System Menu Operation Flow

6-1

System Menu Operation Flow

Create the Screen Data
Start Up the NT31/NT31C
(Display the System
Menu) (page 134)
Initialize the Memory
(page 140)
Transmit the Screen Data
(page 155)
Set the Memory Switches
(pages 157, 168, 188)
Start Operation (page
168)
System Maintenance
(page 191)
Follow the procedure below when using the NT31/NT31C for the first time or
changing the system program.
Create the data to be displayed on the NT31/NT31C by using the Support Tool.
For details on creating screen data, refer to the NT-series Support Tool Ver. 4.1
for Windows Operation Manual (V061-E1-j).
Turn ON the power to the NT31/NT31C.
If no screen data has been registered, an error message is displayed. In this
case, press the OK touch switch on the error message screen to display the Sys-
tem Menu.
If screen data has been registered and the RUN mode is established, perform
the appropriate operations on the touch panel to display the System Menu.
If necessary, initialize the memory of the NT31/NT31C by operation from the
System Menu.
Connect the Support Tool to the NT31/NT31C and transmit the screen data from
the Support Tool to the NT31/NT31C.
For details on connecting the Support Tool, refer to 3-2 Connecting to the Sup-
port Tool (page 35).
Select the System Menu and set the operations of the NT31/NT31C — for exam-
ple the conditions for communication with the host — using the memory
switches.
Connect the NT31/NT31C to the host and start operation.
If an error occurs during operation, check the I/Os, settings, etc., by referring to
this guide.
