPYC-12 No connection COM5 MPYC-12 No connection Alarm5 MPYC-12 No connection COM6 MPYC-12 No connection Connector J6 Signal Alarm7 Alarm7 Alarm8 Alarm8 Remarks...
  • Page 72 2. WIRING 2.6.3 How to set jumper blocks in the sensor adapters MC-3000S Set the jumper blocks on the MC-CS Board (24P0114) referring to the tables that fol- low. (J22/J23 are not used) J14 J22 J23 J15 J16 J17 (Not Used) J20 J21 (J20/J21 are not used) MC-CS Board (24P0114)
  • Page 73 2. WIRING (Termination resistor ON) • When setting the starting/ending terminal for the multipoint, or the multipoint is not connected (CH1 to 4). (Terminal resistor OFF) • When setting the terminal other than starting/ending for the multipoint (CH1 to 4). Jumper block J14 Connector J4 (CH1) SHORT...
  • Page 74 2. WIRING MC-3010A/3020D/3030D This paragraph shows how to set the MC-ANLG Board (24P0115, for MC-3010A), MC-DIN Board (24P0116, for MC-3020D) and MC-DOUT Board (24P0117, for MC- 3030D). Rotary switch: Use the rotary switch (U18) to set the MODBUS address with a digit of number from "0".

  • Page 75: Lan Signal Converter Kit (Option)

    2. WIRING LAN Signal Converter Kit (option) The optional LAN Signal Converter OP03-223-3 (code: 001-254-380) allows the use of existing antenna cable RW-9600, or enables installation of the antenna unit on the foremast, using antenna cable RW-9600. 2.7.1 Application overview The LAN Signal Converter has two applications.
  • Page 76 2. WIRING Application 2: Foremast installation Foremast installation, where the distance between the antenna unit and the power supply unit is more than 100 m (max. 460 m). See section 2.8 and the interconnection diagram for connections in the junction box. The Cable Extension Kit (Type: OP03-224-3, Code No.: 001-254-410), comprised of two junctions boxes, two LAN Signal Converters and necessary hardware, is option- ally available.
  • Page 77 2. WIRING 4. Fasten the BNC case to the antenna unit with two screws. Connect the coaxial ca- ble to the BNC case then pass it through the locking wire saddle circled below. Coaxial cable Coaxial cable 5. Fasten the converter to the transceiver unit with four screws at the locations cir- cled below.
  • Page 78 2. WIRING 7. Connect the LAN cable to the LAN port on the converter. Pass the cable through the four locking wire saddles circled below then connect the cable to J821 on the SPU board. J821 J821 8. Mount the transceiver unit. Connect the coaxial cable from the BNC case to the converter.
  • Page 79 2. WIRING 2.7.3 Installation in the power supply unit Some parts or wiring may have been omitted from the illustrations of the power supply unit for clarity. 1. Set the M_S switch on the converter to the M (Master) position. Master/Slave Coax/PLC TEST...
  • Page 80 2. WIRING 5. Pass the LAN cable thru the clamp circled below then connect it to J102 on the PSU-CNTL board. (The cable will be connected to the converter after the convert- er is installed.) J102 J102 6. Fasten the converter with three screws at the locations shown circled below. At- tach the two supplied locking wire saddles to the locations circled below.
  • Page 81 2. WIRING LAN cable Power cable Power cable J107 J107 Coaxial Coaxial cable cable 2.7.4 How to check the installation Observe the LEDs on the converter to check for proper operation, troubleshoot. Master/Slave Coax/PLC TEST HMC-200CE-A LAN PWR State Meaning Power OFF Lighting green Power ON...

  • Page 82: Junction Box (Option)

    2. WIRING Junction Box (option) Junction boxes are required when the distance between the antenna unit and power supply unit is greater than 100 meters (max. 460 meters); for example, the antenna unit is installed on the foremast. Use signal cable RW-9600(x2), power cable DPYCY- 6(x3), and coaxial cable RG-12/UY(x3).
  • Page 83 2. WIRING Connect the RW-9600 cable as shown below. Refer also to the interconnection dia- gram. POWER SUPPLY UNIT JUNCTION BOX JUNCTION BOX ANTENNA UNIT PSU-014 RJB-001 RJB-001 RSB-128 TB131 RW-9600,MAX.30m RW-9600,MAX.30m TB-801 DPYCY-6,MAX.400m TX-HV-H TX-HV-H TX-HV-C TX-HV-C DPYCY-6,MAX.400m P48V-H RED[B] RED[B] P48V-H...

