Summary of Contents for Emulex LP1005DC-CM2
- Page 1 LP1005DC-CM2 Installation Manual...
- Page 2 Emulex Corporation for its use; or for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of Emulex Corporation.
-
Page 3: Table Of Contents
Table of Contents Introduction ... 1 Major Features ... 1 Compatibility ... 2 Prerequisites ... 2 Installing the Host Bus Adapter ... 3 References ... 7 FCC and Regulatory Notices ... 7 Declaration of Conformity ... 9 Driver for Linux, Version 7.2 - Configuration Section Page iii... -
Page 4: Introduction
LP1005DC-CM2 is a dual-channel Fibre Channel (FC) PCI-X host bus adapter (HBA) ® designed specifically for operation in the IBM BladeCenter. The core technology of this HBA is Emulex's 6th generation FC controller, code-named Thor. The Thor controller incorporates a multi-function native PCI-X core that is compliant to the PCI and PCI-X local bus specifications. -
Page 5: Compatibility
PCI bus computer with a clock rate up to 66 MHz • PCI-X bus computer with a clock rate up to 133 MHz LP1005DC-CM2 Hardware Installation Manual • Windows SCSI FCP Miniport Driver for x86 host machines. This version also supports Windows Server 2003 32-bit. -
Page 6: Installing The Host Bus Adapter
Emulex. All numbers are clearly marked on the board. We recommend that you record these numbers before installation. Remove the Blade Server from the BladeCenter server bay in which you want to install the LP1005DC-CM2 HBA. - Page 7 If there is an I/O expansion card tray in that area (see the following illustration), go to step 7. Otherwise, you must install the tray; continue with step 6. Note: Remove any existing screws that will prevent the mounting bracket from flushly mounting on the Blade Server. LP1005DC-CM2 Hardware Installation Manual Page 4...
- Page 8 Note: If you are installing only one I/O expansion card in your HS40 Blade Server, it must be installed in the I/O expansion card location #2 (the slot further in from the edge). Align the LP1005DC-CM2 HBA with the tray as follows: •...
- Page 9 'Press to Install', gently press the HBA connector into the Server Blade connector. Close the Blade Server cover that you opened in step 3. Reinstall the Blade Server into the BladeCenter server bay. LP1005DC-CM2 Hardware Installation Manual Page 6...
-
Page 10: References
The reader is cautioned that changes or modifications made to the equipment not expressly approved by Emulex could void the user's authority to operate this equipment. The above statement applies to products marketed in the USA. - Page 11 This equipment is a Class A ITE, and operation of this equipment in a residential area is likely to cause harmful interference, in which case users will be required to correct the interference at their own expense. LP1005DC-CM2 Hardware Installation Manual Page 8...
-
Page 12: Declaration Of Conformity
WARNING: This is a class A product. In a domestic environment, this product may cause radio interference requiring the user to take adequate measures. Note: Changes or modifications not expressly approved by Emulex Corporation could void the user's authority to operate this equipment. - Page 13 LP1005DC-CM2 Hardware Installation Manual Page 10...
