Connectors and Pin Assignments
Overview
2600-A2-GN20-40
The following sections provide pin assignments for:
DSL Ports and POTS Splitter Connectors
Port 1 and Port 2 10/100BaseT Connectors
Port 3 1000BaseT Connector
Port 3 GigE SFP Connector
E1 and T1 Uplink Connectors
Console Port Connector
ALARM Connector
on page A-6
Figure A-1.
BitStorm 2600 IP Front Panel
March 2005
on page A-2
on page A-3
on page A-3
on page A-4
on page A-5
on page A-5
DSL PORTS 1-24
A
POTS 1-24
2600
03-17455
A-1