  • Page 84: Intelligent Hub (Option)

    2. WIRING Intelligent HUB (option) Fix the LAN cables to the cable clamp with the cable ties (supplied). Power port Power Fail DPYC-1.5 cable DPYC-1.5 cable Ground wire (IV-1.25sq., supplied) LAN cable No use. LAN port To gateway network (ECDIS, radar, etc.) Attach the LAN cap (supplied) to the unused connector holes to comply with waterproofing standard IPX2.

  • Page 85: How To Extend The Control Unit Cable (Option)

    2. WIRING 2.10 How to Extend the Control Unit Cable (option) To extend the length of the cable between a control unit and the processor unit, use the optional cable assy 6TPSH-XH12X2-LxxSP1 (for RCU-024) or 6TPSH-XH12X2- LxxSP2 (for RCU-026). You can select the cable length among 10, 20 and 30 m. 2.10.1 Radar control unit (RCU-025) 1.
  • Page 86 2. WIRING 9. Unfasten the three bolts circled in the figure below to remove the cable clamp (up- per). Clamp holes (upper) Unfasten this bolt to use Unfasten this bolt to use the lower clamp holes. the lower clamp holes. Clamp holes (lower) Unfasten these three bolts to remove the upper plate.
  • Page 87 2. WIRING 2.10.2 Trackball control unit 1. Unfasten four binding screws (M3 8) from the bottom of the control unit, and a pan head screw (M3 8) and flat washer from the back of the control unit to remove the cover.
  • Page 88 2. WIRING Cable assy Shield Cable clamp Circuit board 6. Reattach the control unit cover. 7. Unfasten four screws (M4 8) to remove the processor unit cover. 8. Unfasten the three bolts circled below to remove the cable clamp (upper) as shown below.

  • Page 89: Settings And Adjustments

    SETTINGS AND ADJUSTMENTS Note: After completing the settings and adjustments, copy the setting data to a USB flash memory, referring to section 23.2 in the Operator's Manual. This will allow easy restoration of setting data after the SPU Board is replaced, etc. How to Access the Radar Installation Menu The [RADAR INSTALLATION] menu has various items for adjustment of the radar.

  • Page 90: How To Adjust The Sweep Timing

    3. SETTINGS AND ADJUSTMENTS 1. Select a stationary target echo at a range between 0.125 and 0.25 NM, preferably near the heading line. 2. Operate the EBL control to bisect the target echo. 3. Read the target bearing. 4. Measure the bearing of the stationary target on a navigation chart and calculate the difference between the actual bearing and apparent bearing on the radar screen.

  • Page 91: How To Suppress Main Bang

    3. SETTINGS AND ADJUSTMENTS How to Suppress Main Bang Main bang is the clutter at the center of the screen that you typically see on the radar display, and it may mask close-in targets. If main bang appears at the screen center, suppress it as follows.
  • Page 92 3. SETTINGS AND ADJUSTMENTS 3.5.2 How to set the width and length for the picture from the exter- nal radar If two FAR-3xx0 series radars are to be used for the dual radar display, set the same dis- play area on each radar to ensure proper per- formance.
  • Page 93 3. SETTINGS AND ADJUSTMENTS 5. Use the scrollwheel to set [START] and [ANGLE], referring to the example below. Spin the scrollwheel to set and push it to confirm. A solid green line marks the dual radar display area. Width of sector ANGLE START (Example: 100°)

