C. Technical Specifications
C-2
Table C-1. BitStorm 2600 Technical Specifications (2 of 2)
Specifications Criteria
Interfaces DSL PORTS: 50-pin RJ21X Telco-type connector
POTS: 50-pin RJ21X Telco-type connector
CONSOLE: DB9 (EIA-232-E)
Port 1 and Port 2: 8-pin modular jack (10/100BaseT)
Port 3 copper interface: 8-pin modular jack (1000BaseT)
Port 3 fiber interface: SFP socket
T1/E1 MLPPP interface: eight RJ48C modular jacks
Operating Ambient Temperature: 0° to 50° C (32° to 122° F)
Environment Relative Humidity: 5% to 95% noncondensing
Storage Temperature: –40° to 85° C (–40° to 185° F)
Shock and vibration tolerance sufficient to withstand normal shipping
Physical Height: 1.75" (44.5 mm, or 1U as defined in EIA-310-C) without feet
Dimensions Width: 17.2" (437 mm) without mounting brackets
Depth: 16.0" (406 mm) with cables
Power 90–265 VAC, 47–63 Hz
Power Model 2611: 45 Watts Maximum
Consumption
Model 2614: 43 Watts maximum
Model 2621: 57 Watts Maximum
Model 2624: 55 Watts Maximum
Model 2631: 57 Watts Maximum
Model 2671: 46 Watts Maximum
Model 2674: 44 Watts Maximum
Weight 2611 without splitters: 15.1 lb (6.8 kg)
2611 with splitters: 17.0 lb (7.7 kg)
2614: 13.1 lb (5.9 kg)
2621 without splitters: 14.7 lb (6.7 kg)
2621 with splitters: 16.3 lb (7.4 kg)
2624: 12.2 lb (5.5 kg)
2631 without splitters: 14.7 lb (6.7 kg)
2631 with splitters: 16.3 lb (7.4 kg)
2671: 15.5 lb (7.0 kg)
2674: 13.1 lb (5.9 kg)
March 2005 2600-A2-GN20-40
