F7X34S Series Router
User Manual
F7X34S Series Router User Manual
The user manual is suitable for the following model:
Documentation No.
Product Name：F7X34S
Model
Product Type
F7434S
GPS+WCDMA WIFI ROUTER
F7534S
GPS+TD-SCDMA WIFI ROUTER
F7634S
GPS+EVDO WIFI ROUTER
F7734S
GPS+LTE/TD-SCDMA WIFI ROUTER
F7834S
GPS+LTE/WCDMA WIFI ROUTER
F7A34S
GPS+LTE/EVDO WIFI ROUTER
Xiamen Four-Faith Communication Technology Co., Ltd.
Add：J1-J3,3rd Floor,No.44,GuanRi Road,SoftWare
Park,XiaMen,China
Tel：+86 592-6300326 ，6300325，6300324
Fax:+86 592-5912735
http://www.fourfaith.co
Product Version
V1.1
Zip Code:361008
Page
Total:96

Advertisement

Table of Contents
loading

Related Manuals for Four-Faith F7 34S Series

Summary of Contents for Four-Faith F7 34S Series

  • Page 1 GPS+WCDMA WIFI ROUTER F7534S GPS+TD-SCDMA WIFI ROUTER F7634S GPS+EVDO WIFI ROUTER F7734S GPS+LTE/TD-SCDMA WIFI ROUTER F7834S GPS+LTE/WCDMA WIFI ROUTER F7A34S GPS+LTE/EVDO WIFI ROUTER Xiamen Four-Faith Communication Technology Co., Ltd. Add：J1-J3,3rd Floor,No.44,GuanRi Road,SoftWare Park,XiaMen,China Zip Code:361008 Tel：+86 592-6300326 ，6300325，6300324 Fax:+86 592-5912735 http://www.fourfaith.co...
  • Page 2 Modify related parameter and add installation introduction of TF/SIM card’s L shape shield Modify Access the Configuration Web Page and Remote Manager Xiamen Four-Faith Communication Technology Co.,Ltd. Page 2 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324...
  • Page 3 Four-Faith Communication Technology Co., Ltd. Without written permission, all commercial use of the files from Four-Faith are forbidden, such as copy, distribute, reproduce the files, etc., but non-commercial purpose, downloaded or printed by individual (all files shall be not revised, and the copyright and other proprietorship notice shall be reserved) are welcome.
  • Page 4 F7X34S Series Router User Manual Xiamen Four-Faith Communication Technology Co.,Ltd. Page 4 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...

  • Page 5: Table Of Contents

    3.3.3.3 USB....................... 49 3.3.3.4 FTP Server.....................50 3.3.3.5 Hotspot......................51 3.3.4 VPN.........................52 3.3.4.1 PPTP......................52 3.3.4.2 L2TP......................53 3.3.4.3 OPENVPN....................55 3.3.4.4 IPSEC......................59 Xiamen Four-Faith Communication Technology Co.,Ltd. Page 5 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...
  • Page 6 3.3.11.1 Router......................82 3.3.11.2 WAN......................84 3.3.11.3 LAN......................86 3.3.11.4 Wireless....................... 89 3.3.11.5 Bandwidth....................90 3.3.11.6 Sys-Info....................... 92 Appendix............................95 Xiamen Four-Faith Communication Technology Co.,Ltd. Page 6 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...

  • Page 7: Chapter 1 Brief Introduction Of Product

    Stability and Reliability  Support hardware and software WDT  Support auto recovery mechanism, including online detect, auto redial when offline to make router always online Xiamen Four-Faith Communication Technology Co.,Ltd. Page 7 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
  • Page 8  Full protocol support , such as TCP/IP, UDP, ICMP, SMTP(optional), HTTP, POP3(optional), OICQ(optional), TELNET, FTP(optional), SNMP, SSHD, etc.  Schedule Reboot, Schedule Online and Offline,etc. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 8 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 9: Working Principle

