Summary of Contents for Emulex LPe1150 HBA

  • Page 1 LPe1150 HBA Installation Manual...
  • Page 2 Emulex Corporation for its use; or for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of Emulex Corporation.

  • Page 3: Table Of Contents

    Applying Power...5 Viewing the LEDs ... 5 POST Conditions and Results ... 5 References ... 7 Specifications ... 7 FCC and Regulatory Notices ... 8 Declaration of Conformity ... 9 Laser Safety Notice ...11 LPe1150 Hardware Installation Manual Page iii...

  • Page 4: Introduction

    Introduction The Emulex LPe1150 host bus adapter (HBA) is a single-channel, 4.25 gigabit per second (Gb/s), Fibre ® Channel (FC) Peripheral Component Interconnect Express (PCIe) HBA. The core technology of this HBA is Emulex’s eighth generation FC controller. The controller incorporates a multifunction native PCIe core that is compliant to the PCIe Base Specification 1.0a and PCI Express CEM Specification 1.0a.

  • Page 5: Compatibility

    • Host interface via Emulex standard drivers or through custom drivers written to the Emulex Service Level Interface (SLI-2) that is compatible with the many existing Emulex drivers for products such as LP8000, LP9002L, LP9802, LP10000 HBAs • Comprehensive array of operating system (OS) drivers: •...
  • Page 6 10. Secure the HBA's mounting bracket to the case with the panel screw or clip. 11. Replace the computer case and tighten case screws. The HBA is now installed in the PC and is ready for media attachment. LPe1150 Hardware Installation Manual 8 to change the bracket if –...

  • Page 7: Attaching Media

    Figure 2: Connecting Fiber Optic Cable 2. Connect the other end of the cable to the Fibre Channel device. After the media is connected to the HBA, you are ready to apply power to the computer. LPe1150 Hardware Installation Manual Minimum Length Connector .5 meters...

  • Page 8: Applying Power

    Slow Blink Fast Blink Flashing 1 Fast Blink 2 Fast Blinks 3 Fast Blinks Slow Blink LPe1150 Hardware Installation Manual Green LED Wake-up failure (Dead board) POST failure (Dead board) Wake-up failure monitor POST failure POST processing in progress Failure while functioning...
  • Page 9 Table 3: POST Conditions and Results (Continued) Yellow LED Slow Blink Slow Blink Fast Blink Slow Blink Flashing Slow Blink LPe1150 Hardware Installation Manual Green LED Off-line for download Restricted off-line mode (Waiting for restart) Restricted off-line mode (Test active) State Page 6...

  • Page 10: References

    References Specifications Table 4: LPe1150 Specifications Parameter Media Interface The controller interfaces to the physical media through an FC-0 Media Interface (FC-PI compliant transceiver), and then connects through dual optical fiber LC connectors. Physical Dimensions Low-profile MD2 form factor, 6.600 inches by 2.536 inches, and accommodates both the full-height and low-profile bracket.

  • Page 11: Fcc And Regulatory Notices

    The reader is cautioned that changes or modifications made to the equipment not expressly approved by Emulex could void the user's authority to operate this equipment. The above statement applies to products marketed in the USA.

  • Page 12: Declaration Of Conformity

    WARNING: This is a class A product. In a domestic environment, this product may cause radio interference requiring the user to take adequate measures. Note: Changes or modifications not expressly approved by Emulex Corporation could void the user's authority to operate this equipment.
  • Page 13 LPe1150 Hardware Installation Manual Page 10...

  • Page 14: Laser Safety Notice

    PCI/PCI-X expansion slot. In the United States, all optical small form factor transceivers sold by Emulex are certified as Class 1 laser products that conform to the requirements contained in the Department of Health and Human Services (DHHS) regulation 21 CFR subchapter J.

  • Page 15: Usage Restrictions

    Short wavelength and long wavelength small form factor transceivers embedded in Emulex host adapter are non-OFC. For non- OFC links, a compatible laser device must be non-OFC and certified as a Class 1 laser product.
  • Page 16 Copies of the certificate of conformity for any small form factor transceiver sold by Emulex can be obtained upon request from Emulex Corporation, Costa Mesa. LPe1150 Hardware Installation Manual Page 13...
