Nortel Passport Module 8672A Using Manual

Nortel networks passport module user guide
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Using the Passport 8672ATM
Module
Part No. 209195-A
March 2001
4401 Great America Parkway
Santa Clara, CA 95054

Advertisement

Table of Contents
loading

Related Manuals for Nortel Passport Module 8672A

Summary of Contents for Nortel Passport Module 8672A

  • Page 1 Using the Passport 8672ATM Module Part No. 209195-A March 2001 4401 Great America Parkway Santa Clara, CA 95054...

  • Page 2: Statement Of Conditions

    Nortel Networks NA Inc. does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein.
  • Page 3 LICENSE AGREEMENT. THE TERMS EXPRESSED IN THIS AGREEMENT ARE THE ONLY TERMS UNDER WHICH NORTEL NETWORKS WILL PERMIT YOU TO USE THE SOFTWARE. If you do not accept these terms and conditions, return the product, unused and in the original shipping container, within 30 days of purchase to obtain a credit for the full purchase price.
  • Page 4 Software is provided will be free from defects in materials and workmanship under normal use for a period of 90 days from the date Software is first shipped to Licensee. Nortel Networks will replace defective media at no charge if it is returned to Nortel Networks during the warranty period along with proof of the date of shipment.
  • Page 5 7. Term and termination. This license is effective until terminated; however, all of the restrictions with respect to Nortel Networks’ copyright in the Software and user manuals will cease being effective at the date of expiration of the Nortel Networks copyright; those restrictions relating to use and disclosure of Nortel Networks’ confidential information shall continue in effect.
  • Page 6 209195-A...

  • Page 7: Table Of Contents

    Contents Preface ............17 Before you begin .
  • Page 8 Contents Chapter 3 Installing the Passport 8672ATM Module ......35 Safety and environmental precautions ........35 Installing the Passport 8672ATM Module .
  • Page 9 1483 ELAN statistics ..........75 config atmcard elan-stats .
  • Page 10 Contents Basic configuration procedures ......... 118 Bridging point-to-point traffic using an ATM 1483 PVC using Device Manager .
  • Page 11 Figures Figure 1 Passport 8672ATM module ........26 Figure 2 1-port OC-12c/STM-4 MDA .
  • Page 12 Figures Figure 28 show ports info atm all command output ......83 Figure 29 show ports info atm ports command output ..... . . 85 Figure 30 show ports info atm pvc command output .
  • Page 13 Figure 61 IPX routing with ATM 1483 PVCs ......136 Figure 62 IPX VLAN dialog box .
  • Page 14 Figures 209195-A...
  • Page 15 Tables Table 1 Passport 8672ATM Module online LED indications Table 2 MDA LED indications Table 3 Device Manager port color codes ......50 Table 4 Device Manager buttons .
  • Page 16 Tables Table 30 Information fields for the show ports stats atm linecurrent command Table 31 Information fields for The show ports stats atm lineinterval command . . 99 Table 32 Information fields for the show ports stats atm pathcurrent command . 100 Table 33 Information fields for the show ports stats atm pathinterval command 101 Table 34...

  • Page 17: Preface

    • Understanding of the transmission and management protocols used on your network • Experience with windowing systems or graphical user interfaces (GUIs) ® 8672ATM Module is part of the Nortel Networks Passport 8600 Using the Passport 8672ATM Module...

  • Page 18: Text Conventions

    Preface Text conventions This guide uses the following text conventions: angle brackets (< >) bold Courier text braces ({}) brackets ([ ]) ellipsis points (. . . ) 209195-A Indicate that you choose the text to enter based on the description inside the brackets.
  • Page 19 italic text Indicates new terms, book titles, and variables in command syntax descriptions. Where a variable is two or more words, the words are connected by an underscore. Example: If the command syntax is show at <valid_route>, valid_route variable and you substitute one value for it. Indicates command syntax and system output, for plain Courier text...

  • Page 20: Related Publications

    Getting Started with the Passport 8000 Series Management Software (part number 209663-C) Outlines the procedures for installing and booting your Passport 8600 Series 8000 series switch, as well as instructions for installing the Passport 8672ATM Module. • Reference for the Passport 8000 Series Management Software Switching Operations Release 3.1 (part number 207414-D)
  • Page 21 Reference for the Passport 8000 Series Command Line Interface Switching Operations Release 3.1 (part number 207308-D) Describes how to use the CLI to configure and manage switching functions with the Passport 8000 Series switch, including procedures and illustrations of pertinent commands. •...

  • Page 22: How To Get Help

    Preface How to get help If you purchased a service contract for your Nortel Networks product from a distributor or authorized reseller, contact the technical support staff for that distributor or reseller for assistance. If you purchased a Nortel Networks service program, contact one of the following...

  • Page 23: About The Passport 8672Atm Module

    ATM network. The module also provides existing ATM customers with the capability for connectivity to the Passport 8600 Routing Switch. (For more information on ATM, refer to the ATM Forum Web site at the http://www.atmforum.com URL.) The Passport 8672ATM Module occupies a single slot in a Passport 8600 series chassis.

  • Page 24: Features

    Chapter 1 About the Passport 8672ATM Module Refer to Networking Concepts for the Passport 8000 Series Switch for a thorough discussion of the complete functionality of the Passport 8000 series product line, including the Passport 8672ATM Module. Note that Spanning Tree Groups (STGs), VRRP, DiffServ, and ATM QoS are not supported on this module.

  • Page 25: Atm Elans, And Ethernet Vlans

    ATM ELANs, and Ethernet VLANs The Passport 8672ATM Module supports ATM Forum Emulated LANs (ELANs). An ELAN extends an Ethernet VLAN, which is a broadcast domain, over an ATM network. In general, there is a one-to-one mapping between an ATM ELAN and an Ethernet VLAN.

  • Page 26: Rfc 1483 Support

    RFC 1483 bridged 802.3. The links can be set up within a single device or with another switch. Multiple RFC 1483 links can be set up within one ELAN. In all cases, the PVCs must be set up without loops; STP must be disabled.

  • Page 27: Media Dependent Adapters

    To configure and manage the Passport 8672ATM Module, connect to the Passport 8690SF Module. For information on connecting to the Passport 8690SF console port, refer to Using the Passport 8600 Modules. Media dependent adapters The Passport 8672ATM Module has space for two media dependent adapters MDAs) that have their own LEDs.

