  • Page 1: Table Of Contents

    Emulex Drivers, Software and Manuals LP9002S Installation and Reference Manual Table of Contents Installation Compatability Prerequisites Install HBA Attach Media Apply Power View LEDs Reference Specifications FCC and Regulatory Notices Declaration of Conformity Laser Safety...

  • Page 2: Compatability

    Emulex Drivers, Software and Manuals Chapter 1 − Installation Table of Contents Compatability Prerequisites Install HBA Attach Media Apply Power View LEDs...

  • Page 3: Chapter 1 − Installation

    Maximum SBus clock rate of 25 MHz Media and connectors Note The LP9002S supports both a 32− and 64−bit bus, but not in all transfer modes. For 32−bit slave mode, both 4 byte or less and burst mode transfers are supported. For 32−bit DMA mode, only 4 byte or less transfers are supported.

  • Page 4: Install The Host Bus Adapter Board

    IEEE addresses. The IEEE address is used when configuring your system. The serial number is used when communicating with Emulex. All numbers are clearly marked on the board. We recommend that you record these numbers before installing the adapter.

  • Page 5: Attach Media

    Connect the fiber optic cable to the LC connector on the HBA. Connect the other end of the cable to the Fibre Channel device. After the media is connected to the host bus adapter, you are ready to apply power to the computer. Emulex Drivers, Software and Manuals Minimum Connector Length...

  • Page 6: Apply Power

    Fast blink (4 Hz) Flashing (irregular) Slow blink (1 Hz) Fast blink (4 Hz) Blink (1 Hz) Emulex Drivers, Software and Manuals State Wake−up failure (dead board) POST failure (dead board) Wake−up failure (dead board) Failure in POST (dead board)

  • Page 7: Specifications

    Emulex Drivers, Software and Manuals Chapter 2 − Reference Table of Contents Specifications FCC and Regulatory Notices Declaration of Conformity Laser Safety...
  • Page 8 TUV certified to EN60950 FCC Rules, Part 15, Class A Industry Canada, ICES−003, Class A EMC Directive 89/336/EEC (CE Mark) EN55022, Class A EN55024 Australian EMC Framework (C−Tick Mark) AS/NZS 3548: Class A VCCI, Class A Emulex Drivers, Software and Manuals...

  • Page 9: Fcc And Regulatory Notices

    APPAREIL A` LASER DE CLASSE 1 The above statement applies to products marketed in the European Union. Model LP9002 / LP9002L / LP952L / LP9002S / LP9002DC / LP9002C / LP9402DC (2x5 SFF Models) This device complies with Part 15 of the FCC Rules. Operation is subject to the...
  • Page 10 Consult the dealer or an experienced radio/TV technician for help. The reader is cautioned that any changes or modifications to the equipment not expressly approved by Emulex could void the user’s authority to operate this equipment. This class B digital apparatus meets all requirements of the Canadian Interference −...
  • Page 11 VCCI Notices and Translations (Japan Only) Note VCCI regulations provide that changes or modifications not expressly approved by Emulex Corporation could void your authority to operate this equipment. LP9000−N1/L1/T1 (GBIC Model): Translation: This is a Class B product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI).
  • Page 12 Emulex Drivers, Software and Manuals Manual Notice Translation: This is a Class A product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance may arise. When...

  • Page 13: Declaration Of Conformity

    Declaration of Conformity LP9002 / LP9002L / LP952L / LP9002S / LP9002C / LP9002DC / LP9402DC−F2 (2x5 SFF models) Note Changes or modifications not expressly approved by Emulex Corporation could void the user's authority to operate this equipment. This equipment complies with CISPR22/EN55022 Class A.
  • Page 14 − Australian EMC Framework (Carries the C−Tick mark accordingly) February 22, 2002 Costa Mesa, CA European Emulex Corporation Contact: 7 & 8 Forrest Court, Oaklands Park, Fishponds Road Wokingham, Berkshire, RG41 2FD, England Emulex Drivers, Software and Manuals Telephone: 44−118−977−2929 Fax: 44−118−977−3237...

  • Page 15: Laser Safety Notice

    In turn, the host adapter can be inserted into any host system's PCI/cPCI slot. In the United States, all optical GLMs, GBICs, 1x9 and small form factor transceivers sold by Emulex are certified as Class 1 laser products that conform to the requirements contained in the Department of Health and Human Services (DHHS) regulation 21 CFR subchapter J.
  • Page 16 Emulex Drivers, Software and Manuals In Europe, all optical GLMs, GBICs, 1x9 and small form factor transceivers sold by Emulex are certified as Class 1 laser component assemblies that conform to the requirements contained in the CENELEC (European Committee for Electrotechnical Standardization) standard EN60825−1:1994 (including...

  • Page 17: Product Information

    The power emitted from either an open fiber or open laser transmitter is guaranteed to be below the Class 1 limit. Class 1 laser products are not considered hazardous. No user Emulex Drivers, Software and Manuals...
  • Page 18 Class 1 limits established in the U. S. by the DHHS and within Europe by EN60825−1/EN60825−2. GBIC 1 x 9 Transceiver Small Form Factor Transceiver Emulex Drivers, Software and Manuals...
  • Page 19 Short wavelength and long wavelength GBICs allow normal data transmission on the optical link when they are connected to another compatible laser product. Short wavelength and long wavelength GBICs sold by Emulex as accessories are non−OFC devices. For non−OFC links, a compatible laser device must be non−OFC and certified as a Class 1 laser product.
  • Page 20 Class 1 limits. System Level Certification All GLMs and GBICs sold as accessories by Emulex or host adapters containing embedded 1x9 or small form factor transceivers are certified as Class 1 laser products within the U.S. and Class 1 laser component assemblies outside of the U.S.
