NOTE: No diagnostic indicators are lit when the system is switched off. To start the system, plug it
into a working power source and press the power button.
Table 5. Diagnostic indicators
Icon Description
Health
indicator
Hard drive
indicator
Electrical
indicator
Temperature
indicator
Memory
indicator
Condition
If the system is on and in
good health, the indicator
turns solid blue.
The indicator flashes amber
if the system is on or in
standby, and if any error
exists (for example, a failed
fan or hard drive).
The indicator flashes amber
if there is a hard drive error.
The indicator flashes amber
if the system experiences an
electrical error (for example,
voltage out of range, or a
failed power supply unit
(PSU) or voltage regulator).
The indicator flashes amber
if the system experiences a
thermal error (for example, a
temperature out of range or
fan failure).
The indicator flashes amber
if a memory error occurs.
Corrective action
None required.
Check the System Event Log or system
messages for the specific issue. For more
information about error messages, see the
Dell Event and Error Messages Reference
Guide at Dell.com/openmanagemanuals >
OpenManage software.
Invalid memory configurations can cause
the system to halt at startup without any
video output. See Getting
Check the System Event Log to determine
the hard drive that has an error. Run the
appropriate Online Diagnostics test. Restart
the system and run embedded diagnostics
(ePSA). If the hard drives are configured in a
RAID array, restart the system and enter the
host adapter configuration utility program.
Check the System Event Log or system
messages for the specific issue. If it is due
to a problem with the PSU, check the LED
on the PSU. Reseat the PSU. If the problem
persists, see Getting help.
Ensure that none of the following
conditions exist:
• A cooling fan is removed or has failed.
• System cover, cooling shroud, EMI filler
panel, memory module blank, or back
filler bracket is removed.
• Ambient temperature is too high.
• External airflow is obstructed.
See Getting help.
Check the system event log or system
messages for the location of the failed
memory. Reseat the memory module. If
the problem persists, see
help.
Getting help.
