- Page 1 Grandstream Networks, Inc. GXV3240/3275 BroadWorks Xsi Directories and Call Logs Guide GXV3240/3275 BroadWorks Xsi Directories and Call Logs Guide...
-
Page 2: Table Of Contents
GXV3240/3275 BroadWorks Xsi Directories and Call Logs Guide Index INTRODUCTION ..................3 BROADWORKS XTENDED SERVICES INTRODUCTION ......4 XSI ARCHITECTURE AND MESSAGEING ..................4 BROADWORKS XSI DIRECTORY AND CALL LOGS CONFIGURATION 6 BROADWORKS SERVER CONFIGURATION ..................6 GXV PHONE CONFIGURATION ......................6 XSI AUTHENTICATION WITH BROADWORKS USER LOGIN CREDENTIALS ...... - Page 3 Table of Figures GXV3240/3275 BroadWorks Xsi Directories and Call Logs Guide Figure 1: Xsi-Actions Requests Response ....................4 Figure 2: Broadsoft Xsi Configuration with BroadWorks User Login Credentials ......... 7 Figure 3: Broadsoft Xsi Configuration with SIP Authentication Credentials ..........9 Figure 4: GXV32xx Contacts Page ......................
-
Page 4: Gxv3240/3275 Broadworks Xsi Directories And Call Logs Guide
Grandstream GXV3240/GXV3275 IP Multimedia phone supports the BroadWorks Xtended Services Interfaces (Xsi) Directories and Call Log features. This User Guide will describe how to configure and use the BroadWorks Xsi Directories and Call Logs features on GXV3240/GXV3275. To learn more about GXV3240/GXV3275 features, please visit http://www.grandstream.com/support... -
Page 5: Broadworks Xtended Services Introduction
When an HTTP requests is received from the remote application and successfully authenticated, then the request is processed by the BroadWorks core and an appropriate response is generated. Figure 1: Xsi-Actions Requests Response GXV3240/3275 BroadWorks Xsi Directories and Call Logs Guide Page 4 of 19... - Page 6 The BroadWorks Xsi Directories and Xsi Call Logs feature allows user to access the phonebook and call log entries managed by BroadWorks Servers via the Xsp server. GXV3240/3275 BroadWorks Xsi Directories and Call Logs Guide Page 5 of 19...
-
Page 7: Broadworks Xsi Directory And Call Logs Configuration
For example, the Group Directory’s default name is “Group” if it keeps blank. If the user fills “Grandstream” into the blank, the phone will display “Grandstream” for the Group Directory. GXV3240/3275 BroadWorks Xsi Directories and Call Logs Guide Page 6 of 19... -
Page 8: Figure 2: Broadsoft Xsi Configuration With Broadworks User Login Credentials
The following figure shows an example of how to configure the Broadsoft Xsi Directories and Call Log settings on the GXV3240/GXV3275 phones. Figure 2: Broadsoft Xsi Configuration with BroadWorks User Login Credentials GXV3240/3275 BroadWorks Xsi Directories and Call Logs Guide Page 7 of 19... -
Page 9: Xsi Authentication With Sip Authentication Credentials
If the user fills “Grandstream” into the blank, the phone will display “Grandstream” for the Group Directory. The following figure shows an example of how to configure the Broadsoft Xsi Directories with SIP Authentication Credentials on the GXV3240/GXV3275 phones. GXV3240/3275 BroadWorks Xsi Directories and Call Logs Guide Page 8 of 19... -
Page 10: Broadworks Xsi Directories
Figure 3: Broadsoft Xsi Configuration with SIP Authentication Credentials BROADWORKS XSI DIRECTORIES After configuring the phone as the steps above, users can use Broadsoft Xsi Directories features on GXV phones. Please do as the following steps: GXV3240/3275 BroadWorks Xsi Directories and Call Logs Guide Page 9 of 19... -
Page 11: Figure 4: Gxv32Xx Contacts Page
1. On the phone idle screen or menu, open Contacts app by tapping on icon , or on the phone idle screen/menu screen, tap on icon on the bottom of the screen. (GXV3240 also can access the contacts page by pressing the key on the keypad) Figure 4: GXV32xx Contacts Page 2. -
Page 12: Figure 5: Broadworks Contacts Page
Personal, Group Common, Group, Enterprise Common, Enterprise, respectively. 3. If the Contact page displays “Request error, recheck configuration”, please check the BroadWorks Xsi configuration, or request technical assistance from the service provider. GXV3240/3275 BroadWorks Xsi Directories and Call Logs Guide Page 11 of 19... -
Page 13: Figure 6: Request Error On Broadworks Contacts Page
Figure 6: Request Error on BroadWorks Contacts Page If the Contact page displays “This item is disabled”, please enable the contact category on the WebUI. Figure 7: Disable Contact Category on BroadWorks Contacts Page GXV3240/3275 BroadWorks Xsi Directories and Call Logs Guide Page 12 of 19... -
Page 14: Figure 8: Broadworks Contact Dialing
PSTN number; the latter one, after the “-”, is the extension number. For this kind of entries, the phone allows user to select the string for dialing after tapping the icon. GXV3240/3275 BroadWorks Xsi Directories and Call Logs Guide Page 13 of 19... -
Page 15: Figure 9: Selecting Number On Broadworks Contact Dialing Page
Figure 9: Selecting Number on BroadWorks Contact Dialing Page 6. GXV3240/GXV3275 is able to search the contact entries in Group Directory, Enterprise and Enterprise Common Directories. The following figure shows that the user types “david” to search the contact whose name including the string “david” in the Enterprise Directory. The phone will show the matched results. -
Page 16: Broadworks Xsi Call Logs
Figure 10: BroadWorks Xsi Directory Searching and Results BROADWORKS XSI CALL LOGS After configuring the phone, users can use Broadsoft Xsi Call Logs features on GXV3240/GXV3275. Please follow the steps: 1. Tap on phone's menu or idle screen if call history shortcut is created on the desktop. Or tap on the bottom of the idle screen or menu screen. -
Page 17: Figure 11: Call History Page
Figure 11: Call History Page 2. Tap the icon to enter the BroadWorks Call Log page. Figure 12: BroadWorks Call Log Page GXV3240/3275 BroadWorks Xsi Directories and Call Logs Guide Page 16 of 19... - Page 18 6. GXV3240/GXV3275 is able to sort the BroadWorks Call Logs by name or time. The call logs are displayed in chronological order, the most recent first, by default.
-
Page 19: Figure 13: Sorting On Broadworks Call Log Page
Figure 13: Sorting on BroadWorks Call Log Page 7. GXV3240/GXV3275 supports to delete the call log entries by sending HTTP requests and sync it with the BroadWorks server. Long pressing the selected entry to highlight it and then tap at the upper right corner to delete it. -
Page 20: Figure 14: Selecting Call Logs On Broadworks Call Log Page
Figure 14: Selecting Call Logs on BroadWorks Call Log Page Users also can select multiple call logs or taping upper left corner to select all logs and delete them. Figure 15: Selecting All Call Logs GXV3240/3275 BroadWorks Xsi Directories and Call Logs Guide Page 19 of 19...
