Spanning-Tree Protocols Feature Guide for EX9200 Switches

Understanding MSTP for EX Series and QFX Series Switches

MSTP Maps Multiple VLANs

78
Ethernet networks are susceptible to broadcast storms if loops are introduced. However,
an Ethernet network needs to include loops because they provide redundant paths in
case of a link failure. Spanning-tree protocols address both of these issues because they
provide link redundancy while simultaneously preventing undesirable loops.
Spanning-tree protocols intelligently avoid loops in a network by creating a tree topology
(spanning tree) of the entire bridged network with only one available path between the
tree root and a leaf. All other paths are forced into a standby state. The tree root is a
switch within the network elected by the STA (spanning-tree algorithm) to use when
computing the best path between bridges throughout the network and the root bridge.
Frames travel through the network to their destination–a leaf. A tree branch is a network
segment, or link, between bridges. Switches that forward frames through an STP
spanning-tree are called designated bridges.
Juniper Networks EX Series and QFX Series switches provide Layer 2 loop prevention
through Spanning Tree Protocol (STP), Rapid Spanning Tree Protocol (RSTP), Multiple
Spanning Tree Protocol (MSTP), and VLAN Spanning Tree Protocol (VSTP). This topic
explains MSTP.
NOTE: If you are using Junos OS for EX Series and QFX Series switches with
support for the Enhanced Layer 2 Software (ELS) configuration style, you
can force the original IEEE 802.1D Spanning Tree Protocol (STP) version to
run in place of RSTP or VSTP by setting force-version.
This topic describes:
MSTP Maps Multiple VLANs on page 78
Configuring MSTP Regions on page 79
Selecting a Spanning Tree Protocol on page 79
MSTP is an extension of RSTP that maps multiple independent spanning-tree instances
onto one physical topology. Each spanning-tree instance (STI) includes one or more
VLANs. Unlike in STP and RSTP configurations, a port might belong to multiple VLANs
and be dynamically blocked in one spanning-tree instance, but forwarding in another.
This behavior significantly improves network resource utilization by load-balancing across
the network and maintaining switch CPU loads at moderate levels. MSTP also leverages
the fast reconvergence time of RSTP when a network, switch, or port failure occurs within
a spanning-tree instance.
MSTP creates a common and internal spanning tree (CIST) to interconnect and manage
all MSTP regions and even individual devices that run RSTP or STP, which are recognized
as distinct spanning-tree regions by MSTP. The CIST views each MSTP region as a virtual
bridge, regardless of the actual number of devices participating in the MSTP region, and
enables multiple spanning-tree instances (MSTIs) to link to other regions. The CIST is a