  • Page 28: Online Led

    Chapter 1 About the Passport 8672ATM Module Figure 4 shows the Passport 8672ATM Module with one OC-12c/STM-4 MDA installed. For information on installing the MDAs, refer to Installing the Passport 8672ATM Module MDAs. Figure 4 Passport 8672 ATM module with OC-12c/STM-4 MDA Online LED The front panel of the Passport 8672ATM Module has an Online LED that indicates whether or not the module has power applied and is initialized correctly.

  • Page 29: Mda Leds

    Console port on the Passport 8690 SF module, refer to Getting Started with the Passport 8000 Series Management Software. The Diag port on the Passport 8672ATM Module is used only by Nortel Networks personnel for debugging purposes. You can see diagnostic messages but you cannot input any text.
  • Page 30 Chapter 1 About the Passport 8672ATM Module 209195-A...

  • Page 31: Passport 8672Atm Module Technology Overview

    ATM uses dedicated media connections running in parallel, allowing simultaneous multiple connections through a single switch device at very high speeds. •...
  • Page 32 Chapter 2 Passport 8672ATM Module technology overview • VC: Virtual circuit. This is a network service that provides connection-oriented service regardless of the underlying network structure. • VP: Virtual path. A virtual path is a set of virtual channels between a common source and destination.

  • Page 33: Sonet Terms And Acronyms

    SONET terms and acronyms This section provides a brief listing of common Synchronous Optical Network (SONET) terms. SONET is a medium for transmitting data that uses fiber optic cables. The following terms and acronyms are frequently used with SONET information: •...

  • Page 34: Sonet Transmission Rates

    Chapter 2 Passport 8672ATM Module technology overview SONET transmission rates The following transmission rates are commonly used with SONET: • OC-3c/STM-1: 155.52 Mb/s (and SDH/STM-1) • OC-12c/STM-4: 622.08 Mb/s (and SDH/STM-4) The SONET specification defines optical both as: • Single-mode fiber (SMF) •...

  • Page 35: Installing The Passport 8672Atm Module

    • To prevent damage caused by electrostatic discharge (ESD), handle the switch chassis and modules only when you, the chassis, and the chassis modules are properly grounded. Nortel Networks recommends the use of a grounding wrist strap. precautions,” next Using the Passport 8672ATM Module...
  • Page 36 Chapter 3 Installing the Passport 8672ATM Module • When handling modules, do not touch components on the modules; always handle modules by their edges. Store unused modules in their protective packaging. Warning: Fiber optic equipment can emit laser or infrared light that can injure your eyes.

  • Page 37: Installing The Passport 8672Atm Module

    Installing the Passport 8672ATM Module To install the Passport 8672ATM Module: Remove the filler panel from the module slot in the Passport 8600 series chassis (Figure Figure 5 Removing the filler panel Make sure the inserter/extractor levers are extended away from the Passport 8672ATM Module front panel Figure 6 Extending the inserter/extractor levers Chapter 3 Installing the Passport 8672ATM Module...

  • Page 38: Figure 7 Inserting The Passport 8672Atm Module

    Chapter 3 Installing the Passport 8672ATM Module Note: Always handle an I/O module by the sides and carefully slide it out of the chassis. Place the module on a grounded work surface and in an antistatic bag for storage. Handling the Passport 8672ATM Module by the sides only, carefully align it with the card guides in the chassis.

  • Page 39: Figure 8 Closing The Inserter/Extractor Levers

    Chapter 3 Installing the Passport 8672ATM Module Figure 8 Closing the inserter/extractor levers 10037FA Tighten the retaining screws (Figure Figure 9 Tightening the retainer screws 10038FA You must install at least one MDA on the Passport 8672ATM Module in order to pass traffic.

  • Page 40: Verifying Installation

    Chapter 3 Installing the Passport 8672ATM Module For information on configuring and managing the Passport 8672ATM Module, refer to Chapter 4, “Managing the Passport 8672ATM Module with Device Manager,” on page with the CLI,” on page Module,” on page Verifying installation The Passport 8672ATM Module front panel has an Online LED that indicates whether or not the module has power applied and is initialized correctly.
  • Page 41 Chapter 3 Installing the Passport 8672ATM Module ERROR Task=rcStart Couldn’t find an ATM download image! Aborting card initialization in Slot=4 ERROR Task=rcStart portPresent:port=X/X, invalid port Type The Passport 8672ATM Module requests a redownload from the Passport 8690SF module, and the screen displays the following message: Redownload requested by ATM card in slot <number>.

  • Page 42: Figure 10 Unsuccessful Download Screen Output

    2744752 to 12936388 (12936388) Starting at 0x10000... CENTENNIAL Passport 8600 System Software Release REL3.1.0.0_B022 Copyright (c) 1996-2000 Nortel Networks, Inc. Waiting for cpu in slot 5 ... 2 seconds [08/09/00 14:03:13] System boot /pcmcia/ [08/09/00 14:03:13] Passport System Software Release REL3.1.0.0_B022...

  • Page 43: Mda Insertion And Configuration

    After the image loads onto the Passport 8672ATM Module, it performs a series of self-diagnostic tests. If the module fails the diagnostics, the screen displays the following message: Fatal bring up error on ATM card in slot <number>. If you see this message, contact a service representative. For information on contacting service representatives, refer to When the image successfully loads onto the Passport 8672ATM Module, the screen displays the following message:...

  • Page 44: Replacing A Module

    For information on enabling ports, refer to page You configure and manage the Passport 8600 series switch operation for your network using the command line interface (CLI) or SNMP-based network management software, such as Device Manager. For information on configuring and managing the Passport 8672ATM Module, refer to Passport 8672ATM Module with Device Manager,”...

  • Page 45: Starting The System After A Module Replacement

    • When you save the configuration in nonvolatile random access memory (NVRAM), turn off the switch, replace a module with a different module type, and turn the system on again, the system discards the configuration of the old ports, and adds new ports to either the default VLAN or an unassigned VLAN, depending on the operating mode of the switch.
  • Page 46 Chapter 3 Installing the Passport 8672ATM Module 209195-A...

  • Page 47: Managing The Passport 8672Atm Module With Device Manager

    Chapter 4 Managing the Passport 8672ATM Module with Device Manager Two management tools enable you to manage your Passport 8672ATM Module: Device Manager and the command line interface (CLI). You can also use the embedded Web-based management feature to monitor the 8672ATM Module. This chapter contains information on these topics: •...

