F3X25 Series Router
User Manual
F3X25 Series Router User Manual
The user manual is suitable for the following model:
Documentation No.
Product Name：
Model
F3125
F3225
F3325
F3425
F3525
F3625
F3725
LTE/TD-SCDMA ROUTER
F3825
F3A25
Xiamen Four-Faith Communication Technology Co., Ltd.
Add：J1-J3,3rd Floor,No.44,GuanRi Road,SoftWare
Park,XiaMen,China
Tel：+86 592-6300326 ，6300325，6300324
Fax:+86 592-5912735
http://www.fourfaith.co
Product Version
Product Type
GPRS ROUTER
CDMA ROUTER
EDGE ROUTER
WCDMA ROUTER
TD-SCDMA ROUTER
EVDO ROUTER
LTE/WCDMA ROUTER
LTE/EVDO ROUTER
Zip Code:361008
Page
Total:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F3125 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Four-Faith F3125

Summary of Contents for Four-Faith F3125

  • Page 1 CDMA ROUTER F3325 EDGE ROUTER F3425 WCDMA ROUTER F3525 TD-SCDMA ROUTER F3625 EVDO ROUTER F3725 LTE/TD-SCDMA ROUTER F3825 LTE/WCDMA ROUTER F3A25 LTE/EVDO ROUTER Xiamen Four-Faith Communication Technology Co., Ltd. Add：J1-J3,3rd Floor,No.44,GuanRi Road,SoftWare Park,XiaMen,China Zip Code:361008 Tel：+86 592-6300326 ，6300325，6300324 Fax:+86 592-5912735 http://www.fourfaith.co...
  • Page 2 F3X25 Series Router User Manual Files Revised Record Date Version Remark Author 2012-09-16 V1.00 Initial Draft 2012-11-1 V1.01 Add Packet Filter Xiamen Four-Faith Communication Technology Co.,Ltd. Page 2 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...

  • Page 3: Copyright Notice

    Four-Faith Communication Technology Co., Ltd. Without written permission, all commercial use of the files from Four-Faith are forbidden, such as copy, distribute, reproduce the files, etc., but non-commercial purpose, downloaded or printed by individual (all files shall be not revised, and the copyright and other proprietorship notice shall be reserved) are welcome.
  • Page 4 F3X25 Series Router User Manual Xiamen Four-Faith Communication Technology Co.,Ltd. Page 4 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...

  • Page 5: Table Of Contents

    NAT ........................50 3.3.6.1 Port Forwarding ..................50 3.3.6.2 Port Range Forward ................50 3.3.6.3 Port Triggering ..................51 Xiamen Four-Faith Communication Technology Co.,Ltd. Page 5 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...
  • Page 6 WAN ....................62 3.3.10.3 LAN....................63 3.3.10.4 Bandwidth ..................66 3.3.10.5 Sys-Info ................... 67 Chapter 4 Appendix ........................69 Xiamen Four-Faith Communication Technology Co.,Ltd. Page 6 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...

  • Page 7: Chapter 1 Brief Introduction Of Product

     Support hardware and software WDT  Support auto recovery mechanism, including online detect, auto redial when offline to make router always online  Ethernet port: 1.5KV magnetic isolation protection Xiamen Four-Faith Communication Technology Co.,Ltd. Page 7 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
  • Page 8  Full protocol support , such as TCP/IP, UDP, ICMP, SMTP, HTTP, POP3, OICQ, TELNET, FTP, SNMP, SSHD, etc.  Schedule Reboot, Schedule Online and Offline,etc. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 8 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 9: Working Principle

