4G DHCP
Default
Apply
Cancel
4. Enter all the settings and click Apply. The modified profile will be shown as below.
command to restrict 3G band or do any special settings.
APN -APN means Access Point Name which is provided
and required by some ISPs. Type the name.
Modem Dial String -Such value is used to dial through USB
mode. Please use the default value. If you have any question,
please contact to your ISP.
PPP Username -Type the PPP username (optional).
PPP Password -Type the PPP password (optional).
SIM Pin code –Type PIN code of the SIM card that will be
used to access Internet.
Network Mode – Force Vigor router to connect Internet
with the mode specified here. If you choose 4G/3G/2G as
network mode, the router will choose a suitable one
according to the actual wireless signal automatically.
APN Name – APN means Access Point Name which is
provided and required by some ISPs.
Click it to restore the default settings.
Click it to save and exit the dialog.
Click it to exit the dialog without saving anything.
