Master Bilt QMVM-36 Specification Sheet

QMVM-48E
FEATURES
NEW
STANDARD TEXTURED FINISH
Standard Black also
white available
CONSTRUCTION
• Standard electronic controller with
these features:
– Ability to monitor defrost functions
from the front panel interface
– Audible and visual alarm
– Eliminates room thermostat,
defrost termination/fan delay
control, defrost timer and digital
thermometer or other temperature
indicator
• 24 gauge painted textured galva-
nized steel exterior and interior
• Stainless steel floor pans (removable
for easy service)
Standard cord
and plug on
QMVM-36E and
QMVM-48E
models
• 2" foamed-in-place "zero ODP"
urethane insulation
• Shelves adjustable in 1" increments
• Three lighted tiers of two-position
shelving with price tag molding
• Perforated interior back wall and top
for better air flow
• Electric defrost
• Easily accessible electrical enclosure
REFRIGERATION
• Refrigerant: R-404A
• Front air intake and rear air discharge
• Self-contained, bottom mount
refrigeration system
• Minimum of 6" clearance between
cabinet back and wall and a clear-
ance of 10" at top
• Temp. range: 34° to 41°F (1° to 5°C)
• R-factor (insulation efficiency rating):
17.24
• Drain plumbing hookup recom-
mended. Condensate pan available
if there is no access to drain plumb-
ing. Condensate pan must be field
installed and requires a dedicated
15 amp, 120 volt circuit.
908 Highway 15 North • New Albany, MS 38652
PHONE: 800-647-1284 or 662-534-9061 • FAX: 800-232-3966 or 662-534-6049 • www.master-bilt.com
ITEM NO. ______________________________________________________
PROJECT ______________________________________________________
LOCATION _____________________________________________________
DATE _________________________ QTY. ___________________________
QMVM SERIES
Quantum Series
Medium Temp
Vertical Open Display
Merchandisers
MODELS
❑ QMVM-36E
❑ QMVM-48E
❑ QMVM-72E
WARRANTY
• Standard limited three year extend-
ed compressor and two year limited
parts and labor
OPTIONS
❑ Add suffix "R" for remote system
❑ Add suffix "ESS" for stainless steel
interior and exterior
❑ Custom exterior colors
❑ Condensate evaporator drain pan
❑ Condensate pump
❑ Product hooks
❑ Casters
❑ Extra lighted shelves (one only)
❑ Extra non-lighted shelves
❑ 1" vinyl bumper in choice of black,
❑ Vinyl retractable night curtain
❑ Locking metal night curtain (less
(QMVM-48E and -72E only)
NOTE: Must be field installed and
requires a dedicated 15A, 120v
circuit.
blue, brown, green, red or white
locks)
