- Page 1 Grandstream Networks, Inc. GXV3240 IP Multimedia Phone for Android Bluetooth User Guide GXV3240 Bluetooth User Guide...
-
Page 2: Table Of Contents
Index INTRODUCTION ................... 3 CONNECT TO BLUETOOTH ............... 4 TURN ON/OFF BLUETOOTH......................4 PAIR GXV3240 WITH A BLUETOOTH DEVICE .................. 5 UNPAIR A BLUETOOTH DEVICE ....................... 7 BLUETOOTH CONFIGURATIONS .............. 8 CHANGE BLUETOOTH DEVICE NAME FOR GXV3240 ..............8 CONFIGURE VISIBILITY TIMEOUT ....................9 GXV3240 BLUETOOTH FEATURE - HEADSET MODE ...... - Page 3 Figure 6: Paired Device Details ........................7 Figure 7: Rename Option ..........................8 Figure 8: Enter New Name For Bluetooth Device ..................9 Figure 9: GXV3240 Bluetooth Visible to Nearby Bluetooth Devices ............10 Figure 10: Visibility Timeout Option ......................10 Figure 11: Select Visibility Timeout......................11 Figure 12: Enable Headset Mode ......................
-
Page 4: Gxv3240 Bluetooth User Guide
GXV3240 from mobile devices using Bluetooth hands-free profile, and listen to media (music or other audio output) from the GXV3240. This document serves as an end user guide on how to use Bluetooth feature on the GXV3240. To learn more about GXV3240's basic and advanced features, please visit http://www.grandstream.com/support... -
Page 5: Connect To Bluetooth
CONNECT TO BLUETOOTH To connect to a Bluetooth device, turn on GXV3240’s Bluetooth radio first. The first time when using a new Bluetooth device with the GXV3240, "pair" the device with GXV3240 so that both devices know how to connect securely to each other. After that, users could simply connect to a paired device. -
Page 6: Pair Gxv3240 With A Bluetooth Device
5. Tap on the GXV3240 Bluetooth device name to make it visible to all nearly Bluetooth devices. 6. The GXV3240 scans and displays the IDs of all available Bluetooth devices within the range. If the device you would like to pair with does not show up in the list, ensure that the other device is turned on and set to be discoverable. -
Page 7: Figure 3: Search For Devices
Bluetooth device you are connected to or other procedures to obtain the passcode. Figure 4: Input Bluetooth Pairing Passcode 10. The paired device will be displayed in Bluetooth Settings screen. GXV3240 Bluetooth User Guide Page 6 of 14... -
Page 8: Unpair A Bluetooth Device
Figure 5: Paired Device UNPAIR A BLUETOOTH DEVICE 1. On the GXV3240 LCD Bluetooth Settings screen (see ), tap on the [Figure 5: Paired Device] paired/connected Bluetooth device. 2. Users will see the details for the paired/connected device. -
Page 9: Bluetooth Configurations
BLUETOOTH CONFIGURATIONS CHANGE BLUETOOTH DEVICE NAME FOR GXV3240 The GXV3240 uses "GXV3240" as Bluetooth device name by default. The device name will be visible to other devices when pairing/connecting them. Follow the steps below to change the Bluetooth device name. -
Page 10: Configure Visibility Timeout
3. Select Wireless & Network. Make sure Bluetooth is turned on. 4. Tap on Bluetooth settings. 5. Tap on device name (by default it's GXV3240) and the visible time will start to count down from the configured timeout value. GXV3240 Bluetooth User Guide... -
Page 11: Figure 9: Gxv3240 Bluetooth Visible To Nearby Bluetooth Devices
Figure 9: GXV3240 Bluetooth Visible to Nearby Bluetooth Devices 6. To adjust the visible time of the GXV3240 Bluetooth, press Menu button under Bluetooth Settings screen. 7. Tap on Visibility timeout. Figure 10: Visibility Timeout Option 8. Select the interval you would like to set for the visibility timeout. Scroll up/down to view all timeout options. -
Page 12: Figure 11: Select Visibility Timeout
Figure 11: Select Visibility Timeout GXV3240 Bluetooth User Guide Page 11 of 14... -
Page 13: Gxv3240 Bluetooth Feature - Headset Mode
GXV3240 will show the BT profile for the connected cell phone on the idle screen account widget. Additionally, when using the GXV3240 dial pad to make a call from the BT profile, the dial pad will show the contact information from the connected cell phone dynamically with the entered digits. This feature is known as predictive dialing. -
Page 14: Predictive Dialing
When the GXV3240 and the Bluetooth device (cell phone) are being connected, usually a prompt will pop up on the Bluetooth device (cell phone) to confirm whether or not to allow the GXV3240 to access the cell phone's contacts. If it's allowed, the GXV3240 can show predictive dialing list which is the cell phone's contacts information when users enter the digits in the GXV3240 dial pad. -
Page 15: Answer Call
ANSWER CALL 1. When there is an incoming call to the cell phone, both the cell phone and the GXV3240 will ring at the same time. 2. Answer the call on the GXV3240. SWITCH DEVICE DURING CALL When calling out or during the call, users can switch the device to be used for the call. This can be done on the cell phone device.