  • Page 48: Device Manager

    Chapter 4 Managing the Passport 8672ATM Module with Device Manager The management systems identify an interface by its slot number (in the Passport 8600 series chassis) and its port number, using the syntax slot number/port number (s/p). The Passport 8672ATM Module can contain up to eight ports when two 4-port MDAs are inserted.

  • Page 49: Device Manager Access And Passwords

    Chapter 4 Managing the Passport 8672ATM Module with Device Manager • Getting Started with the Passport 8000 Series Management Software • Reference for the Passport 8000 Series Management Software Routing Operations • Reference for the Passport 8000 Series Management Software Switching Operations The following sections describe the Device Manager features that are specific to the Passport 8672ATM Module:...

  • Page 50: Figure 11 Passport 8000 Series Chassis With Passport 8672Atm Module

    Chapter 4 Managing the Passport 8672ATM Module with Device Manager Figure 11 Passport 8000 series chassis with Passport 8672ATM Module The ports on the graphical image are color-coded to provide at-a-glance port status. Table 3 Table 3 Device Manager port color codes Field Green Orange...

  • Page 51: Configuring Atm Using Device Manager

    Applies the changes you entered to fields in a window or dialog box. Refresh Refreshes the information in the window. Each time you click Refresh, new information is polled form the switch and displays. Close Closes the window or dialog box and disregards any changes you made to fields.

  • Page 52: Figure 12 Interface Tab

    Chapter 4 Managing the Passport 8672ATM Module with Device Manager Figure 12 Interface tab Table 5 describes the items in the Interface tab. 209195-A...

  • Page 53: Table 5 Interface Tab Items

    Chapter 4 Managing the Passport 8672ATM Module with Device Manager Table 5 Interface tab items Item Description Index Unique value assigned to each interface. The value ranges between 16 and 255. Name Displays the name of this port. To assign or change a name to the port, highlight the field and enter alphanumeric characters.

  • Page 54: Resetting The Module

    Chapter 4 Managing the Passport 8672ATM Module with Device Manager Table 5 Interface tab items (continued) Item Action Result From the Interface tab, select other ATM-specific tabs to configure the port or change current or default configurations. Resetting the module To reset the module: Highlight the module.

  • Page 55: Figure 13 Card Tab

    Chapter 4 Managing the Passport 8672ATM Module with Device Manager Figure 13 Card tab Table 6 describes the fields in the Card tab. Using the Passport 8672ATM Module...

  • Page 56: Table 6 Card Tab Fields

    Chapter 4 Managing the Passport 8672ATM Module with Device Manager Table 6 Card tab fields Field FrontType FrontDescription FrontAdminStatus FrontOperStatus FrontSerialNum FrontHWVersion FrontPartNumer FrontDateCode FrontDeviations BackType BackDescription BackSerialNum BackHWVersion BackPartNumer BackDateCode BackDeviations Click the ATM tab. The ATM tab opens 209195-A Description Card type.

  • Page 57: Viewing Mda Information

    Chapter 4 Managing the Passport 8672ATM Module with Device Manager Figure 14 ATM tab Table 7 describes the fields in the ATM tab. Table 7 ATM tab fields Field Description Action: reset Resets the card. ImageFileName Name of the image file which downloads at initialization. Click reset.

  • Page 58: Enabling Or Disabling A Port

    Chapter 4 Managing the Passport 8672ATM Module with Device Manager The MDA dialog box opens Figure 15 MDA dialog box Table 8 describes the fields in the MDA dialog box. Table 8 MDA dialog box fields Field Type Description Enabling or disabling a port You can enable or disable a port by two methods.

  • Page 59: Editing Port Parameters

    Chapter 4 Managing the Passport 8672ATM Module with Device Manager Click Apply. To enable or disable a port using a shortcut menu: Right-click on the port. A shortcut menu opens. Choose Enable or Disable. Editing port parameters To view or change the general parameters of the port: On the device view, highlight a port.

  • Page 60: Figure 16 Atm Tab

    Chapter 4 Managing the Passport 8672ATM Module with Device Manager Figure 16 ATM tab Table 9 describes the items in the ATM tab. Table 9 ATM tab items Item ifIndex MediaType LineSpeed NumVpiBits NumVciBits 209195-A Description Interface Index. mmf (multimode fiber) or smf (single-mode fiber) For OC-3c, the operating speed is 155.52 Mb/s;...

  • Page 61: Editing Circuit Parameters

    Chapter 4 Managing the Passport 8672ATM Module with Device Manager Table 9 ATM tab items (continued) Item Description ScrambleEnable Sets the port to scramble the data by clicking the box. FramingMode Sets the framing for the port to: • sonet, which means the Synchronous Optical Network format, the standard format in North America.

  • Page 62: Figure 17 Atm Pvc Tab

    Chapter 4 Managing the Passport 8672ATM Module with Device Manager Figure 17 ATM PVC tab Table 10 Table 10 ATM PVC tab fields Item PvcId Name Encapsulation ServiceType PeakCellRate SustainedCellRate MaxBurstSize Click Insert. The Insert ATM PVC dialog box opens 209195-A describes the fields in the ATM PVC tab.

  • Page 63: Figure 18 Insert Atm Pvc Dialog Box

    Chapter 4 Managing the Passport 8672ATM Module with Device Manager Figure 18 Insert ATM PVC dialog box Table 11 describes the fields in the Insert ATM PVC dialog box. Table 11 Insert ATM PVC dialog box fields Item Description Numeric value, within the range 0...255. Numeric value, within the range 0...65535 Note: For <vpi.vci>, 0.0 is not supported.

  • Page 64: Deleting A Pvc

    Chapter 4 Managing the Passport 8672ATM Module with Device Manager In the Vci field, type the VCI-bit size (an integer between 0 and 65, 535). Note: For <vpi.vci>, 0.0 is not supported. In the Name field, type the name of the ATM PVC. In the Encapsulation field, select the encapsulation method (null or IIcSnap).

  • Page 65: Configuring Atm 1483 Elan Parameters

    Chapter 4 Managing the Passport 8672ATM Module with Device Manager Figure 19 ATM PVC tab with PVC selected Click Delete. The PVC is deleted. Configuring ATM 1483 ELAN parameters To view and configure ATM 1483 ELAN parameters for the port: On the device view, highlight a port.

