LEDs

LED Locations

2600-A2-GN20-40
The locations of the System and DSL Port LEDs on the front panel of the
BitStorm 2600 are shown in
Link LEDs Activity LEDS
Figure 3-1. Front Panel LEDs (GigE Uplink)
Figure 3-2. Front Panel LEDs (T1/E1 Uplink)
March 2005
Figure 3-1, Front Panel LEDs (GigE
260 0
3
Uplink).
DSL Ports LEDs
03-17454
3-1