    F7534S GPS+TD-SCDMA WIFI ROUTER TD-SCDMA/HSDPA/HSUPA /LTE Download speed:2.8Mbps <24dBm <-108 1880-1920/2010-2025MHz upload speed:2.2Mbps GSM850/900/1800/1900MHz GPRS/EDGE CLASS 12 LTE(Download speed:100Mbps, upload speed:50Mbps) Xiamen Four-Faith Communication Technology Co.,Ltd. Page 9 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...
  • Page 10 (Band 1/2/5/6/8） UMTS:384Kbps EDGE/GPRS/GSM (download 850/900/1800/1900MHz speed/upload speed) HSPA+: 42Mbps(download speed) 5.76Mbps(upload speed) F7A34S LTE&EVDO+WIFI ROUTER Xiamen Four-Faith Communication Technology Co.,Ltd. Page 10 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...
  • Page 11 WIFI Specification Item Content Standard IEEE802.11b/g/n Bandwidth IEEE802.11b/g: 54Mbps (max) IEEE802.11n: 150Mbps (max) Security WEP, WPA, WPA2, etc. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 11 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...
  • Page 12 Power Vehicle power jack, reverse-voltage and overvoltage protection Reset Restore the router to its original factory default settings Power Input Xiamen Four-Faith Communication Technology Co.,Ltd. Page 12 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324...
  • Page 13 206x135x28 mm Weight 790g Environmental Limits Item Content Operating -35~+75ºC（-31~+167℉） Temperature Storage -40~+85ºC（-40~+185℉） Temperature Operating 95% ( Non-condensing) Humidity Xiamen Four-Faith Communication Technology Co.,Ltd. Page 13 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...

  • Page 14: Chapter 2 Installation Introduction

    Vehicle interface line Power adapter Stator M3 Sunk screw L shape shield Manual CD Certification card Maintenance card Xiamen Four-Faith Communication Technology Co.,Ltd. Page 14 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...

  • Page 15: Installation And Cable Connection

    (Pay attention to put the side which has metal point outside), and insert card sheath back to the SIM/UIM card outlet. Warning: Forbid to install SIM/UIM card when powered! Installation of TF/SIM card’s L shape shield: Xiamen Four-Faith Communication Technology Co.,Ltd. Page 15 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
  • Page 16 Insert one end of the network cable into the switch interface with sign “Local Network”, and insert the other end into the Ethernet interface of user’s device. The signal connection of network direct cable is as follows: RJ45-1 RJ45-2 Xiamen Four-Faith Communication Technology Co.,Ltd. Page 16 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：...

  • Page 17: Power

    We recommend user to use the standard DC 12V/1.5A power. 2.5 Indicator Lights Introduction The router provides following indicator lights: “Power”, “System”, “Online”, “GPS”, “TF”, “WAN”, “WIFI”, “Signal Strength”. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 17 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 18: Reset Button Introduction

    The router has a “Reset” button to restore it to its original factory default settings. When user press the “Reset” button for up to 15s, the router will restore to its original factory default settings and restart automatically. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 18 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...

  • Page 19: Chapter 3 Configuration And Management

    Users have to click "change password" to make it work if they modify user name and password. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 19 of 96 Add：...
  • Page 20 F7X34S Series Router User Manual After access to the information main page Users need to input user name and password if it is their first time to login. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 20 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 21: Management And Configuration

    ISP, if required. 3.3.1.1 Basic Setting WAN Connection Type Five Ways: Disabled, Static IP, Automatic Configuration-DHCP, PPPOE, 3G/UNMTS/4G/LTE Disabled Xiamen Four-Faith Communication Technology Co.,Ltd. Page 21 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324...
  • Page 22 T-Home VDSL VLAN 7/8 Tagging: enable to support the front of the modem is vdsl MPPE Encryption: Microsoft point to point encryption. It is used to encrypt the point-to-point Xiamen Four-Faith Communication Technology Co.,Ltd. Page 22 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
  • Page 23 Detection Method: None: do not set this function Ping: Send ping packet to detect the connection, when choose this method, users should also Xiamen Four-Faith Communication Technology Co.,Ltd. Page 23 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：...
  • Page 24 STP (Spaning Tree Protocol) can be applied to loop network. Through certain algorithm achieves path redundancy, and loop network cuts to tree-based network without loop in the meantime, thus Xiamen Four-Faith Communication Technology Co.,Ltd. Page 24 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
  • Page 25 DHCP server option, users can set all the computers on the LAN to automatically obtain an IP address and DNS, and make sure no other DHCP server in the network. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 25 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
  • Page 26 DNSMasq: users' domain name in the field of local search, increase the expansion of the host option, to adopt DNSMasq can assign IP addresses and DNS for the subnet, if select DNSMasq, dhcpd service is used for the subnet IP address and DNS. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 26 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...