  • Page 66: Figure 20 Atm 1483 Elan Tab (Left Section)

    Chapter 4 Managing the Passport 8672ATM Module with Device Manager Figure 20 ATM 1483 ELAN tab (left section) Figure 21 ATM 1483 ELAN tab (right section) Table 12 describes the fields in the ATM 1483 ELA Table 12 ATM 1483 ELAN tab fields Field VlanId ElanId...

  • Page 67: Figure 22 Insert Atm 1483 Elan Dialog Box

    Chapter 4 Managing the Passport 8672ATM Module with Device Manager Table 12 ATM 1483 ELAN tab fields (continued) Field Description DummyMacAddress Dummy MAC address assigned to this VLAN: used in IP and IPX routed circuits when there is no appropriate source MAC to use.

  • Page 68: Table 13 Insert Atm 1483 Elan Dialog Box Items

    Chapter 4 Managing the Passport 8672ATM Module with Device Manager Table 13 describes the items in the Insert ATM 1483 ELAN dialog box. Table 13 Insert ATM 1483 ELAN dialog box items Item VlanId PvcIds ConnectType LocalIpAddress RemoteIpAddress InArpSendEnable InArpSendInterval IpxVlanEncapMethod IPX encapsulation protocol: llc, snap, ether-ii, or raw.

  • Page 69: Figure 23 Insert Atm 1483 Elan Dialog Box For Ip Routing

    Chapter 4 Managing the Passport 8672ATM Module with Device Manager Figure 23 shows the relevant fields for IP routing. Figure 23 Insert ATM 1483 ELAN dialog box for IP routing 10 If Ipx is selected in the ConnectType field, complete the following fields: In the IpxVlanEncapMethod, select the encapsulation method (llc, snap, ether-ii, or raw).

  • Page 70: Deleting An Atm 1483 Elan

    Chapter 4 Managing the Passport 8672ATM Module with Device Manager Figure 24 Insert ATM 1483 ELAN dialog box for IPX routing Deleting an ATM 1483 ELAN To delete an ATM 1483 ELAN: On the device view, highlight a port. Choose Edit > Port. The Port dialog box opens with the Interface tab displayed page 52).

  • Page 71: Displaying Statistics Using Device Manager

    Chapter 4 Managing the Passport 8672ATM Module with Device Manager Figure 25 ATM 1483 ELAN tab with ElanId selected Click Delete. The ATM 1483 ELAN is deleted. Displaying statistics using Device Manager Statistics are not supported in Device Manager in this release. See the stats atmport command”...
  • Page 72 Chapter 4 Managing the Passport 8672ATM Module with Device Manager 209195-A...

  • Page 73: Managing The Passport 8672Atm Module With The Cli

    Chapter 5 Managing the Passport 8672ATM Module with the You can manage your Passport 8672ATM Module through the command line interface (CLI). You can also use the embedded Web-based management feature to monitor the 8672ATM Module. This chapter contains information on these topics: •...

  • Page 74: Configuration Commands

    Chapter 5 Managing the Passport 8672ATM Module with the CLI This section contains the following information: • “Configuration • “Show commands” on page 82 Configuration commands This section describes the CLI configuration commands available with the Passport 8672ATM Module. There are three types of configuration commands: •...

  • Page 75: 1483 Elan Statistics

    Chapter 5 Managing the Passport 8672ATM Module with the CLI Table 14 config atmcard command parameters and variables Parameters and variables card-reset elan-stats <enable|disable> info 1483 ELAN statistics The 1483 ELAN statistics commands allow you to collect ELAN statistics for an ATM port.

  • Page 76: Show Atm Elan-Stats

    Chapter 5 Managing the Passport 8672ATM Module with the CLI show atm elan-stats <vlan id> Use this command to display the ELAN statistics for a particular VLAN ID. If the collection of ELAN statistics is disabled, a message is printed before the ELAN statistics.

  • Page 77: Clear Atm Elan-Stats

    Chapter 5 Managing the Passport 8672ATM Module with the CLI Table 15 Information fields for the show atm elan-stats command (continued) Field InDiscards OutDiscards InUcastPkts OutUcastPkts InMcastPkts OutMcastPkts InBcastPkts OutBcastPkts clear atm elan-stats Use this command to clear the ELAN statistics for a particular VLAN ID. The syntax is: clear atm elan-stats <vlan_id>...

  • Page 78: Config Atm Command

    Chapter 5 Managing the Passport 8672ATM Module with the CLI config atm command Table 16 describes the parameters and variables for the config atm < ports > command. Table 16 config atm command parameters and variables Parameters and variables action <action choice> number-vpi-bits <number-vpi-bits>...

  • Page 79: Config Atm Pvc Command

    Chapter 5 Managing the Passport 8672ATM Module with the CLI Table 16 config atm command parameters and variables (continued) Parameters and variables info perform-tagging <enable | disable> config atm pvc command Table 17 describes the parameters and variables for the config atm pvc command.

  • Page 80: Config Atm Pvc 1483 Command

    Chapter 5 Managing the Passport 8672ATM Module with the CLI config atm pvc 1483 command Use the config atm pvc 1483 commands to configure 1483 parameters on the Passport 8672ATM Module. The syntax is: • config atm <ports> pvc 1483 bridged •...

  • Page 81: Config Atm Info Command

    Chapter 5 Managing the Passport 8672ATM Module with the CLI Table 19 config atm pvc 1483 ip command parameters and variables Parameters and variables create <vid> <vpi.vci> <remoteip> Creates a routed 1483 IP circuit on the specified VLAN to the delete <vid>...

  • Page 82: Show Commands

    Chapter 5 Managing the Passport 8672ATM Module with the CLI Figure 27 Sample output for the config atm info command number-vpi-bits : 4 Show commands This section discusses the CLI show commands available with the Passport 8672ATM Module. These commands allow you to view information about the module: show ports info atm all [<ports>] show ports info atm ports [<ports>]...

  • Page 83: Figure 28 Show Ports Info Atm All Command Output

    Chapter 5 Managing the Passport 8672ATM Module with the CLI show ports info atm all Figure 28 Passport-8610:5/show/ports/info/atm# all ======================================================= ====================================================== PORT SCRAMBLE FRAMING MAX-BITS CLOCK DESCRIPION ENABLE --------------------------------------------------------------------- OC-12c MM enable Quad OC-3c MM enable Quad OC-3c MM enable Quad OC-3c MM enable ===================================================================== =====================================================================...

