70 en | Technical Specifications
Number of devices
MAP LSN gateways
MAP control centers
DR2020T printer
MAP power supplies 150W
MAP CAN splitter modules
Ethernet interface
Management system connection
Number of inputs
Programmable inputs on LSN Bus
Number of inputs (on MAP main panel)
Number of outputs
Programmable outputs on LSN Bus
Power drive (on MAP main panel)
Dry contact (on MAP main panel)
Auxiliary power (on MAP main panel)
Supervised output (on MAP DE module)
Open-collector output (on MAP DE module)
1
VdS system is limited to two areas, when connecting to the MAP control centres via the
internal and external BDB. More areas can be realized with additional operating and display
panels (one per area) on the LSN bus or with additional control centers on the external BDB
using the CAN splitter module.
Environmental
Minimum operating temperature in °C
Maximum operating temperature in °C
Minimum storage temperature in °C
Maximum storage temperature in °C
Minimum relative humidity in %
Maximum relative humidity in %
Protection class
2016.06 | 17 | F.01U.168.332
8
32
1 (in VdS systems for service purposes only)
32
8
1, RJ 45 connection
Via Ethernet interface and the Open Intrusion
Interface OII or the MAP OPC server from
Bosch - in VdS systems, only feedback-free
connection as information system via
exclusive transmission path
Limited to maximum number of available
addresses system wide
8
Limited to maximum number of available
addresses system wide
2
2
1
3
2
-10
55
-20
60
5
95
IP30
IP31 (with an edge protection profile)
