CHIEF FWD-111 Installation Instructions Manual

Flat panel dual swing arm wall mount

Advertisement

Quick Links

I N S T A L L A T I O N
Flat Panel
Dual Swing Arm Wall Mount
FWD-111
The FWD-111 dual arm wall mount was designed to support
flat panel displays with 10" to 30" diagonal screens and
weighing a maximum of 40 lbs (18.1 kg).
At only 2.15" deep in the closed position, the mount allows
side-to-side pivot adjustment up to 180 degrees in the closed
and the fully extended position. A display can be extended
14.2" from the wall and pivot 360 degrees.
The FWD-111 fits the following VESA® patterns:
• 75mm/75mm (using the Centris™ mount)
• 100mm/100mm (using the Centris mount)
• 200mm/100mm (using the interface bracket with the
Centris mount)

BEFORE YOU BEGIN

• Caution: To prevent damage to the FWD-111, which could affect or void the Factory warranty, and to the
equipment that will be attached to it, thoroughly study all instructions and illustrations before you begin
the installation. Pay particular attention to the "Important Warnings and Cautions" on Page 2.
• The maximum weight to be installed on the FWD-111 wall mount is 40 pounds (18.1 kg).
• The FWD-111 wall mount is designed to be installed using wall studs or supporting framework. The structure to
which the FWD-111 wall mount is anchored must be capable of supporting five times the total weight of the mount
and all attached equipment.
• If you have any questions about this installation, contact Chief Manufacturing at 1-800-582-6480.
CHIEF MANUFACTURING INC.
1-800-582-6480 952-894-6280 FAX 952-894-6918
8401 EAGLE CREEK PARKWAY STE. 700
SAVAGE, MINNESOTA 55378 USA
I N S T R U C T I O N S
PART NO. 8832-000132
©2005 Chief Manufacturing
www.chiefmfg.com
10/05

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FWD-111 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CHIEF FWD-111

  • Page 1: Before You Begin

    • The FWD-111 wall mount is designed to be installed using wall studs or supporting framework. The structure to which the FWD-111 wall mount is anchored must be capable of supporting five times the total weight of the mount and all attached equipment.
  • Page 2: Important Warnings And Cautions

    • WARNING: The installer is responsible for verifying that the wall to which the FWD-111 is anchored will safely sup- port the combined load of all attached components or other equipment. • WARNING: The weight of the display placed on the FWD-111 must not exceed 40 lbs. (18.1 kg), the maximum load capacity of the FWD-111.
  • Page 3: Table Of Contents

    Install FWD-111 on Wall Bracket ......Flush Mount – 75mm/100mm Pattern....Carefully inspect the FWD-111 for shipping damage. If any damage is apparent, call your carrier claims agent and Recessed Mount – 75mm/100mm Pattern .... do not continue with the installation until the carrier has 200mm/100mm Pattern .........
  • Page 4: Components

    Installation Instructions FWD-111 COMPONENTS Figure 1. FWD-111 Components...
  • Page 5: Parts

    Installation Instructions FWD-111 PARTS Table 1: Parts ITEM NUMBER DESCRIPTION NOTES WALL MOUNT PHILLIPS PAN HEAD MACHINE SCREW, M4 x 12mm FLUSH MOUNT PHILLIPS PAN HEAD MACHINE SCREW, M4 x 30mm (USE WITH 40)* 3/4” NYLON SPACER RECESSED MOUNT PHILLIPS PAN HEAD MACHINE SCREW, M4 x 20mm (USE WITH 60)** 3/8”...
  • Page 6: Installation

    FWD-111 INSTALLATION Secure Wall Bracket WARNING: It is the responsibility of the installer to ver- ify that the surface to which the FWD-111 is anchored will safely support the combined load of all attached components and equip- ment. Install the FWD-111 as follows: Determine the exact mounting location prior to installa- tion, considering the unit’s swing and extension radius.
  • Page 7: Install Fwd-111 On Wall Bracket

    Install FWD-111 on Wall Bracket Install the FWD-111 on the wall bracket by placing the top of the FWD-111 over the top of the wall bracket and push- ing the bottom of the FWD-111 over the bottom of the wall bracket (see Figure 5).
  • Page 8: Flush Mount - 75Mm/100Mm Pattern

    Secure the mount to your display using the four screws (30 or 50) that were selected in step 1. 40 or 60 Perform the procedure to “Install FWD-111 on Wall Bracket” on page 7. Proceed to “CABLE MANAGEMENT” on page 10 and the “ADJUSTMENTS”...
  • Page 9: 200Mm/100Mm Pattern

    Installation Instructions FWD-111 200mm/100mm Pattern To mount the display using the 200mm x 100mm mounting hole pattern, do the following: Attach interface bracket (70) to the display using six M4 x 12mm flat head screws (80). See Figure 10. Start two M4 x 5mm Phillips pan head screws (90) into the top two mounting holes of the display (see Figure 11).
  • Page 10: Cable Management

    Installation Instructions FWD-111 CABLE MANAGEMENT WARNING: Make sure your cables do not run through a pinch point. Connect and secure power/audio/video cables, making sure to leave sufficient slack to allow for movement of the display. Route power/audio/video cables under each arm, allowing...