  • Page 84: Table 21 Information Fields For The Show Ports Info Atm All Command

    Chapter 5 Managing the Passport 8672ATM Module with the CLI Table 21 describes the information fields for the show ports info atm all command. Table 21 Information fields for the show ports info atm all command Field PORT NUM MDA DESCRIPTION SCRAMBLE ENABLE FRAMING MODE MAX-BITS VPI...

  • Page 85: Show Ports Info Atm Ports Command

    Chapter 5 Managing the Passport 8672ATM Module with the CLI Table 21 Information fields for the show ports info atm all command (continued) Field Description ENCAPS Encapsulation methods: either null, or llc-snap. SERVICE TYPE Unspecified bit rate (ubr) or variable bit rate (vbr). VLAN ID VLAN name to which the ELAN belongs.

  • Page 86: Table 22 Information Fields For The Show Ports Info Atm Ports Command

    Chapter 5 Managing the Passport 8672ATM Module with the CLI Table 22 describes the information fields for the show ports info atm ports command. Table 22 Information fields for the show ports info atm ports command Field PORT NUM MDA DESCRIPTION SCRAMBLE ENABLE FRAMING MODE MAX-BITS VPI...

  • Page 87: Show Ports Info Atm Pvc Command

    Chapter 5 Managing the Passport 8672ATM Module with the CLI show ports info atm pvc command This command displays information circuits (PVCs) for the specified port or for all ports. The command uses the syntax: show ports info atm pvc [<ports>] Figure 30 show ports info atm pvc command output Passport-8610:5/show/ports/info/atm# pvc =======================================================...

  • Page 88: Show Ports Info Atm 1483 Command

    Chapter 5 Managing the Passport 8672ATM Module with the CLI show ports info atm 1483 command This command displays information specified port or for all ports. The command uses the syntax: show ports info atm 1483 [< ports >] Figure 31 show ports info atm 1483 command output Passport-8610:5# show ports info atm 1483 3/8 ================================================================ ================================================================...

  • Page 89: Show Ports Stats Atmport Command

    Chapter 5 Managing the Passport 8672ATM Module with the CLI Table 24 Information fields for the show ports info atm 1483 command (continued) Field Description VLAN MAC ADDRESS MAC address assigned to this VLAN: used in IP and IPX routed circuits when there is no appropriate destination MAC to use.

  • Page 90: Figure 32 Show Ports Stats Atmport [] Command Output

    Chapter 5 Managing the Passport 8672ATM Module with the CLI Figure 32 show ports stats atmport [<port num>] command output Passport-8606:6/show/ports/stats# atmport =========================================================================== =========================================================================== PORT CELLS CELLS --------------------------------------------------------------------------- 6744908 6744901 6744893 6744888 35314189 =========================================================================== =========================================================================== PORT IN DROP PKTS PKTS --------------------------------------------------------------------------- Passport-8606:6/show/ports/stats# Table 25...

  • Page 91: Show Ports Stats Atm Felinecurrent

    Chapter 5 Managing the Passport 8672ATM Module with the CLI Table 25 Information fields for the show ports stats atmport command (continued) Field Description IN UNCORR HCS ERR Number of packets received using the interface which were discarded because of an unknown or unsupported protocol.

  • Page 92: Figure 33 Show Ports Stats Atm Felinecurrent Command Output

    Chapter 5 Managing the Passport 8672ATM Module with the CLI Figure 33 show ports stats atm felinecurrent command output Passport-8610:5/show/ports/stats/atm# felinecurrent ====================================================================== ATM Far End Line Current Stats ====================================================================== PORT ERRORED SECONDS COUNT (ES) ---------------------------------------------------------------------- Passport-8610:5/show/ports/stats/atm# felinecurrent Table 26 describes the information fields for the felinecurrent Table 26 Information fields for the show ports stats atm felinecurrent command Field...

  • Page 93: Show Ports Stats Atm Felineinterval

    Chapter 5 Managing the Passport 8672ATM Module with the CLI show ports stats atm felineinterval This command displays statistics interval. You specify which interval, or span of intervals, to display for the command. The command uses the syntax: show ports stats atm felineinterval <intervalid> Figure 34 show ports stats atm felineinterval command output Passport-8610:5/show/ports/stats/atm# felineinterval 96 ======================================================================...

  • Page 94: Show Ports Stats Atm Fepathcurrent

    Chapter 5 Managing the Passport 8672ATM Module with the CLI Table 27 Information fields for the show ports stats atm felineinterval command (continued) Field SEVERELY ERRORED COUNT (SES) CODE VIOLATION COUNT (CV-L) UNAVAILABLE SECONDS (UAS) INTERVAL ID show ports stats atm fepathcurrent This command displays current statistics at the receiving end.

  • Page 95: Show Ports Stats Atm Fepathinterval

    Chapter 5 Managing the Passport 8672ATM Module with the CLI Table 28 describes the information fields for the show ports command. fepathcurrent Table 28 Information fields for the show ports stats atm fepathcurrent command Field Description PORT NUM Port number. ERRORED SECONDS Errored Second (ES) is a second with one or more Coding COUNT (ES)

  • Page 96: Figure 36 Show Ports Stats Atm Fepathinterval Command Output

    Chapter 5 Managing the Passport 8672ATM Module with the CLI Figure 36 show ports stats atm fepathinterval command output Passport-8610:5/show/ports/stats/atm# fepathinterval 96 ========================================================================= ========================================================================= PORT ERRORED SECONDS COUNT (ES) ------------------------------------------------------------------------ INTERVAL ID = 96 Passport-8610:5/show/ports/stats/atm# fepathinterval 96 Table 29 describes the information fields for the show ports fepathinterval Table 29 Information fields for the show ports stats atm fepathinterval command Field...

  • Page 97: Show Ports Stats Atm Linecurrent

    Chapter 5 Managing the Passport 8672ATM Module with the CLI show ports stats atm linecurrent This command displays current statistics uses the syntax: show ports stats atm linecurrent [< ports >] Figure 37 show ports stats atm linecurrent command output Passport-8610:5/show/ports/stats/atm# linecurrent ========================================================================= ========================================================================...

