Draytek Vigor3900 User Manual page 415

WANs
ACS Server URL/
ACS Server Username /
ACS Server Password
Last Inform Response
Time
ACS Connection Status
Port
CPE URL
CPE Username
CPE Password
Turn on log message to
syslog
Periodic Status
Periodic Time
Enable STUN
Apply
Cancel
Enter all of the settings and click Apply.
Vigor3900 Series User's Guide
connection when the original WAN interface fails.
Such data must be typed according to the ACS (Auto
Configuration Server) you want to link. Please refer to Auto
Configuration Server user's manual for detailed information.
Display the response time informed by VigorACS.
When it lights in green, it means the router has been detected
and can be managed by VigorACS.
Type the port number for Vigor3900 which will be
recognized by VigorACS.
Display the URL of such CPE.
Type the user name for the CPE which will be used by the
administrator of VigorACS to log into the WUI of
Vigor3900.
Type the password for the CPE which will be used by the
administrator of VigorACS to log into the WUI of
Vigor3900.
The default setting Disable. Click Enable to make the log
message being recorded by Syslog.
The default setting is Enable. Please set periodic time for
VigorACS to send notification to CPE. Or click Disable to
close the mechanism of notification.
Set the time for VigorACS to send notification to CPE.
Enable/Disable - The default is Disable. If you click
Enable, please type the relational settings listed below:
Server Address – Type the IP address of the STUN server.
Server Port – Type the port number of the STUN server.
Minimum Keep Alive Period – If STUN is enabled, the
CPE must send binding request to the server for the purpose
of maintaining the binding in the Gateway. Please type a
number as the minimum period. The default setting is "60
seconds".
Maximum Keep Alive Period – If STUN is enabled, the
CPE must send binding request to the server for the purpose
of maintaining the binding in the Gateway. Please type a
number as the maximum period. A value of "-1" indicates
that no maximum period is specified.
Click it to save the configuration.
Click it to discard the settings configured in this page.
407
