Draytek Vigor3900 User Manual page 339

4 . 9 . 4 . 2
4 . 9 . 4 . 2
This page display current status for VPN tunnel built with L2TP protocol.
Available parameters are listed as follows:
Item
Authenticate Protocol
User Authentication
Type
LDAP profiles
DHCP from
DHCP Relay
Vigor3900 Series User's Guide
L 2 T P
L 2 T P
Description
The router will authenticate the dial-in user with the protocol
selected here.
PAP - It means the router will attempt to authenticate dial-in
users with the PAP protocol.
CHAP - It means the router will attempt to authenticate
dial-in users with the CHAP protocol.
Set user authentication to Local server or RADIUS server.
Choose a LDAP profile for PPTP Server if LDAP is selected
as user authentication type.
To clear the selected one, click
selections.
Choose a LAN profile for L2TP Server if RADIUS is
selected as user authentication type.
Enable - Let the router assign IP address to every host in the
LAN.
331
to remove current object