  • Page 27: Dynamic Dns

    IP address, and will forward traffic directed at their domain to their frequently-changing IP address. DDNS Service: Four-Faith router currently support DynDNS, freedns, Zoneedit, NO-IP, 3322, easyDNS, TZO, DynSIP and Custom based on the user. Xiamen Four-Faith Communication Technology Co.,Ltd.

  • Page 28: Clone Mac Address

    Some ISP need the users to register their MAC address. The users can clone the router MAC address to their MAC address registered in ISP if they do not want to re-register their MAC address Xiamen Four-Faith Communication Technology Co.,Ltd. Page 28 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...

  • Page 29: Advanced Router

    LAN, select Both. To disable the Dynamic Routing feature for all data transmissions, keep the default setting, Disable. Note：Dynamic Routing is not available in Gateway mode Static Routing Xiamen Four-Faith Communication Technology Co.,Ltd. Page 29 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 30: Vlans

    WAN (Internet), or Loopback (a dummy network in which one PC acts like a network, necessary for certain software programs) Show Routing Table 3.3.1.5 VLANs Xiamen Four-Faith Communication Technology Co.,Ltd. Page 30 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：...

  • Page 31: Networking

    VLAN0-VLAN15. However there is only 5 time ports (1 WAN port and 4 LAN port) divided by users themselves,and LAN port and WAN port disable to divide into one VLAN port meanwhile. 3.3.1.6 Networking Xiamen Four-Faith Communication Technology Co.,Ltd. Page 31 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：...
  • Page 32 Click 'Add' to take it effect. Note: corresponding interface of WAN ports interface should not be binding, this bridge function is basically used for LAN port, and should not be binding with WAN port Xiamen Four-Faith Communication Technology Co.,Ltd. Page 32 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
  • Page 33 Masquerade/NAT: enable or disable Masquerade/NAT IP Address: set ra0's IP address, and do not conflict with other ports or bridge Subnet Mask: set the port's subnet mask Xiamen Four-Faith Communication Technology Co.,Ltd. Page 33 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 34: Wireless

    'Save' or 'Apply' to put it into effect after setting. Note: Only configure and click 'Save' can configure the next, can not configure multiple DHCP at the same time. 3.3.2 Wireless 3.3.2.1 Basic Settings Xiamen Four-Faith Communication Technology Co.,Ltd. Page 34 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：...
  • Page 35 Unbridged：There is no bridge to the router, IP addresses need to manually configure. Virtual Interfaces：Click Add to add a virtual interface. Add successfully, click on the remove, you can remove the virtual interface。 Xiamen Four-Faith Communication Technology Co.,Ltd. Page 35 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...

  • Page 36: Wireless Security

    Disabled by default, not safe mode is enabled. Such as changes in Safe Mode, click Apply to take effect immediately. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 36 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
  • Page 37 Passphrase：The letters and numbers used to generate a key. Key1-Key4：Manually fill out or generated according to input the pass phrase. WPA Personal/WPA2 Personal/WPA2 Person Mixed: ， TKIP/AES/TKIP+AES ， dynamic Xiamen Four-Faith Communication Technology Co.,Ltd. Page 37 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...