    GSM850/900/1800/1900MHz <33dBm GPRS/EDGE Class 12 GSM1800/1900： <30dBm F3425 WCDMA&HSDPA&HSUPA ROUTER UMTS/WCDMA/HSDPA/HSUPA HSUPA:5.76Mbps <24dBm <-109 /HSPA+ 850/1900/2100MHz (Upload speed) Xiamen Four-Faith Communication Technology Co.,Ltd. Page 9 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...
  • Page 10 F3825 LTE/WCDMA ROUTER LTE FDD LTE(DL:100Mbps,UL <32dBm <-93.3dBm 2600/2100/1800/900/800MHz, :50Mbps) 700/1700/2100MHz(optional) HSUPA:5.76Mbps(Up load speed) HSPA+/HSDPA/HSUPA/WCDM HSDPA:7.2Mbps(Do /UMTS900/2100MHz, wnload speed) Xiamen Four-Faith Communication Technology Co.,Ltd. Page 10 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...
  • Page 11 Standard 3V/1.8V user card interface, 15KV ESD protection Power Standard 3-PIN power jack, reverse-voltage and overvoltage protection Reset Restore the router to its original factory default settings Xiamen Four-Faith Communication Technology Co.,Ltd. Page 11 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：...
  • Page 12 440g Environmental Limits Item Content -35~+75º C（-31~+167℉） Operating Temperature Storage -40~+85º C（-40~+185℉） Temperature Operating 95% ( Non-condensing) Humidity Xiamen Four-Faith Communication Technology Co.,Ltd. Page 12 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...

  • Page 13: Chapter 2 Installation Introduction

    Power adapter Manual CD Certification card Maintenance card 2.3 Installation and Cable Connection Installation of SIM/UIM card: Xiamen Four-Faith Communication Technology Co.,Ltd. Page 13 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...
  • Page 14 The signal definition of the DB9F serial communication interface is as follows: RS232 signal name The direction for Router output output Xiamen Four-Faith Communication Technology Co.,Ltd. Page 14 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324...

  • Page 15: Power

    SIM/UIM card does not work or the signal of the antenna is week Signal One Light Signal strength is weak Strength Xiamen Four-Faith Communication Technology Co.,Ltd. Page 15 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324...

  • Page 16: Reset Button Introduction

    The router has a “Reset” button to restore it to its original factory default settings. When user press the “Reset” button for up to 15s, the router will restore to its original factory default settings and restart automatically. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 16 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...

  • Page 17: Chapter 3 Configuration And Management

    Users have to click "change password" to make it work if they modify user name and password. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 17 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
  • Page 18 F3X25 Series Router User Manual After access to the information main page Users need to input user name and password if it is their first time to login. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 18 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 19: Management And Configuration

    ISP, if required. 3.3.1.1 Basic Setting WAN Connection Type Seven Ways: Disabled, 3G/UNMTS/4G/LTE Disabled Xiamen Four-Faith Communication Technology Co.,Ltd. Page 19 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...
  • Page 20 Route: Detect connection with route method, when choose this method, users should also configure "Detection Interval", "Primary Detection Server IP" and "Backup Detection Server IP" items. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 20 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
  • Page 21 Domain Name: ISP provides MTU: auto (1500) and manual (1200-1492 in PPPOE/PPTP/L2TP mode, 576-16320 in other modes) Router Internal Network Settings Router IP Xiamen Four-Faith Communication Technology Co.,Ltd. Page 21 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324...
  • Page 22 DNS, and make sure no other DHCP server in the network. DHCP Type: DHCP Server and DHCP Forwarder Enter DHCP Server if set DHCP Type to DHCP Forwarder as blow: Xiamen Four-Faith Communication Technology Co.,Ltd. Page 22 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
  • Page 23 To adjust time by the system and refresh to get the time of the web, user can set to modify the time of the system. They can change to adjust time by manual to achieve adjust time by the system if the system fails to get NTP server Xiamen Four-Faith Communication Technology Co.,Ltd. Page 23 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...

  • Page 24: Dynamic Dns

    IP address, and will forward traffic directed at their domain to their frequently-changing IP address. DDNS Service: Four-Faith router currently support DynDNS, freedns, Zoneedit, NO-IP, 3322, easyDNS, TZO, DynSIP and Custom based on the user. User Name: users register in DDNS server, up to 64 characteristic...

