Intel R2000WF Configuration Manual page 24

Feature
Storage Bay Options
Supported Rack Mount Kit Accessory
Options
** Storage System Configurations include the following: R2312WFxxxx and R2224WFxxxx
Non-Storage System Configurations include: R2308WFxxxx, R2208WFxxxx, and R2208WFxxxx + 8 Drive Accessory Kit
Intel® Server S2600WF Product Family Configuration Guide and Spares/Accessories List
Description
Hot Swap Backplane Options:
Note: All available backplane options have support for SAS 3.0 (12 Gb/sec)
 8 x 3.5" SAS/ SATA
 8 x 2.5" combo backplane – SAS/SATA/NVMe
 8 x 2.5" Dual Port SAS
 12 x 3.5" SAS/ SATA (supports up to 2 NVMe drives)
Storage Bay Options:
 8 x 3.5" SAS/SATA hot swap drive bays + Standard front panel
 12 x 3.5" SAS/SATA hot swap drive bays (supports up to 2NVMe drives) + Storage Front Panel
 8 x 2.5" SAS/SATA/NVMe hot swap drive bays + Standard front panel
 16 (8+8 acc) x 2.5" SAS/SATA/NVMe hot swap drive bays + Standard front panel
 24 x 2.5" SAS/SATA/NVMe swap drive bays + Standard front panel
 2 x 2.5" SATA SSD Back of Chassis Hot Swap Drive Bays (accessory Option)
 2 x internal fixed mount 2.5" SSDs (all SYSTEM MODELs)

AXXELVRAIL – Enhanced value rack mount rail kit - 424mm max travel length, 59kgs (130lbs.) max supported weight

AXXFULLRAIL- 2U Premium rail with CMA support – 800mm max travel length, 45kgs (99lbs.) max supported weight

AXXSHRTRAIL - 2U Premium rail without CMA support - 788mm max travel length, 45kgs (99lbs.) max supported weight
 AXX2POSTBRCKT – Two post fixed mount bracket kit
 AXXCMA2– Cable Management Arm – (*supported with AXXFULLRAIL only)
16