  • Page 38: Wireless Mac Filter

    MAC addresses. For information how to get MAC addresses from Windows-PCs, see MAC Address Cloning for detailed instructions。 Use Filter：Disabled by default. Select Enable to open the Wireless MAC Filter。 Filter Mode： Xiamen Four-Faith Communication Technology Co.,Ltd. Page 38 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 39: Advance Settings

    The default setting will ensure maximum compatibility with all devices. You may also choose to enable all data rates by selecting ALL. For Xiamen Four-Faith Communication Technology Co.,Ltd. Page 39 of 96 Add：...
  • Page 40 After receiving an RTS, the wireless station responds with a Clear to Send (CTS) frame to acknowledge the right to begin transmission. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 40 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
  • Page 41 WLAN during some hours of the day. Hours during which the WLAN is on are marked in green, while red indicates that the radio is off. Clicking on the respective hour toggles between on and off. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 41 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
  • Page 42 High throughput. Bulk data that requires maximum throughput and is not time-sensitive is sent to this queue (FTP data, for example). Best Effort: Priority is Medium. Medium throughput and delay. Most traditional IP data is sent to this queue Xiamen Four-Faith Communication Technology Co.,Ltd. Page 42 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 43: Wds

    APs communicate both with each other and with wireless stations (at the expense of half the throughput). This firmware currently supports one types of WDS, LAN. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 43 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
  • Page 44 If the signal is "0dBm" then there may be something wrong. Check your antenna connections and configuration settings, and try again. 7. Once you have a good signal (-70dBm to -30dBm, -70dBm being lowest), you can change the Xiamen Four-Faith Communication Technology Co.,Ltd. Page 44 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...

  • Page 45: Services

    (dynamic and static) as well as forwarding and caching DNS entries from remote DNS servers. Local DNS enables DHCP clients on the LAN to resolve static and dynamic DHCP hostnames. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 45 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
  • Page 46 Enable Syslogd to capture system messages. By default they will be collected in the local file /var/log/messages. To send them to another system, enter the IP address of a remote syslog server. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 46 of 96 Add：...

  • Page 47: Pppoe Server

    Ttraff Daemon: enable or disable wan traffic counter function 3.3.3.2 PPPoE Server PPPoE Server RP-PPPoEServer Daemon: enable or disable PPPoE server RP-PPPoEServer Options Xiamen Four-Faith Communication Technology Co.,Ltd. Page 47 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324...
  • Page 48 User: set PPPOE client's user name Password: set PPPOE client's user password IP Address: set PPPOE client's user IP address Enable: enable or disable this setting Radius Xiamen Four-Faith Communication Technology Co.,Ltd. Page 48 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：...

  • Page 49: Usb

    Enable the service to identify the U disk connected to the router, TF card or SD memory card, and use these types of storage media. Specific setup instructions screenshot below Xiamen Four-Faith Communication Technology Co.,Ltd. Page 49 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...

  • Page 50: Ftp Server

    ： Log in to the router FTP server administrator account, the default user name “admin” router WEB configuration management Password：Log on to the FTP server to the router's administrator password, the default is “admin” Xiamen Four-Faith Communication Technology Co.,Ltd. Page 50 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...

  • Page 51: Hotspot

    180 seconds Client Timeout (minutes): detects the connection at the maximum timeout this station WIFI wireless router client terminals (computers, mobile phones, etc.) did not have the Internet to Xiamen Four-Faith Communication Technology Co.,Ltd. Page 51 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...

  • Page 52: Vpn

    PPTP Server Broadcast support: enable or disable broadcast support of PPTP server Force MPPE Encryption: enable of disable force MPPE encryption of PPTP data DNS1/DNS2/WINS1/WINS2: set DNS1/DNS2/WINS1/WINS2 Xiamen Four-Faith Communication Technology Co.,Ltd. Page 52 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 53: L2Tp

    NAT: network Address Translation User Name: user name to login PPTP Server. Password: password to log into PPTP Server. 3.3.4.2 L2TP L2TP Server Xiamen Four-Faith Communication Technology Co.,Ltd. Page 53 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324...
  • Page 54 Remote Subnet Mask: subnet mask of remote PPTP server MPPE Encryption: enable or disable Microsoft Point-to-Point Encryption MTU: maximum transmission unit MRU: maximum receive unit Xiamen Four-Faith Communication Technology Co.,Ltd. Page 54 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：...