  • Page 94: Other Settings

    3. SETTINGS AND ADJUSTMENTS Other Settings This section describes the menu items not previously described. 3.6.1 [ECHO ADJ] menu Open the main menu then select [9 RADAR IN- STALLATION] [1 ECHO ADJ] to open the [ECHO ADJ] menu. [1 VIDEO LEVEL ADJ] Adjust the video level manually.
  • Page 95 3. SETTINGS AND ADJUSTMENTS 3.6.2 [SCANNER] menu Open the main menu then select [9 RADAR IN- STALLATION] [2 SCANNER] to open the [SCANNER] menu. [1 BLIND SECTOR1], [2 BLIND SECTOR2] Set area(s) where to prevent transmission. Head- ing must be properly aligned (see section 3.2) be- fore setting any blind sector.
  • Page 96 3. SETTINGS AND ADJUSTMENTS 3.6.3 [INSTALLATION] menu Open the main menu then select [9 RADAR INSTALLATION] [3 INSTALLATION] to open the [INSTALLATION] menu. IMO-/A-type radars B-type radar AUTO/MANUAL AUTO/MANUAL [1 RANGE UNIT] For the B-type radar, select the range unit, NM, SM, KM or kyd then push the left but- ton.
  • Page 97 3. SETTINGS AND ADJUSTMENTS [6 PM GAIN ADJ] Adjust the performance monitor, Before setup Before setup After setup After setup automatically or manually, when- ever the magnetron is replaced. For automatic adjustment, no fur- ther operation is required; close 8.1 NM to 8.1 NM to the menu at the completion of the 10.1 NM...
  • Page 98 3. SETTINGS AND ADJUSTMENTS 3.6.4 [TT PRESET] menu Open the main menu then select [9 RADAR INSTALLATION] [4 TT PRESET] to open the [TT PRESET] menu. Page 2 Page 1 [1 TT DATA OUTPUT] Show the [TT DATA OUTPUT] menu. Note: Confirm the data input configuration for the equipment which will receive the TT (target tracking) sentence BEFORE setting this menu.
  • Page 99 3. SETTINGS AND ADJUSTMENTS [2 NUMBER OF TT] Set the number of targets that can be acquired, [100] or [MAX] (200). For FAR-2xx7 radar, select [100]. [3 MAX RANGE] Select the maximum target tracking range, 24 or 32 nm. [4 QV DISPLAY] [OFF]: Normal picture, [ON]: Quantized video.
  • Page 100 3. SETTINGS AND ADJUSTMENTS [7 TRACK PRESET] • [GATE SIZE]: Set the gate size among [S], [M], [L] or [LL]. • [FILTER RESPONSE]: Set the filter response function. The setting range is 1 to 4. 1: Filter response is improved. 4: Filter stability is improved.
  • Page 101 3. SETTINGS AND ADJUSTMENTS 3.6.5 [OTHERS] menu Open the main menu then select [9 RADAR IN- STALLATION] [5 OTHERS] to open the [OTH- ERS] menu. [1 DEMO ECHO] Select the type of demonstration echo to use. [EG] (Echo Generator), [TT-TEST] or [PC]. Select [OFF] to deactivate the demonstration echo feature.

  • Page 102: Network Transmission Setting Between Ecdis And Radar

    3. SETTINGS AND ADJUSTMENTS Network Transmission Setting Between ECDIS and Radar Connect the ECDIS and FAR-3xx0 series radar with the LAN cable to show the radar echo and TT symbols on the ECDIS chart display, and show the ECDIS route and user chart symbols on the radar display.

  • Page 103: Synchronization With Ship's Clock

    3. SETTINGS AND ADJUSTMENTS 6. When [FWD DIST NM] is different between port and starboard sides, check the checkbox of [Use different values for Port and Starboard] and then enter each set- ting value. 7. Click the [Save] button to save the configuration. Synchronization With Ship’s Clock The time (UTC) received from the GPS is shown.

  • Page 104: How To Change The Display Color For Sensor Data Based On Integrity

    3. SETTINGS AND ADJUSTMENTS 3.10 How to Change the Display Color for Sensor Data Based on Integrity The following procedure shows how to change the color of the data in the sensor in- formation box based on the results of the Integrity Check. For the Integrity Check, see the Operator’s Manual for the Chart Radar.

  • Page 105: Web Setting Menu

    3. SETTINGS AND ADJUSTMENTS 4. Click [Ship & Route Parameters], then click the [Function2] tab. 5. Check the checkbox of [Show Echo tab at Overlay/NAV Tools]. 6. Click the [Save] button to save the configuration. 3.12 Web Setting Menu Set up the radar from the [Common Installation Setting] menu on the web browser. For details on the [Common Installation Setting] menu, see the Instruction Manual (E32- 01305).
  • Page 106 3. SETTINGS AND ADJUSTMENTS This page is intentionally left blank. 3-18...

  • Page 107: Input/Output Data

    EPFS meeting the requirements of the IMO resolution MSC.112(73). Gyrocompass meeting the requirements of the IMO resolution A.424(XI). SDME meeting the requirements of IMO resolution MSC.96(72). The radar may be interconnected via HUB-3000 to other FURUNO processing units having approved LAN ports. Processor Unit Input and output data are shown in the table below.

