Juniper EX9200 Features Manual page 115

Meaning
Purpose
Action
Copyright © 2017, Juniper Networks, Inc.
Local parameters
Bridge ID
Extended system ID
Internal instance ID
STP bridge parameters for MSTI 1
MSTI regional root
Root cost
Root port
Hello time
Maximum age
Forward delay
Hop count
Local parameters
Bridge ID
Extended system ID
Internal instance ID
STP bridge parameters for MSTI 2
MSTI regional root
Hello time
Maximum age
Forward delay
Local parameters
Bridge ID
Extended system ID
Internal instance ID
The operational mode command
domain information such as the designated port and the port roles. The spanning-tree
interface parameters for instance 2 show that both ports are designated ports, which
means Switch 2 is the root bridge for this instance.
The operational mode command
domain information at either the bridge level or interface level. If the optional interface
name is omitted, all interfaces in the spanning-tree domain are displayed.
Verifying MSTP Configuration on Switch 3
Verify the MSTP configuration on Switch 3.
Issue the operational mode commands show spanning-tree interface and show
spanning-tree bridge:
user@switch3> show spanning-tree interface
Spanning tree interface parameters for instance 0
Interface Port ID
ge-0/0/26 128:513
ge-0/0/28 128:515
ge-0/0/24 128:517
Spanning tree interface parameters for instance 1
: 32768.00:19:e2:50:3d:20
: 0
: 0
: 4096.00:19:e2:50:51:e0
: 1000
: ge-0/0/18
: 2 seconds
: 20 seconds
: 15 seconds
: 19
: 32768.00:19:e2:50:3d:20
: 0
: 1
: 4096.00:19:e2:50:3d:20
: 2 seconds
: 20 seconds
: 15 seconds
: 4096.00:19:e2:50:3d:20
: 0
: 2
show spanning-tree interface
show spanning-tree bridge
Designated Designated
port ID bridge ID
128:513 8192.0019e25051e0
128:515 8192.0019e25051e0
128:517 8192.0019e25051e0
Chapter 4: Using MSTP
displays spanning-tree
displays the spanning-tree
Port State Role
Cost
1000 FWD DESG
1000 FWD DESG
1000 FWD DESG
99
