Chapter 1
User Interface
NI Ultiboard User Manual
Button
New File button. Creates a new project (if none are
currently open) or a new design if a project is currently
open. Refer to the
Design
sections of Chapter 2,
more information.
Open File button. Opens an existing project. Refer to the
Opening an Existing File
a
Design, for more information.
Open Sample button. Opens the samples folder.
Save File button. Saves the active design to its current
name and directory. Refer to the
section of Chapter 2,
information.
Print button. Displays the Print dialog. Refer to the
Printing your Design
Manufacturing/Assembly, for more information.
Cut button. Cuts the selected element from the design and
places it on the Windows Clipboard.
Copy button. Copies the selected element from the design
and places it on the Windows Clipboard.
Paste button. Pastes the element from the Windows
Clipboard to the design.
Undo button. Undoes the last action.
Redo button. Redoes the last action (used after undoing).
1-2
Description
Creating a Project
and
Beginning a
section of Chapter 2,
Saving and Closing
Beginning a
Design, for more
section of Chapter 8,
Creating a
Design, for
Beginning
Preparing for
ni.com