  • Page 25: Clone Mac Address

    Dynamic Routing Dynamic Routing enables the router to automatically adjust to physical changes in the network's layout and exchange routing tables with other routers. The router determines the network packets’ Xiamen Four-Faith Communication Technology Co.,Ltd. Page 25 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
  • Page 26 WAN (Internet), or Loopback (a dummy network in which one PC acts like a network, necessary for certain software programs) Show Routing Table Xiamen Four-Faith Communication Technology Co.,Ltd. Page 26 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 27: Services

    LAN Domain: users can define here their local LAN domain which is used as local domain for DNSmasq and DHCP service if chose above. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 27 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
  • Page 28 DHCP server IP range: dhcp-range=192.168.0.110,192.168.0.111,12h SNMP Location: equipment location Contact: contact this equipment management Name: device name Xiamen Four-Faith Communication Technology Co.,Ltd. Page 28 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324...
  • Page 29 Telnet: enable a telnet server to connect to the router with telnet. The username is and the password is the router's password. Note: If users use the router in an untrusted environment (for example as a public hotspot), it is Xiamen Four-Faith Communication Technology Co.,Ltd. Page 29 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 30: Pppoe Server

    MPPE PPPoE Encryption: enable or disable MPPE PPPoE Encryption Session Limit per MAC: default is 10 LCP Echo Interval: time interval to set the the LCP calibration phase response Xiamen Four-Faith Communication Technology Co.,Ltd. Page 30 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...

  • Page 31: Vpn

    3.3.3 VPN 3.3.3.1 PPTP PPTP Server Xiamen Four-Faith Communication Technology Co.,Ltd. Page 31 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324...
  • Page 32 Note: client IP must be different with IP assigned by router DHCP. The format of CHAP Secrets is user * password *. PPTP Client Server IP or DNS Name: PPTP server’s IP Address or DNS Name Xiamen Four-Faith Communication Technology Co.,Ltd. Page 32 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 33: L2Tp

    CHAP Secrets: user name and password of the client using L2TP service Note: client IP must be different with IP assigned by router DHCP. The format of CHAP Secrets is user * password *. L2TP Client Xiamen Four-Faith Communication Technology Co.,Ltd. Page 33 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 34: Openvpn

    Start Type: WAN UP----start after on-line, System----start when boot up Config via: GUI----Page configuration, Config File----config File configuration Server mode: Router (TUN)-route mode, Bridge (TAP)----bridge mode Router (TUN): Xiamen Four-Faith Communication Technology Co.,Ltd. Page 34 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
  • Page 35 Tunnel Protocol: UCP or TCP of OPENVPN tunnel protocol Encryption Cipher: Blowfish CBC，AES-128 CBC，AES-192 CBC，AES-256 CBC，AES-512 Hash Algorithm: Hash algorithm provides a method of quick access to data, including SHA1， SHA256，SHA512，MD5 Advanced Options Xiamen Four-Faith Communication Technology Co.,Ltd. Page 35 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：...
  • Page 36 Client connect script: define some client script by user self CA Cert: CA certificate Public Server Cert: server certificate Private Server Key: the key seted by the server DH PEM: PEM of the server Xiamen Four-Faith Communication Technology Co.,Ltd. Page 36 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：...
  • Page 37 Encryption Cipher: Blowfish CBC，AES-128 CBC，AES-192 CBC，AES-256 CBC，AES-512 Hash Algorithm: Hash algorithm provides a method of quick access to data, including SHA1, SHA256, SHA512, MD5 nsCertType verification: support ns certificate type Xiamen Four-Faith Communication Technology Co.,Ltd. Page 37 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
  • Page 38 Additional Config: additional configurations of OPENVPN server Policy based Routing: input some defined routing policy CA Cert: CA certificate Public Client Cert: client certificate Private Client Key: client key Xiamen Four-Faith Communication Technology Co.,Ltd. Page 38 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：...