  • Page 108: Iec 61162 Sentences

    4. INPUT/OUTPUT DATA IEC 61162 Sentences Input sentence and sentence priority Data Sentence priority Acknowledge alarm AIS base station addressed channel management command AIS addressed and binary broadcast acknowledgment AIS voyage static data Datum Depth DPT>DBT Heartbeat supervision report Heading (true) THS>HDT NAVTEX received message Position...

  • Page 109: Appendix 1 Jis Cable Guide

    EX: TTYCYSLA - 4 MPYC - 4 TTYCSLA-4 # of cores Designation type Designation type # of twisted pairs The following reference table lists gives the measurements of JIS cables commonly used with Furuno products: Cable Core Cable Core Diameter Diameter...
  • Page 110 APPENDIX 2 ROD TERMINALS MC-3000S, MC-CS Board (24P0114) Connector # Pin # Signal name Rod terminal to use Connected cable 24V_VOUT AI 0.34-6 TQ (blue) 24V_GND MODBUS-A AI 0.14-8 GY (gray) MC1.5-W-Lxxx MODBUS-B Connector # Pin # Signal name Rod terminal to use Connected cable 24V_IN AI 1.5-6 BK (black)

  • Page 111: Appendix 2 Rod Terminals

    APPENDIX 2 ROD TERMINALS Connector # Pin # Signal name Rod terminal to use Connected cable TD4-A TD4-B RD4-A TTYCS-4 RD4-B AI 0.75-6 GY (gray) TTYCSLA-4 ISOGND4 RD4-H RD4-C Connector # Pin # Signal name Rod terminal to use Connected cable TD5-A TD5-B TTYCS-1Q...
  • Page 112 APPENDIX 2 ROD TERMINALS MC-3010A MC-ANALG Board (24P0115) Connector # Pin # Signal name Rod terminal to use Connected cable 24V_IN AI 0.34-6 TQ (blue) 24V_GND MODBUS-A AI 0.14-8 GY (gray) MC1.5-W-Lxxx MODBUS-B Connector # Pin # Signal name Rod terminal to use Connected cable 24V_OUT AI 0.34-6 TQ (blue)
  • Page 113 APPENDIX 2 ROD TERMINALS Connector # Pin # Signal name Rod terminal to use Connected cable DV12V_OUT1 DIGI_IN1 DIGI_RTN1 AI 1-6 RD (red) MPYC-12 DC12V_OUT2 DIGI_IN2 DIGI_RTN2 Connector # Pin # Signal name Rod terminal to use Connected cable DV12V_OUT3 DIGI_IN3 DIGI_RTN3 AI 1-6 RD (red)
  • Page 114 APPENDIX 2 ROD TERMINALS MC-3030D, MC-DOUT Board (24P0117) Connector # Pin # Signal name Rod terminal to use Connected cable 24V_IN AI 0.34-6 TQ (blue) 24V_GND MODBUS-A AI 0.14-8 GY (gray) MC1.5-W-Lxxx MODBUS-B Connector # Pin # Signal name Rod terminal to use Connected cable 24V_OUT AI 0.34-6 TQ (blue)

