Media Speci cations
Core inside diameter, standard:
Core inside diameter, with adapter:
Maximum roll outside diameter:
Media width, label with liner/receipt:
M e i d l a n e g h t l , b a : l e
M e i d l a n e t g , h e r e c p i : t
Media caliper, label with liner/receipt:
Media caliper, tag (maximum):
Gap length (centered on perforation):
Notch length (centered on perforation):
Notch width (centered on perforation):
Black mark length (centered on perforation):
Black mark width (centered on media width):
Receipt roll stock media is supplied as a continuou s roll. Label, tag,
and fanfold media use repeat indicators for non-con tinuous media.
Gap, notch, and black marks are used as repeat indi cators:
Here are a few things to keep in mind when ordering media for the
PB51 printer:
PB51 Mobile Label and Recept Printer User's Guide
Gap: Label and fanfold media
Notch: Tag media
Black mark: Label, tag, and fanfold media
Black marks can only be sensed on the back side of the media.
You can use higher caliper media in the printer, bu t print quality
will be reduced.
Receipt roll stock media has an end of roll indicat or. The end of
roll indicator is a red marking (on last 3 feet of roll) on the
thermally sensitive side of the paper.
Chapter A — Speci cations
19 mm (0.75in)
10.2 mm (0.4 in)
67.3 mm (2.65 in)
49mm (1.9 in) to 111.5 mm (4.4 in)
5 2 4 . m m . 1 ( i 0 ) n o t 6 9 0
C o t n n i u o s u
0.05 mm (0. 002 in) to 0.165 mm (0.0065 in)
0.15 mm (0.006 in)
3.17 mm (0.125 in) to 12.7 mm (0.50 in)
6.35 mm (0.2 5 in)
12.7 mm (0.50 in)
3.17 mm (0.125 in) to 12.7 mm (0.50 in)
Full wid th of media
6 . m m 2 ( i 4 ) n
