Bosch ICP-MAP5000-2 Installation Manual page 83

MAP 5000
Selecting the access level
AE 1 Access for everyone, no authorization/code required
AE 2A Access for users, user passcode required
AE 2B Access for users, user passcode required
AE 3 Access for installers via control center
1.
2.
3.
AE 3 Access for installers via RPS for MAP
1.
2.
AE 4 Access for manufacturers via RPS for MAP
1.
2.
3.
4.
5.
1) Activation of the warning device on opening the control panel enclosure may be omitted if
access to access level 3 is controlled by switches, locks (at least 15,000 variation possibilities)
or other equivalent means.
Internal warning device when control panel enclosure is opened
An internal warning device must be provided that trips a time-limited audible alarm when the
control panel enclosure is opened in unarmed state.
1.
2.
Functions of the Access Levels
The assignment of the functions to the access levels 2 and 3 can be adapted in RPS.
Further subdivisions are possible within the access levels if the owner wishes to grant the
users different permissions: User Manager > Permission Sets
General permissions
May silence buzzer on control center
May change own user passcode
Bosch Sicherheitssysteme GmbH
Open control panel enclosure.
The internal warning device is activated for 3 sec.
Switch to installer mode (refer to Installer button, page 67).
Enter installer passcode.
Open control panel enclosure.
Internal warning device is activated for 3 sec.
or
authorize from RPS with an AE 2 user with corresponding permissions (control center:
main menu page 2 > RPS).
Establish a connection between the panel and RPS.
Authorize the manufacturer user with an AE 3 user with corresponding permissions
(control center: main menu page 1 > maintenance page 3 > manufacturer permission).
Open control panel enclosure.
The internal warning device is activated for 3 sec.
Switch to installer mode = AE 3 (Installer button, page 67).
Login with the passcode of the manufacturer at the installer control center (Manufacturer
authorization, page 60).
Establish a connection between the panel and RPS.
Assign device siren to free output.
In the properties> behavior item list of the device siren, activate the option Include
External Tamper Alarm Disarmed of Onboard Tamper.
1
Installation manual
Appendices | en
1
1
Access Level
1 2A 2B
X X X
X X
2016.06 | 17 | F.01U.168.332
83
3 4
X
X X
