DST1-XD0808SL-1
5-4-5

Internal Circuits and Terminal Arrangement

(non-isolated)
V+
CAN
H
DeviceNet
Shield
CAN
L
V−
I/O power
supply
circuit
1 2 3
V0 V0 IN0
11 12 13
G0 G0 T0
Node address switches
DeviceNet
communications
connector
• Refer to 4-2 Indicators for details on the LED indicators.
• Refer to 2-4 Connecting the Communications Connector for details on the
DeviceNet communications connector.
• Refer to 5-4-5 Internal Circuits and Terminal Arrangement for details on
the terminal arrangement.
The following diagram shows the internal circuits of the DST1-XD0808SL-1.
DC-DC
converter
physical
layer
Test output
Safety input circuit
circuit
(sinking inputs)
(sourcing outputs)
4 5 6 7 8 9
IN1 IN2 IN3 IN4 IN5 IN6
14 15 16 17 18 19
T1 T0 T1 T0 T1 T2
Internal circuits
I/O power
Safety output circuit
supply
(sourcing outputs)
circuit
10 21 22 23 24 25
OUT OUT OUT
IN7 V1 V1
0 1 2
20 31 32 33 34 35
T3 G1 G1 G1 G1 G1
Section 5-4
Operation display section
I/O connectors
26 27 28 29 30
OUT OUT OUT OUT OUT
3 4 5 6 7
36 37 38 39 40
G1 G1 G1 G1 G1