  • Page 98: Show Ports Stats Atm Lineinterval

    Chapter 5 Managing the Passport 8672ATM Module with the CLI Table 30 Information fields for the show ports stats atm linecurrent command (continued) Field SEVERELY ERRORED COUNT (SES) CODE VIOLATION COUNT (CV-P) UNAVAILABLE SECONDS (UAS) STATUS show ports stats atm lineinterval This command displays statistics interval.

  • Page 99: Show Ports Stats Atm Pathcurrent

    Chapter 5 Managing the Passport 8672ATM Module with the CLI Table 31 describes the information fields for the show ports command. lineinterval Table 31 Information fields for The show ports stats atm lineinterval command Field Description PORT NUM Port number. ERRORED SECONDS Errored Second (ES) is a second with one or more Coding COUNT (ES)

  • Page 100: Figure 39 Show Ports Stats Atm Pathcurrent Command Output

    Chapter 5 Managing the Passport 8672ATM Module with the CLI Figure 39 show ports stats atm pathcurrent command output Passport-8610:5/show/ports/stats/atm# pathcurrent ========================================================================= ========================================================================= PORT ERRED SECS SEVERELY ERRED CODE VIOLATION COUNT (ES) COUNT (SES) ------------------------------------------------------------------------- Passport-8610:5/show/ports/stats/atm# Table 32 describes the information fields for the show ports pathcurrent Table 32 Information fields for the show ports stats atm pathcurrent command Field...

  • Page 101: Show Ports Stats Atm Pathinterval

    Chapter 5 Managing the Passport 8672ATM Module with the CLI show ports stats atm pathinterval This command displays statistics You specify the interval or span of intervals to display. The command uses the syntax: show ports stats atm pathinterval < intervalid> [<ports >] Figure 40 show ports stats atm pathinterval command output Passport-8610:5/show/ports/stats/atm# pathinterval 96 =========================================================================...

  • Page 102: Show Ports Stats Atm Sectioncurrent

    Chapter 5 Managing the Passport 8672ATM Module with the CLI Table 33 Information fields for the show ports stats atm pathinterval command (continued) Field SEVERELY ERRORED COUNT (SES) CODE VIOLATION COUNT (CV-P) UNAVAILABLE SECONDS (UAS) INTERVAL ID show ports stats atm sectioncurrent This command displays the current statistics command uses the syntax: show ports stats atm sectioncurrent...

  • Page 103: Show Ports Stats Atm Sectioninterval

    Chapter 5 Managing the Passport 8672ATM Module with the CLI Table 34 describes the information fields for the show ports command. sectioncurrent Table 34 Information fields for the show ports stats atm sectioncurrent command Field Description PORT NUM Port number. ERRORED SECONDS Errored Second (ES) is a second with one or more Coding COUNT (ES)

  • Page 104: Figure 42 Show Ports Stats Atm Sectioninterval Command Output

    Chapter 5 Managing the Passport 8672ATM Module with the CLI Figure 42 show ports stats atm sectioninterval command output Passport-8610:5/show/ports/stats/atm# sectioninterval 96 =========================================================================== =========================================================================== PORT ERRORED SECONDS COUNT (ES) --------------------------------------------------------------------------- INTERVAL ID = 96 Passport-8610:5/show/ports/stats/atm# sectioninterval 96 Table 35 describes the information fields for the show ports sectioninterval Table 35 Information fields for the show ports stats atm sectioninterval command Field...

  • Page 105: Show Ports Stats Atm Sonetmediumtbl

    Chapter 5 Managing the Passport 8672ATM Module with the CLI show ports stats atm sonetmediumtbl This command displays statistics command uses the syntax: show ports stats atm sonetmediumtbl Figure 43 show ports stats atm sonetmediumtbl command output Passport-8610:5/show/ports/stats/atm# sonetmediumtbl ========================================================================= =========================================================================== PORT MEDIUM...

  • Page 106: Web Management

    Device Manager software. For information on: • Accessing your switch through the Web interface • Descriptions of the Web page layout refer to Getting Started with the Passport 8000 Series Management Software.

  • Page 107: Figure 44 System Page

    Chapter 5 Managing the Passport 8672ATM Module with the CLI Figure 44 System page Table 37 describes the fields displayed in the System page. Table 37 System page fields Field sysDescr sysUpTime sysContact sysName sysLocation Authentication Traps EnableWebServer EnableAccessPolicy Description Port type of this interface.
  • Page 108 Chapter 5 Managing the Passport 8672ATM Module with the CLI Table 37 System page fields (continued) Field LastChange LastVlanChange LastRuntimeConfigSave LastRuntimeConfigSavetoSlave LastBootConfigSave LastBootConfigSaveOnSlave DefautlRuntimeConfigFileName DefaultBootConfigFileName ConfigFileName When you click ATM in the navigation pane, the headings in the ATM menu are displayed.

  • Page 109: Figure 45 Atm Menu

    Chapter 5 Managing the Passport 8672ATM Module with the CLI Figure 45 ATM menu To view the current PVC parameters, in the ATM menu, click PVC. The PVC page opens (Figure 46). Using the Passport 8672ATM Module...

  • Page 110: Figure 46 Pvc Page

    Chapter 5 Managing the Passport 8672ATM Module with the CLI Figure 46 PVC page Table 38 describes the fields displayed in the PVC page. Table 38 PVC page items Field Index Pvc Id Name Encapsulation Service Type Peak Cell Rate Sustained Cell Rate Max Burst Size 209195-A...

  • Page 111: Figure 47 1483 Elan Page, (Left Section)

    Chapter 5 Managing the Passport 8672ATM Module with the CLI To view the current 1483 ELAN parameters, in the ATM menu, click 1483 ELAN. The 1483 ELAN page opens. view the entire table, use the scroll arrow at the bottom right corner. shows the right section of the page.

  • Page 112: Table 39 1483 Elan

    Chapter 5 Managing the Passport 8672ATM Module with the CLI Table 39 describes the fields displayed in the 1483 ELAN page. 1483 ELAN Table 39 Field Index Elan Id Num Pvc Ids PvcIds Vlan Ids Connect Type Vlan Mac Address Dummy Mac Address Local Ip Address Remote Ip Address...

  • Page 113: Figure 49 Port Page

    Chapter 5 Managing the Passport 8672ATM Module with the CLI Figure 49 Port page Table 40 describes the fields displayed in the Port page. Table 40 Port page items Field Index Num Vpi Bits Num Vci Bits Media Type Scramble Enable Description Interface Index.
  • Page 114 Chapter 5 Managing the Passport 8672ATM Module with the CLI Table 40 Port page items (continued) Field Framing Mode Clock Source Line Speed Loop Back Mode Mac Address 209195-A Description Sets the framing for the port to: • sonet means the Synchronous Optical Network format; standard format used in North America.

