Intel® Server S2600WF Product Family Configuration Guide and Spares/Accessories List
4 or 8-port Mezzanine 12Gb 4 or 8-port 12Gb SAS RAID
SAS ROC Module to 12 Gb PCIe* add-in card to 12 Gb
SAS Expander
12 Gb SAS Expander
RES3TV360 installed:
SAS Mezz -> Exp 0-3 (G) SAS PCIe -> Exp 0-3 (G)
730mm HD -- HD
SAS PCIe -> Exp 4-7 (H)
SAS Mezz -> Exp 4-7 (H)
730mm HD -- HD
From data above, select SAS PCIe -> Exp 0-3 (G)
appropriate cable kits from
list below: SAS PCIe -> Exp 4-7 (H)
AXXCBL730HDHD
(2) 730mm cables Included in From data above, select
all 2.5" L6) appropriate cable kits from list
below:
AXXCBL650HDHD
AXXCBL730HDHD
(2) 730mm cables Included in
all 2.5" L6)
12 Gb SAS Expander to drive 12 Gb SAS Expander to drive
bays
Use cables included in SAS Use cables included in SAS
Expander Kit Expander Kit
62
SAS Expander
12 Gb SAS Expander
RES3TV360 installed:
From Riser #1:
650mm HD -- HD
650mm HD -- HD
From Riser #2:
730mm HD -- HD
730mm HD -- HD
bays
