I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation Small Flat Panel Steel Stud Wall Mount Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description FWGSK110...
FWGSK110 Installation Instructions DISCLAIMER WARNING: Failure to read, thoroughly understand, and CSAV, Inc., and its affiliated corporations and subsidiaries follow all instructions can result in serious personal injury, (collectively, "CSAV"), intend to make this manual accurate and damage to equipment, or voiding of factory warranty! It is the complete.
Page 3
Installation Instructions FWGSK110 TOOLS REQUIRED FOR INSTALLATION AND PARTS 3/16" 1/2" (Ø13mm) 5/32" A (1) [flat panel wall mount] C (1) [cable management cover] D (4) B (2) M4 x 20 #8-32 X 3/8" E (4) M4 x 12 F (4) 1/2"...
FWGSK110 Installation Instructions Site Requirements WARNING: IMPROPER INSTALLATION CAN LEAD TO EQUIPMENT FALLING CAUSING SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT! The figure below identifies the minimum reguirements for installation of display mounts onto a steel stud structure. If the structure or its components do not meet these requirements contact the mount manufacturer for specific instructions before attempting installation.
Installation Instructions FWGSK110 Mount Installation After determining the site meets the installation requirements: Drywall Identify desired mounting location on wall. Using a stud finder or similar method locate studs. Align mounting holes in mount with studs making sure Plastic Straps mounting holes are centered on studs.
FWGSK110 Installation Instructions Display Installation The mounting holes on the back of your display will either be Steel Stud flush with the back surface, or recessed into the back surface. Drywall Refer to the applicable installation procedure. Flush Mount Display...
Installation Instructions FWGSK110 Select proper length spacer and screw. (See Figure 8) NOTE: All spacers used should be the same length. If the recess depths result in multiple spacer lengths, then select the longer spacer. Place the four selected spacers over each of the mount holes on the back of the display.
Page 8
FWGSK110 Installation Instructions Adjustment Screw Cable Path (typical) (C) x 1 Figure 13 Centris Head If previously attached, disconnect cables from display, then (E) x 3 remove display. Using Phillips screwdriver, slightly loosen or tighten the adjustment screw as necessary (See Figure 14).
Page 12
