Table 23: Components of the Topology for Configuring BPDU Protection on EX Series Switches
Property
Switch 1 (Distribution Layer)
Switch 2 (Access Layer)
Configuration
CLI Quick
Configuration
Step-by-Step
Procedure
Copyright © 2017, Juniper Networks, Inc.
Table 23 on page 221 shows the components that will be configured for BPDU protection.
Settings
Switch 1 is connected to Switch 2 on a trunk interface.
Switch 2 has these access ports that require BPDU protection:
ge-0/0/5
ge-0/0/6
This configuration example uses RSTP topology. You also can configure BPDU protection
for MSTP topologies at the [
To configure BPDU protection on two access interfaces:
Quickly configure RSTP on the two Switch 2 interfaces, and then configure BPDU
protection on all edge ports on Switch 2 by copying the following commands and pasting
them into the switch terminal window:
NOTE: This example configures BPDU protection on specific interfaces.
Starting with Junos OS Release 15.1 for EX Series and QFX Series switches
with support for the Enhanced Layer 2 Software (ELS) configuration style,
you can also configure BPDU protection globally on all spanning tree
interfaces. See
on page 230 for additional information.
[edit]
set protocols rstp interface ge-0/0/5 edge
set protocols rstp interface ge-0/0/6 edge
set protocols rstp bpdu-block-on-edge
To configure RSTP on the two Switch 2 interfaces, and then configure BPDU protection:
Configure RSTP on interface
1.
as edge ports:
[edit protocols rstp]
user@switch# set interface ge-0/0/5 edge
user@switch# set interface ge-0/0/6 edge
Configure BPDU protection on all edge ports on this switch:
2.
[edit protocols rstp]
user@switch# set bpdu-block-on-edge
Chapter 10: Using BPDU Protection, Root Protection, and Loop Protection
edit protocols mstp ] hierarchy level.
"Configuring BPDU Protection on Spanning Tree Interfaces"
and interface
ge-0/0/5
, and configure them
ge-0/0/6
221
