CompactFlash Memory Card Product Manual
4.3

Electrical Specification

The following table
Characteristics for the CompactFlash Memory
Card Series.
Unless otherwise stated, conditions are:
SDCFB-XX
Vcc = 5V ±10%
Vcc = 3.3V ± 5%
Ta = 0°C to 60°C
4.3.1

Input Leakage Current

Note: In the table below, x refers to the characteristics described in section 4.3.2. For example, I1U indicates a
pull up resistor with a type 1 input characteristic.
Type Parameter
IxZ Input Leakage Current
IxU Pull Up Resistor
IxD Pull Down Resistor
Note: The minimum pullup resistor leakage current meets the PCMCIA specification of 10k ohms but is
intentionally higher in the CompactFlash Memory Card Series product to reduce power use.
4.3.2

Input Characteristics

Type Parameter
1 Input Voltage
CMOS
2 Input Voltage
CMOS
3 Input Voltage
CMOS
Schmitt Trigger
28
defines all D.C.
SDCFBI-XX
Vcc = 5V ± 5%
Vcc = 3.3V ± 5%
Ta = -40°C to 85°C
Symbol
IL
RPU1
RPD1
Symbol
Vih
Vil
Vih
Vil
Vth
Vtl
SanDisk CompactFlash Memory Card Product Manual © 1998 SANDISK CORPORATION
Absolute Maximum conditions are:
Vcc = -0.3V min. to 7.0V max.
V* = -0.5V min. to Vcc + 0.5V max.
* Voltage on any pin except Vcc with respect
to GND.
Conditions
Vih = Vcc / Vil = Gnd
Vcc = 5.0V
Vcc = 5.0V
MIN TYP MAX
VCC = 3.3 V
2.4
0.6
1.5
0.6
1.8
1.0
MIN TYP MAX
-1 1
50k 500k
50k 500k
MIN TYP MAX
VCC = 5.0 V
2.4
0.8
2.0
0.8
2.8
2.0
Units
µA
Ohm
Ohm
Units
Volts
Volts
Volts