  • Page 115: Configuring The Passport 8672Atm Module

    Chapter 6 Configuring the Passport 8672ATM Module This chapter contains the following topics: • “Initial • “Basic configuration procedures” on page 118 For detailed information on Device Manager, and the CLI, refer to: • Getting Started with the Passport 8000 Series Management Software •...

  • Page 116: Changing The Clock Setting Using Device Manager

    Chapter 6 Configuring the Passport 8672ATM Module • “Changing the clock setting using the CLI” on page 117 Note: The Passport 8672ATM Module supports only Ethernet ELANs. Changing the clock setting using Device Manager This section provides instructions on changing the clock setting. Note: If you are connecting one Passport 8672ATM Module directly to another Passport 8672ATM Module without going through the SONET cloud, the clock mode at both ends of the circuit may be free-running,...

  • Page 117: Changing The Clock Setting Using The Cli

    Chapter 6 Configuring the Passport 8672ATM Module Figure 50 ATM tab Table 9 on page 60 To set the clock setting, in the ClockSource section, click loopTimed or freeRunning. Click Apply. Changing the clock setting using the CLI To change the clock setting using the CLI, enter: config atm <...

  • Page 118: Basic Configuration Procedures

    Passport 8672ATM Modules. You cannot bridge between PVCs in the same VLAN on the same port of the Passport 8672ATM Module. Nortel Networks recommends that you create a new STP group for bridging between ATM ports and Ethernet ports. You should remove the ATM port from the default STP group and from the default VLAN.

  • Page 119: Creating A Vlan "Byport" And Adding Ports

    Chapter 6 Configuring the Passport 8672ATM Module Figure 51 Point-to-point bridging using 1483 PVCs Passport 8600 VLAN2 ATM VC1 8672 ATM MDA 1 MDA 2 Online ATM VC2 VLAN1 To complete this configuration, use the following procedures: • “Creating a VLAN “byPort” and adding •...

  • Page 120: Figure 52 Basic Tab

    Chapter 6 Configuring the Passport 8672ATM Module Figure 52 Basic tab Table 41 describes the Basic tab fields. Table 41 Basic tab fields Field Name ColorIdentifier Type StgId PortMembers ActiveMembers StaticMembers NotAllowtoJoin ProtocolId 209195-A Description Unique VLAN identifier. An administratively-assigned name for this VLAN. An administratively-assigned color code for this VLAN.

  • Page 121: Figure 53 Vlan, Insert Basic Dialog Box

    Chapter 6 Configuring the Passport 8672ATM Module Table 41 Basic tab fields (continued) Field Description SubnetAddr IP subnet address of this VLAN. This value is meaningful only if rcVlanType is equal to byIpSubnet(2). For other VLAN types it should have the value 0.0.0.0. SubnetMask IP subnet mask of this VLAN.

  • Page 122: Table 42 Vlan, Insert Basic Dialog Box Fields

    Chapter 6 Configuring the Passport 8672ATM Module Table 42 VLAN, Insert Basic dialog box fields Field Name ColorIdentifier StgId Type PortMembers QoSLevel Ds field Do the following: In the Id field, enter the Id number for the VLAN (an integer between 0 and 4094).

  • Page 123: Configuring An Atm 1483 Pvc

    Figure 54 VlanPortMembers dialog box Table 43 describes the VlanPortMembers dialog box fields. Table 43 VlanPortMembers dialog box fields Field Left column All other numbers Click port numbers to add ports to the VLAN. Click OK. The VlanPortMembers dialog box closes and the VLAN, Insert Basic dialog is redisplayed.

  • Page 124: Associating The Pvc With The Vlan

    Chapter 6 Configuring the Passport 8672ATM Module Table 11 on page 63 Do the following: In the Port field, click the button to view ports. b Select the port. In the Vpi field, type the VPI-bit size (an integer between 0 and 255). d In the Vci field, type the VCI-bit size (an integer between 0 and 65, 535).

  • Page 125: Bridging Point-To-Point Traffic Using An Atm 1483 Pvc Using The Cli

    Chapter 6 Configuring the Passport 8672ATM Module The Insert ATM 1483 ELAN dialog box opens Table 13 on page 68 Do the following: In the Port field, click the button to view ports. b Select the port for which you configured the ATM PVC in two ATM 1483 PVCs on the same ATM port”...

  • Page 126: Bridging Point-To-Multipoint Traffic Using An Atm 1483 Pvc Using Device Manager

    Chapter 6 Configuring the Passport 8672ATM Module config atm 1/1 pvc create 0.100 enc 1483-null serv vbr<PCR value>scr<SCR value> mbs<MBS value> To associate the ATM 1483 bridged PVC with a VLAN, enter: config atm 1/1 pvc 1483 elan create 2 0.100 Bridging point-to-multipoint traffic using an ATM 1483 PVC using Device Manager In the configuration shown in...

  • Page 127: Configuring Two Atm 1483 Pvcs On The Same Atm Port

    Chapter 6 Configuring the Passport 8672ATM Module Configuring two ATM 1483 PVCs on the same ATM port Follow the procedures outlined in 1483 PVC using Device Manager” on page 118 the same ATM port. Associating the PVCs with the same VLAN Follow the procedures outlined in page 124 to associate both PVCs with the same VLAN.

  • Page 128: Configuring An Ip Routing 1483 Pvc Using Device Manager

    Chapter 6 Configuring the Passport 8672ATM Module Configuring an IP routing 1483 PVC using Device Manager Note: Because the spanning tree protocol (STP) is not supported on the Passport 8672ATM Module, ensure that you have no parallel paths to the destination.

  • Page 129: Creating Two Vlans "Byport

    Chapter 6 Configuring the Passport 8672ATM Module Creating two VLANs “byPort” To create two VLANs “byPort,” see ports” on page 119. One VLAN must have only one ATM port. The second VLAN can have one or multiple Ethernet ports. Assigning IP addresses To assign an IP address to both VLANs: From the Device Manager menu bar, choose VLAN >...

