- Page 1 LPe15004, LPe16004, and LPe16000B-Series Adapters Installation Manual P008875-03A Rev. A Connect • Monitor • Manage...
- Page 2 Information furnished by Emulex is believed to be accurate and reliable. However, no responsibility is assumed by Emulex for its use; or for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent, copyright or related rights of Emulex.
-
Page 3: Table Of Contents
Table of Contents Table of Contents List of Figures ..................4 List of Tables ..................5 1. Introduction ..................6 Overview ....................6 Major Features ..................6 Compatibility ..................7 Prerequisites..................7 Adapter Identification ................7 2. Installation..................8 Preparing the Adapter for Installation ............8 Installing the Adapter ................ -
Page 4: List Of Figures
List of Figures List of Figures Figure 2-1 Typical Optical Transceiver .............. 8 Figure 2-2 Releasing the Latch on an Optical Transceiver........9 Figure 2-3 Removing an Optical Transceiver............9 Figure 2-4 Removing the Bracket ..............10 Figure 2-5 Installing an Optical Transceiver ............12 Figure 2-6 Connecting a Fiber Optic Cable............12 Figure 2-7... -
Page 5: List Of Tables
List of Tables List of Tables Table 1-1 Software and Hardware Environments..........7 Table 2-1 Media Specifications ..............11 Table 2-2 POST Conditions and Results ............14 Table 3-1 LPe15004, LPe16004, and LPe16000B–series Adapter Specifications....15 LPe15004, LPe16004, and LPe16000B-series HBA Installation Manual P008875-03A Rev. -
Page 6: Introduction
LPe16000B, LPe16002B, and LPe16004, 16 Gbps The core technology of these adapters is Emulex's 10th generation FC controller. The controller is a multi-function PCIe Gen3 interface controller that is compliant to the PCI Express Base Specification Rev 3.0 and PCI Express CEM Specification Rev 3.0. The LPe16000B is a single-channel adapter, the LPe16002B is a dual-channel adapter, and the LPe15004 and LPe16004 are four-channel adapters. -
Page 7: Compatibility
Use PCIe Gen 3 compliant systems that are x8 or x16 lane at up to 8 GTps per lane. Adapter Identification Each adapter ships with several numbers clearly marked on the board. Emulex recommends recording these numbers before installation. Serial number – assigned by Emulex. Use this number when communicating ... -
Page 8: Installation
The standard adapters can be connected to fiber optic cables. Preparing the Adapter for Installation The Emulex LPe16004, LPe16000B, and LPe16002B adapters use removable optical transceivers. If you need to change the bracket for an adapter installation, you must first remove the optical transceiver(s), if installed, from the housing (cage). This procedure explains how to remove the transceiver and bracket safely. -
Page 9: Figure 2-2 Releasing The Latch On An Optical Transceiver
2. Installation Preparing the Adapter for Installation Figure 2-2 shows a transceiver with the latch released (bail extended) and another transceiver latched in place. Figure 2-2 Releasing the Latch on an Optical Transceiver Figure 2-3 shows an extracted transceiver and another transceiver latched in place. Figure 2-3 Removing an Optical Transceiver 3. -
Page 10: Installing The Adapter
2. Installation Installing the Adapter 4. Remove the mounting bracket screws from the top of the adapter. Figure 2-4 shows the screws that are removed from the bracket. Figure 2-4 Removing the Bracket 5. Remove the bracket and store it for future use. 6. -
Page 11: Attaching Media
2. Installation Attaching Media See “Preparing the Adapter for Installation” on page 8 to change the brackets if needed. Otherwise, proceed to “Attaching Media” on page 11. 4. Insert the adapter into an empty PCIe x8 or x16 slot. Press firmly until the adapter is seated. -
Page 12: Figure 2-5 Installing An Optical Transceiver
2. Installation Attaching Media To attach media to the adapter: 1. Connect the appropriate cable to the adapter. When connecting an optical cable, ensure the cages have optical transceivers installed in them (see Figure 2-5). Figure 2-5 Installing an Optical Transceiver Once the optical transceivers are installed, insert the optical cable into the LC connectors on the adapter (see Figure 2-6). -
Page 13: Applying Power
2. Installation Applying Power Applying Power To apply power: 1. Verify that the adapter is securely installed in the system. 2. Verify that the correct media is attached. 3. Plug in and turn on the system. 4. Watch the LEDs for Power On Self Test (POST) results. Viewing the LEDs You can view green and yellow LEDs through openings in the adapter's mounting bracket. -
Page 14: Table 2-2 Post Conditions And Results
2. Installation Viewing the LEDs Note: For the Link Rate conditions, there is a 1 second pause when the LED is off between each group of fast blinks (2, 3, or 4). Observe the LED sequence for several seconds to be sure you have correctly identified the pattern. Table 2-2 POST Conditions and Results Green LED Yellow LED... -
Page 15: References
3. References LPe15004, LPe16004, and LPe16000B–Series Adapter Specifications 3. References LPe15004, LPe16004, and LPe16000B–Series Adapter Specifications The specifications of the LPe15004, LPe16004, and LPe16000B–series adapters are listed in Table 3-1. Table 3-1 LPe15004, LPe16004, and LPe16000B–series Adapter Specifications Parameter Range Physical Dimensions LPe16000B-series and LPe15004 adapters: Low-profile form factor, 6.600 inches by 2.731 inches. -
Page 16: Fcc And Regulatory Notices
Responsible Party: Jeff Benck, President and Chief Executive Officer Emulex Corporation (714) 662-5600 3333 Susan St. Costa Mesa, CA. 92626 USA Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. - Page 17 3. References FCC and Regulatory Notices or modifications made to the equipment not expressly approved by Emulex could void the user's authority to operate this equipment. The above statement applies to products marketed in the USA. This class A digital apparatus meets all requirements of the Industry Canada (IC) Interference - Causing Equipment Standard (ICES-003).
-
Page 18: Declarations Of Conformity
3. References Declarations of Conformity Declarations of Conformity LPe16004 and LPe16000B–series Adapter Models This equipment complies with CISPR22/EN55022 Class A. WARNING: This is a class A product. In a domestic environment, this product may cause radio interference requiring the user to take adequate measures. LPe15004, LPe16004, and LPe16000B-series HBA Installation Manual P008875-03A Rev. -
Page 19: Declaration Of Conformity
3. References Declarations of Conformity Note: Changes or modifications not expressly approved by Emulex Corporation, including the use of non-Emulex approved optical transceivers, could void the user's authority to operate this equipment. DECLARATION OF CONFORMITY Manufacturer: Emulex Corporation 3333 Susan Street Costa Mesa, CA. -
Page 20: Laser Safety Notice
This is a class A product. In a domestic environment, this product may cause radio interference requiring the user to take adequate measures. Changes or modifications not expressly approved by Emulex Corporation could void the user's authority to operate this equipment. - Page 21 EN/IEC 60825-1. Class 1 laser devices are not considered to be hazardous. The use of non-Emulex approved optical transceivers, or transceivers which do not comply with the Class 1 radiation performance requirements defined in DHHS/CDRH 21CFR Sub-chapter J and IEC 60825-1, may expose the user to hazardous laser radiation, and such devices should not be used with Emulex products.
