Important Safety Instructions Pre-Installation When using your video equipment, basic safety Have space for this unit available on a flat clean surface such as precautions should always be followed, including the a large table or floor. The work area should be larger than the following: frame size.
Unpackaging the Frame: The frame will arrive in two separate cardboard boxes. One 3. Inside each box the frame pieces will be individually paper box will be very long and will house the top & bottom pieces. wrapped and taped. Remove all paper from pieces. The smaller cardboard box will house the side frame pieces, CAUTION: DO NOT USE A UTILITY KNIFE TO REMOVE hanger hardware, hardware required to put frame together...
Page 4
Frame Assembly (continued) 3. Assemble left side of frame to the top of frame. The large 4. Using a 5/64" allen wrench, tighten set screws in frame black metal L bracket will slide into the aluminum extrusion straightner bracket. Adjust set screw so that the front surfaces while the small L bracket will slide into the aluminum channel.
Page 5
Frame Assembly (continued) 6. Assemble right side of frame to the top of frame. This is done exactly the same way as the left side. When assembling the unit, route the motor wire behind bracket as shown and attach field wiring box to side of frame (Figure 6 and 7). Assemble bottom of frame to the right and left sections of frame.
Two small L brackets included will be used to hold frame securley to wall at bottom. 2. To install the Dual Format lmager over a Da-Lite Perm-Wall screen you will need to place the supplied wooden spacers between the screen and the wall.
Page 7
Wall Mounting Assembly (continued) 6. Hang the frame assembly on the hanger brackets as shown in image. Carefully slide bracket between the top of the frame extrusion and the roller assembly. There is a lip on the back of the frame that wedges itself into the hanger bracket once fully installed on bracket.
Page 8
120V Wiring Diagram for Standard Wall Switch NOTE: Junction box located on left upper side of frame Note: A single switch cannot be used to operate more than one screen. Contact Da-Lite for further information. White Black Motor Green AC Common...
Post Installation Procedures Travel Adjustments: Test installation by carefully running mask surface up and Masking travel is stopped automatically in the up and down down 2-3 times. Be prepared to stop screen. Standard Duty positions by limit switches that are properly adjusted at the Cycle: 1 MIN.
Troubleshooting Symptom Cause Solution Verify 115-125V (or 220-240V). If insufficient voltage, rewire Incorrect line voltage. incoming electric line. Blown fuse. Replace fuse. Tripped circuit breaker. Reset circuit breaker. Masking System will not operate. Motor does not hum. Check above. Tighten all loose wire connections. Correct any improper connections.
Page 12
OF EQUIPMENT, OR FOR INCIDENTAL, DIRECT, OR CONSEQUENTIAL DAMAGES OF ANY NATURE. In the event that there is a defect in materials or workmanship of a Da-Lite product, you may contact our Sales Partners at PO Box 137, Warsaw, IN 46581-0137, (574) 267-8101, (800) 622-3737.