  • Page 115: Appendix 3 Digital Interface

    APPENDIX 3 DIGITAL INTERFACE Digital Interface Input sentence ABK, ACK, ACM, ACN, ALR, CUR, DBT, DPT, DTM, GGA, GLL, GNS, HBT, HDT, MTW, MWV, NRX, RMC, RRT, THS, VBW, VDM, VDO, VDR, VHW, VSD, VTG, ZDA Output sentences ABM, ACK, ALC, ALF, ARC, BBM, EVE, HBT, OSD, RRT, RSD, TLB, TTM, VSD Data reception Data is received in serial asynchronous form in accordance with the standard referenced in IEC 61162-2 or IEC 61162-1 Ed.4.
  • Page 116 APPENDIX 3 DIGITAL INTERFACE ACM, ACN - Alert command $**ACM,hhmmss.ss,aaa,x.x,x.x,ca,a*hh<CR><LF> $**ACN,hhmmss.ss,aaa,x.x,x.x,ca,a*hh<CR><LF> 1. Time (hh=00 to 23, mm=00 to 59, ss.ss=00.00 to 60.99, null) 2. Manufacturer mnemonic code (3 digit alphanumeric code, null) 3. Alert identifier (0 to 9999999) 4. Alert instance (1 to 999999, null) 5.
  • Page 117 APPENDIX 3 DIGITAL INTERFACE DTM - Datum reference $**DTM,ccc,a,x.x,a,x.x,a,x.x,ccc,*hh<CR><LF> 1 2 3 4 5 6 7 1. Local datum (W84=WGS84 W72=WGS72 S85=SGS85, P90=PE90 2. Local datum subdivision code (one character, null) 3. Lat offset, min (0 - 59.99999) 4. N/S 5.
  • Page 118 APPENDIX 3 DIGITAL INTERFACE HBT - Heartbeat supervision sentence $**HBT,x.x,A,x*hh<CR><LF> 1 2 3 1. Configured repeat interval (00.0 to 99.9(s)) 2. Equipment status (A=Normal V=System fail) 3. Sequential sequence identifier (0 to 9) HDT - Heading, true $**HDT, xxx.x,T*hh<CR><LF> 1. Heading, degrees (0.00 to 360.00) 2.
  • Page 119 APPENDIX 3 DIGITAL INTERFACE RMC - Recommended minimum specific GPS/TRANSIT data $GPRMC,hhmmss.ss,A,llll.ll,a,yyyyy.yy,a,x.x,x.x,ddmmyy,x.x,a,a,a*hh<CR><LF> 2 3 4 6 7 8 10 11 1213 1. UTC of position fix (000000 - 235959) 2. Status (A=data valid, V=navigation receiver warning) 3. Latitude (0000.00000 - 9000.0000) 4.
  • Page 120 APPENDIX 3 DIGITAL INTERFACE VDM - UAIS VHF data-link message !AIVDM,x,x,x,x,s--s,x,*hh<CR><LF> 1 2 3 4 5 6 1. Total number of sentences needed to transfer the message (1 to 9) 2. Message sentence number (1 to 9) 3. Sequential message identifier (0 to 9, null) 4.
  • Page 121 APPENDIX 3 DIGITAL INTERFACE VTG - Course over ground and ground speed $**VTG,x.x,T,x.x,M,x.x,N,x.x,K,a,*hh <CR><LF> 1 2 3 4 5 6 7 8 9 1. Course over ground, degrees (0.00 - 360.00) 2. T=True (fixed) 3. Course over ground, degrees (No use) 4.
  • Page 122 APPENDIX 3 DIGITAL INTERFACE ALF - Alert sentence $**ALF,x,x,x,hhmmss.ss,a,a,a,aaa,x.x,x.x,x.x,x,c--c,*hh<CR><LF> 1 2 3 5 6 7 8 9 10 11 12 13 1. Total number of ALF sentences this message (1, 2) 2. Sentence number (1, 2) 3. Sequential message identifier (0 to 9) 4.
  • Page 123 APPENDIX 3 DIGITAL INTERFACE OSD- Own ship data $**OSD,53.21,A,57.89,R,12.52,R,45.67,6.78,N*hh<CR><LF> 1. Heading, degrees true (0.00 - 359.99, null) 2. Heading status (A=data valid, V=data invalid) 3. Vessel course, degrees true (0.00 - 359.99, null) 4. Course reference (B/M/W/R/P, null) B=Bottom tracking log M=Manually entered W=Water referenced R=Radar tracking (of fixed target)
  • Page 124 APPENDIX 3 DIGITAL INTERFACE TTM - Tracked target message $RATTM,05,12.34,23.4,R,45.67,123.4,T,1.23,8.23,N,c--c,T,R,hhmmss.ss,M*hh<CR><LF> 9 10 11 12 13 1. Target number (00 to 999) 2. Target distance from own ship (0.000 - 99.999) 3. Bearing from own ship,degrees (0.0 - 359.9) 4. True or Relative (T) 5.

  • Page 125: Serial Interface

    APPENDIX 3 DIGITAL INTERFACE Serial Interface TD-A TD-B LTC1535 ISOGND RD-A RD-B 110 ohm* * Set with jumper. 470 ohm Open/close switchable. RD-H PC-400 RD-C Processor Unit: IEC 61162-2/1 input/output Sensor Adapter: IEC 61162-2/1 input/output 470 ohm RD-H PC-400 RD-C Processor Unit: IEC 61162-1 input Sensor Adapter: IEC 61162-1 input 10 ohm...