  • Page 39: Ipsec

    Type: to choose IPSEC mode and relevant functions in this part, supports tunnel mode client, tunnel mode server and transfer mode currently Connection: this part contains basic address information of the tunnel Xiamen Four-Faith Communication Technology Co.,Ltd. Page 39 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
  • Page 40 Timeout: set the timeout of connect detection Action: set the action of connect detection Advanced Settings: this part contains relevant setting of IKE, ESP, negotiation mode, etc. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 40 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 41: Gre

    (such as IP and IPX) data packets are encapsulated, so these encapsulated data packets to another network layer protocol (IP)transmission. GRE Tunnel (tunnel) technology, Layer Two Tunneling Protocol VPN (Virtual Private Network). Xiamen Four-Faith Communication Technology Co.,Ltd. Page 41 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
  • Page 42 Interval：The time interval of GRE keepalive packet sent Fail Action：The action would be exec after keeping alive failed Click on “View GRE tunnels” keys can view the information of GRE Xiamen Four-Faith Communication Technology Co.,Ltd. Page 42 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...

  • Page 43: Security

    Filter ActiveX: If refuse to ActiveX, you may not be able to open web pages using the ActiveX programming. Click the check box to enable the function otherwise disabled. Prevent WAN Request Block Anonymous WAN Requests (ping): By selecting “Block Anonymous WAN Requests Xiamen Four-Faith Communication Technology Co.,Ltd. Page 43 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
  • Page 44 The router can keep logs of all incoming or outgoing traffic for your Internet connection. Log: To keep activity logs, select Enable. To stop logging, select Disable. When select enable, the following page will appear. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 44 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...

  • Page 45: Vpn Passthrough

    3.3.4.2 VPN Passthrough Virtual Private Networking (VPN) is typically used for work-related networking. For VPN tunnels, the router supports OPENVPN Passthrough, PPTP Passthrough and L2TP Passthrough. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 45 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 46: Access Restrictions

    Two options in the default policy rules: "Filter" and "reject". If select "Deny”, you will deny specific computers to access any Internet service at a particular time period. If you choose to Xiamen Four-Faith Communication Technology Co.,Ltd. Page 46 of 70 Add：...
  • Page 47 Website Blocking by URL Address: You can block access to certain websites by entering their URL. Website Blocking by Keyword: You can block access to certain website by the keywords contained in their webpage Xiamen Four-Faith Communication Technology Co.,Ltd. Page 47 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
  • Page 48 8. Set the days when access will be filtered. Select Everyday or the appropriate days of the week. 9. Set the time when access will be filtered. Select 24 Hours, or check the box next to From and Xiamen Four-Faith Communication Technology Co.,Ltd. Page 48 of 70 Add：...

  • Page 49: Packet Filter

    Only Accept The Following-- Accept only the data packets conform to the following rules, Discard all other packets Direction input: packet from WAN to LAN output: packet from LAN to WAN Xiamen Four-Faith Communication Technology Co.,Ltd. Page 49 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：...

  • Page 50: Nat

    3.3.6.2 Port Range Forward Port Range Forwarding allows you to set up public services on your network, such as web Xiamen Four-Faith Communication Technology Co.,Ltd. Page 50 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 51: Port Triggering

    Application: Enter the name of the application in the field provided. Triggered Port Range: Enter the number of the first and the last port of the range, which should Xiamen Four-Faith Communication Technology Co.,Ltd. Page 51 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...

  • Page 52: Dmz

    All of this is more or less automatic. QoS allows control of the bandwidth allocation to different services, netmasks, MAC addresses and the four LAN ports. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 52 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 53: Classify

    Check all values and click Save Settings to save your settings. Click the Cancel changes button to cancel your unsaved changes. 3.3.8 Applications 3.3.8.1 Serial Applications Xiamen Four-Faith Communication Technology Co.,Ltd. Page 53 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
  • Page 54 F3X25 Series Router User Manual There is a console port on Four-Faith router. Normally, this port is used to debug the router. This port can also be used as a serial port. The router has embedded a serial to TCP program. The data sent to the serial port is encapsulated by TCP/IP protocol stack and then is sent to the destination server.

