Draytek Vigor3900 User Manual page 132

4 . 2 . 2 . 1 O n l i n e C l i e
4 . 2 . 2 . 1 O n l i n e C l i e
This page displays general information for PPPoE server; allows you to disconnect the
network connection to PPPoE server.
Each item will be explained as follows:
Item
Refresh
Disconnect
Auto Refresh
MAC Address
User Name
IP Address
Up Time
RX Bytes
TX Bytes
n t S t a t u s
n t S t a t u s
Description
Renew current web page.
Click it to disconnect the profile connection.
Specify the interval of refresh time to obtain the latest status.
The information will update immediately when the Refresh
button is clicked.
Display the MAC address of the client's host.
Display the user name used to access into the PPPoE server.
Display the IP address of the client's host.
Display the time that the PPPoE connection built.
Display the total amount of received packets.
Display the total amount of transmitted packets.
124
Vigor3900 Series User's Guide