  • Page 130: Figure 58 Ip, Vlan, Insert Ip Address Dialog Box

    Chapter 6 Configuring the Passport 8672ATM Module IP Address tab Table 44 Field VlanId BrouterPort Click Insert. The IP, VLAN, Insert IP Address dialog box opens Figure 58 IP, VLAN, Insert IP Address dialog box Table 45 describes the IP, VLAN, Insert IP Address dialog box fields. Table 45 IP, VLAN, Insert IP Address dialog box fields Field Ip Address...

  • Page 131: Enabling Rip Routing

    Chapter 6 Configuring the Passport 8672ATM Module Enabling RIP routing From the Device Manager menu bar, choose VLAN > VLANs. The VLAN dialog box opens with the Basic tab displayed Table 41 on page 120 describes the VLAN Basic tab fields. Click one of the VLANs.

  • Page 132: Enabling Ospf Routing

    Chapter 6 Configuring the Passport 8672ATM Module Table 46 RIP tab fields (continued) Field Listen Poison AdvertiseDefaultRoute AcceptDefaultRoute TriggeredUpdateEnable Indicates whether the RIP triggered update feature should AutoAggregateEnable AdvertiseWhenDown Click Enable. Click Apply. The IP Address tab is redisplayed. Click Close. Enabling OSPF routing If the routing protocol is OSPF, to enable OSPF routing: From the Device Manager menu bar, choose VLAN >...

  • Page 133: Figure 60 Ospf Tab

    Chapter 6 Configuring the Passport 8672ATM Module The IP, VLAN, Insert IP Address dialog box opens with the IP Address tab displayed (Figure 58 on page Table 44 on page 129 describes the Ip Address tab fields. Click the OSPF tab. The OSPF tab opens (Figure Figure 60 OSPF tab...

  • Page 134: Configuring A Null-Encapsulation Pvc

    Chapter 6 Configuring the Passport 8672ATM Module Table 47 OSPF tab fields (continued) Field Metric AuthType AreaId AdvertiseWhenDown Click Enable. Click Apply. The OSPF tab closes, and the IP Address tab is redisplayed. Click Close. Configuring a null-encapsulation PVC “Configuring two ATM 1483 PVCs on the same ATM port” on page Associating the PVC with the VLAN “Associating the PVC with the VLAN”...

  • Page 135: Configuring An Ipx Routing 1483 Pvc Using Device Manager

    Chapter 6 Configuring the Passport 8672ATM Module config vlan 2 create byport 1 config vlan 3 create byport 1 To add an ATM port (in this example, 1/1) and several Ethernet ports (in this example, 3/40 to 3/48) to the VLAN, enter: config vlan 2 port add 1/1 config vlan 3 port add 3/40-3/48 To configure IP addresses on both VLANs (use two different subnets), enter:...

  • Page 136: Creating Two Vlans "Byport

    Chapter 6 Configuring the Passport 8672ATM Module Figure 61 IPX routing with ATM 1483 PVCs Note: Each configured ATM 1483 PVC uses one VLAN. The Passport 8672ATM Module can be configured for a maximum of 256 VLANs per MDA and a maximum of 512 VLANs per card. This configuration requires the following procedures: •...

  • Page 137: Figure 62 Ipx Vlan Dialog Box

    Chapter 6 Configuring the Passport 8672ATM Module From the Device Manager menu bar, choose VLAN > VLANs. The VLAN dialog box opens with the Basic tab displayed Table 41 on page 120 describes the VLAN Basic tab fields. Click one of the VLANs. Click IPX.

  • Page 138: Enabling Ipx Forwarding

    Chapter 6 Configuring the Passport 8672ATM Module Figure 63 IPX VLAN, Insert dialog box Table 49 Table 49 IPX VLAN, Insert dialog box fields Field NetAddr Encap In the NetAddr field, configure the IPX network numbers for the VLAN. In the Encap field, click the encapsulation type. Click Insert.

  • Page 139: Enabling Ipx Network Number Forwarding

    Chapter 6 Configuring the Passport 8672ATM Module Figure 64 Globals tab Table 50 describes the Globals tab item. Table 50 Globals tab item Item Description RoutingEnable Enables routing. Click RoutingEnable. Click Apply. Click Close. Enabling IPX network number forwarding To enable forwarding for the IPX network number: From the Device Manager menu bar, choose IPX Routing >...

  • Page 140: Configuring A Null-Encapsulation Pvc

    Chapter 6 Configuring the Passport 8672ATM Module Figure 65 Circuits tab Table 51 Table 51 Circuits tab fields Field Index OperState Index VlanId NetNumber CompressedInitSent In the OperState field, enter “up” for all IPX network numbers created in this procedure. Click Apply.

  • Page 141: Configuring An Ipx Routing 1483 Pvc Using The Cli

    Chapter 6 Configuring the Passport 8672ATM Module Follow the instructions there except, in the ConnectType field, select Ipx instead of bridged. Configuring an IPX routing 1483 PVC using the CLI To configure the Passport 8672ATM Module for this setup using the CLI: To create two VLANs by port, enter: config vlan 2 create byport 1 config vlan 3 create byport 1...
  • Page 142 Chapter 6 Configuring the Passport 8672ATM Module 209195-A...

  • Page 143: Technical Specifications

    Appendix A Technical Specifications This appendix lists the technical specifications for the Passport 8672ATM Module. Environmental specifications Operating temperature: Storage temperature: Operating humidity: Storage humidity: Operating altitude Storage altitude Free fall/drop: Vibration: Shock/bump: Physical specifications Height: Width: Depth: Weight (single module): Performance specifications (64-byte packets) Mean time between failure (MTBF)
  • Page 144 Appendix A Technical Specifications Electromagnetic emissions Meets requirements of: 209195-A CUL CSA 22.2 No. 950 IEC 950/EN 60950 CE mark CB Scheme Test Report and Certification NOM (NOM-019-SCFI-1994) US: FCC, CFR 47, Part 15, Subpart B, Class A Canada: ICES-003, Issue-2, Class A Australia/New Zealand: AS/NZS 3548:1995, Class A Japan: VCCI V-3/97.04, Class A Taiwan: CNS 13438,Class A...

  • Page 145: Factory Defaults

    Appendix B Factory defaults shows the default settings on the Passport 8672ATM Module as it comes Table 52 from the factory, as well as the management tool to change parameters. Table 52 Factory default settings for the Passport 8672ATM Module Parameter VPI bits VCI bits...
  • Page 146 Appendix B Factory defaults 209195-A...

  • Page 147: Index