  • Page 55: Administration

    It's now possible to password protect this page (same username and password than above). Protocol：This feature allows you to manage the router using either HTTP protocol or the HTTPS protocol Xiamen Four-Faith Communication Technology Co.,Ltd. Page 55 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
  • Page 56 802.1x：A limited 802.1x server needed to fulfill WPA handshake requirements to allow Windows XP clients to work with WPA. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 56 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 57: Keep Alive

    At a specific date time each week or everyday. Note： For date based reboots Cron must be activated. See Management for Cron activation. 3.3.9.3 Commands Xiamen Four-Faith Communication Technology Co.,Ltd. Page 57 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：...

  • Page 58: Factory Defaults

    Any settings you have saved will be lost when the default settings are restored. After restoring the router is accessible under the default IP address 192.168.1.2 and the default password admin. 3.3.9.5 Firmware Upgrade Xiamen Four-Faith Communication Technology Co.,Ltd. Page 58 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：...

  • Page 59: Backup

    F3X25 Series Router User Manual Firmware Upgrade：New firmware versions are posted at www.four-faith.com and can be downloaded. If the Router is not experiencing difficulties, then there is no need to download a more recent firmware version, unless that version has a new feature that you want to use.

  • Page 60: Status

    LAN Domain Name: domain name of LAN, unavailable to modify Current Time: local time of the system Uptime: operating uptime as long as the system is powered on Xiamen Four-Faith Communication Technology Co.,Ltd. Page 60 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
  • Page 61 Protocol: connection protocol Timeouts: connection timeouts, unit is second Source Address: source IP address Remote Address: remote IP address Service Name: connecting service port Xiamen Four-Faith Communication Technology Co.,Ltd. Page 61 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324...

  • Page 62: Wan

    Module Type: module type in 3G/UMTS way Signal Status: signal intensity of the module in 3G/UMTS way Network: network type of the module in 3G/UMTS way Xiamen Four-Faith Communication Technology Co.,Ltd. Page 62 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 63: Lan

    Next Month: the flow of next month Backup: backup data administration Restore: restore data administration Delete: delete data administration 3.3.10.3 Xiamen Four-Faith Communication Technology Co.,Ltd. Page 63 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324...
  • Page 64 Starting IP Address: the starting IP Address of the DHCP server’s Address pool Ending IP Address: the ending IP Address of the DHCP server’s Address pool Client Lease Time: the lease time of DHCP client Xiamen Four-Faith Communication Technology Co.,Ltd. Page 64 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
  • Page 65 Interface: the interface assigned by dial-up system Local IP: tunnel IP address of local PPTP Remote IP: tunnel IP address of PPTP server Delete: click to disconnect PPTP Xiamen Four-Faith Communication Technology Co.,Ltd. Page 65 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 66: Bandwidth

    Delete: click to delete PPTP client 3.3.10.4 Bandwidth Bandwidth Monitoring-LAN Graph abscissa axis: time vertical axis: speed rate Xiamen Four-Faith Communication Technology Co.,Ltd. Page 66 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...

  • Page 67: Sys-Info

    LAN MAC: MAC address of LAN port WAN MAC: MAC address of WAN port WAN IP: IP address of WAN port LAN IP: IP address of LAN port Xiamen Four-Faith Communication Technology Co.,Ltd. Page 67 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
  • Page 68 Host Name: host name of LAN client IP Address: IP address of the client MAC Address: MAC address of he client Expires: the expiry the client rents the IP address Xiamen Four-Faith Communication Technology Co.,Ltd. Page 68 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 69: Chapter 4 Appendix

    3. Choose the correct COM port which connects to modem, choose “OK” 4. Configure the serial port parameters as following, choose “OK” Bits per second: 115200 Xiamen Four-Faith Communication Technology Co.,Ltd. Page 69 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 70: Xiamen Four-Faith Communication Technology Co.,Ltd

    Data bits: 8 Parity: None Stop bits: 1 Flow control: None 5. Complete Hyper Terminal operation, It runs as following Xiamen Four-Faith Communication Technology Co.,Ltd. Page 70 of 70 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324...
