  • Page 1: Table Of Contents

    Emulex Drivers, Software and Manuals LP9002C Installation and Reference Manual Table of Contents Installation Compatability Prerequisites Set Jumpers Install HBA Attach Media Apply Power View LEDs Reference Specifications FCC and Regulatory Notices Declaration of Conformity Laser Safety...

  • Page 2: Compatability

    Emulex Drivers, Software and Manuals Chapter 1 − Installation Table of Contents Compatability Prerequisites Set Jumpers Install HBA Attach Media Apply Power View LEDs...

  • Page 3: Installation

    Installation Caution Emulex LightPulse ® Host Bus Adapters (HBAs) contain electronic components that can be damaged by static electricity through an electrostatic discharge (ESD) event. To prevent ESD damage, maintain constant contact with any grounded metal surface. A grounding wrist strap is useful for this purpose.

  • Page 4: Set Jumpers

    Set Jumpers The host adapter has two jumper blocks (JX1, JX2) that control the host adapter's device ID. The default device ID is F900. Device ID F900 1AE5 F901 Emulex Drivers, Software and Manuals Jumper setting JX1:1−2, JX2:2−3 JX1:2−3, JX2:2−3 JX1:2−3,...

  • Page 5: Install The Host Bus Adapter Board

    Remove the blank panel from an empty 32− or 64−bit cPCI bus slot, or remove the existing HBA. With the lever open, hold the LP9002C board by the two side edges or the bracket, and slide the card into the slot between the two guides.
  • Page 6 Emulex Drivers, Software and Manuals Tighten the captive Phillip screws on either side of the board. The host bus adapter is now installed in the system and is ready for media attachment.

  • Page 7: Attach Media

    Connect the fiber optic cable to the LC connector on the HBA. Connect other end of cable to Fibre Channel device. After the media is connected to the host bus adapter, you are ready to apply power to the computer. Emulex Drivers, Software and Manuals Minimum Connector Length...

  • Page 8: Apply Power

    Green Yellow LED Slow Blink (1 Hz) Fast Blink (4 Hz) Flashing (irregular) Slow Blink (1 Hz) Emulex Drivers, Software and Manuals State Wake−up Failure (Dead Board) POST Failure (Dead Board) Wake−up Failure Monitor Failure in POST (Dead Board) POST Processing in Progress...
  • Page 9 Fast Blink (4 Hz) Slow Blink Fast Blink (4 Hz) Fast Blink Fast Blink (4 Hz) Flashing Emulex Drivers, Software and Manuals Normal − 2 Gb Link Rate Normal − Link Down or Not Yet Started Not defined Off−line for Download Restricted Off−line Mode (Waiting...

  • Page 10: Specifications

    Emulex Drivers, Software and Manuals Chapter 2 − Reference Table of Contents Specifications FCC and Regulatory Notices Declaration of Conformity Laser Safety...
  • Page 11 TUV certified to EN60950 FCC Rules, Part 15, Class A Industry Canada, ICES−003, Class A EMC Directive 89/336/EEC (CE Mark) EN55022, Class A EN55024 Australian EMC Framework (C−Tick Mark) AS/NZS 3548: Class A VCCI, Class A Emulex Drivers, Software and Manuals...

  • Page 12: Fcc And Regulatory Notices

    APPAREIL A` LASER DE CLASSE 1 The above statement applies to products marketed in the European Union. Model LP9002 / LP9002L / LP952L / LP9002S / LP9002DC / LP9002C / LP9402DC (2x5 SFF Models) This device complies with Part 15 of the FCC Rules. Operation is subject to the...
  • Page 13 Consult the dealer or an experienced radio/TV technician for help. The reader is cautioned that any changes or modifications to the equipment not expressly approved by Emulex could void the user’s authority to operate this equipment. This class B digital apparatus meets all requirements of the Canadian Interference −...
  • Page 14 VCCI Notices and Translations (Japan Only) Note VCCI regulations provide that changes or modifications not expressly approved by Emulex Corporation could void your authority to operate this equipment. LP9000−N1/L1/T1 (GBIC Model): Translation: This is a Class B product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI).
  • Page 15 Emulex Drivers, Software and Manuals Manual Notice Translation: This is a Class A product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance may arise. When...

  • Page 16: Declaration Of Conformity

    Declaration of Conformity LP9002 / LP9002L / LP952L / LP9002S / LP9002C / LP9002DC / LP9402DC−F2 (2x5 SFF models) Note Changes or modifications not expressly approved by Emulex Corporation could void the user's authority to operate this equipment. This equipment complies with CISPR22/EN55022 Class A.
  • Page 17 − Australian EMC Framework (Carries the C−Tick mark accordingly) February 22, 2002 Costa Mesa, CA European Emulex Corporation Contact: 7 & 8 Forrest Court, Oaklands Park, Fishponds Road Wokingham, Berkshire, RG41 2FD, England Emulex Drivers, Software and Manuals Telephone: 44−118−977−2929 Fax: 44−118−977−3237...

  • Page 18: Laser Safety Notice

    In turn, the host adapter can be inserted into any host system's PCI/cPCI slot. In the United States, all optical GLMs, GBICs, 1x9 and small form factor transceivers sold by Emulex are certified as Class 1 laser products that conform to the requirements contained in the Department of Health and Human Services (DHHS) regulation 21 CFR subchapter J.
  • Page 19 Emulex Drivers, Software and Manuals In Europe, all optical GLMs, GBICs, 1x9 and small form factor transceivers sold by Emulex are certified as Class 1 laser component assemblies that conform to the requirements contained in the CENELEC (European Committee for Electrotechnical Standardization) standard EN60825−1:1994 (including...

  • Page 20: Product Information

    The power emitted from either an open fiber or open laser transmitter is guaranteed to be below the Class 1 limit. Class 1 laser products are not considered hazardous. No user Emulex Drivers, Software and Manuals...
  • Page 21 Class 1 limits established in the U. S. by the DHHS and within Europe by EN60825−1/EN60825−2. GBIC 1 x 9 Transceiver Small Form Factor Transceiver Emulex Drivers, Software and Manuals...
  • Page 22 Short wavelength and long wavelength GBICs allow normal data transmission on the optical link when they are connected to another compatible laser product. Short wavelength and long wavelength GBICs sold by Emulex as accessories are non−OFC devices. For non−OFC links, a compatible laser device must be non−OFC and certified as a Class 1 laser product.
  • Page 23 Class 1 limits. System Level Certification All GLMs and GBICs sold as accessories by Emulex or host adapters containing embedded 1x9 or small form factor transceivers are certified as Class 1 laser products within the U.S. and Class 1 laser component assemblies outside of the U.S.
