Spreadsheet View: SMT Pads Tab
© National Instruments Corporation
Column
Routing
The routing priority for the selected net group. 1 is the
Priority
highest priority, 2 the second highest, etc. Leave as
None if priority routing is not required. This feature is
not available in all versions of Ultiboard.
Locked
Yes indicates that the part cannot be moved. No
indicates that the part can be moved.
Max Via
This is the maximum number of vias allowed in the
Count
net group.
Use the SMT Pads tab to work with pad information for surface-mount
devices.
Column
Pad Name
The unique identifier for the pad, by RefDes and Pin
Number. For example, U1, P1 is pin number one of
the device with RefDes U1.
Pad Shape
The shape of the pad as set in the SMT Pin
Properties dialog box. Refer to the
Editing SMT Pin Properties
Working with
Pad Radius
The radius of the pad as set in the SMT Pin
Properties dialog box. Refer to the
Editing SMT Pin Properties
Working with
Pad Width
The width of the pad as set in the SMT Pin
Properties dialog box. Refer to the
Editing SMT Pin Properties
Working with
Pad Height
The height of the pad as set in the SMT Pin
Properties dialog box. Refer to the
Editing SMT Pin Properties
Working with
Description
Description
Parts, for more information.
Parts, for more information.
Parts, for more information.
Parts, for more information.
1-39
Chapter 1
User Interface
Viewing and
section of Chapter 4,
Viewing and
section of Chapter 4,
Viewing and
section of Chapter 4,
Viewing and
section of Chapter 4,
NI Ultiboard User Manual
