Spanning-Tree Protocols Feature Guide for EX9200 Switches

RSTP or VSTP Forced to Run as IEEE 802.1D STP

Related
Documentation

Forcing RSTP or VSTP to Run as IEEE 802.1D STP (CLI Procedure)

162
Configuring Multiple Spanning Tree Protocol
Configuring VLAN Spanning Tree Protocol
edge on page 39
interface (Spanning Tree)
Configuring RSTP (CLI Procedure) on page 33
Configuring VLAN Spanning Tree Protocol on page 168
Configuring MSTP on page 108
On MX Series routers and EX Series and QFX Series switches in a Layer 2 environment,
you can force the configured Rapid Spanning Tree Protocol (RSTP) or VLAN Spanning
Tree Protocol (VSTP) to run as the original IEEE 802.1D Spanning Tree Protocol (STP)
version. Configure original IEEE_802.1D STP for compatibility with older bridges that do
not support RSTP or VSTP.
Keep the following limitations in mind when RSTP or VSTP are forced to run as the original
STP version:
If you configure an instance interface as an edge port, the configuration statement is
ignored.
If you configure point-to-point link mode for an instance interface, the configuration
statement is ignored.
Configuring RSTP (CLI Procedure) on page 33
Configuring VLAN Spanning Tree Protocol on page 168
Reverting to RSTP or VSTP from Forced IEEE 802.1D STP on page 34
force-version on page 40
NOTE: This procedure uses Junos OS for EX Series switches with support for
the Enhanced Layer 2 Software (ELS) configuration style. For ELS details,
see Getting Started with Enhanced Layer 2 Software.
On EX Series switches running Rapid Spanning Tree Protocol (RSTP) (the default) or
VLAN Spanning Tree Protocol (VSTP), you can force the original IEEE 802.1D Spanning
Tree Protocol (STP) version to run in place of RSTP or VSTP. Configure the force-version
stp statement for compatibility with older bridges that do not support RSTP or VSTP.