  • Page 55: Openvpn

    Pool end IP: pool end IP of the client allowed by OPENVPN server Gateway: the gateway of the client allowed by OPENVPN server Netmask: netmask of the client allowed by OPENVPN server Xiamen Four-Faith Communication Technology Co.,Ltd. Page 55 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
  • Page 56 TLS Cipher: TLS (Transport Layer Security) encryption standard supports AES-128 SHA and AES-256 SHA Client connect script: define some client script by user self CA Cert: CA certificate Xiamen Four-Faith Communication Technology Co.,Ltd. Page 56 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
  • Page 57 Additional Config: additional configurations of the server CCD-Dir DEFAULT file: other file approaches TLS Auth Key: authority key of Transport Layer Security Certificate Revoke List: configure some revoke certificates OPENVPN Client Xiamen Four-Faith Communication Technology Co.,Ltd. Page 57 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：...
  • Page 58 AES-256 SHA TLS Auth Key: authority key of Transport Layer Security Additional Config: additional configurations of OPENVPN server Policy based Routing: input some defined routing policy Xiamen Four-Faith Communication Technology Co.,Ltd. Page 58 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 59: Ipsec

    Enable: when the connection is enable, it will launch tunnel establish request when the system reboot or reconnect, otherwise the connection will not do it Add: to add a new IPSEC connection Add IPSEC connection or edit IPSEC connection Xiamen Four-Faith Communication Technology Co.,Ltd. Page 59 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
  • Page 60 Timeout: set the timeout of connect detection Action: set the action of connect detection Advanced Settings: this part contains relevant setting of IKE, ESP, negotiation mode, etc. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 60 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 61: Gre

    (such as IP and IPX) data packets are encapsulated, so these encapsulated data packets to another network layer protocol (IP)transmission. GRE Tunnel (tunnel) technology, Layer Two Tunneling Protocol VPN (Virtual Private Network). Xiamen Four-Faith Communication Technology Co.,Ltd. Page 61 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
  • Page 62 Interval：The time interval of GRE keepalive packet sent Fail Action：The action would be exec after keeping alive failed Click on “View GRE tunnels” keys can view the information of GRE Xiamen Four-Faith Communication Technology Co.,Ltd. Page 62 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...

  • Page 63: Security

    (ping)” box to enable this feature, you can prevent your network from the Ping or detection of other Internet users. so that make More difficult to break into your network. The default state of Xiamen Four-Faith Communication Technology Co.,Ltd. Page 63 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
  • Page 64 The router can keep logs of all incoming or outgoing traffic for your Internet connection. Log: To keep activity logs, select Enable. To stop logging, select Disable. When select enable, the following page will appear. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 64 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...

  • Page 65: Vpn Passthrough

    3.3.5.2 VPN Passthrough Virtual Private Networking (VPN) is typically used for work-related networking. For VPN tunnels, the router supports OPENVPN Passthrough, PPTP Passthrough and L2TP Passthrough. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 65 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 66: Access Restrictions

    Two options in the default policy rules: "Filter" and "reject". If select "Deny”, you will deny specific computers to access any Internet service at a particular time period. If you choose to Xiamen Four-Faith Communication Technology Co.,Ltd. Page 66 of 96 Add：...
  • Page 67 Website Blocking by URL Address: You can block access to certain websites by entering their URL. Website Blocking by Keyword: You can block access to certain website by the keywords contained in their webpage Url Filter Xiamen Four-Faith Communication Technology Co.,Ltd. Page 67 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：...
  • Page 68 2. For this policy is enabled, click the "Enable" 3. Enter a name in the Policy Name field. 4. Click the Edit List of Clients button. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 68 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 69: Packet Filter

    Discard The Following--Discard packets conform to the following rules, Accept all other packets Only Accept The Following-- Accept only the data packets conform to the following rules, Discard all other packets Xiamen Four-Faith Communication Technology Co.,Ltd. Page 69 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 70: Nat

    When users send this type of request to your network via the Internet, the router will forward those requests to the appropriate PC. If you want to forward a whole range of ports, see Port Range Forwarding. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 70 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...

  • Page 71: Port Range Forward

    Triggering rules, you can allow inbound traffic to arrive at a specific LAN host, using ports different than those used for the outbound traffic. This is called port triggering since the outbound traffic triggers to which ports inbound traffic is directed. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 71 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...

  • Page 72: Dmz

    IP address in the DMZ Host IP Address field. To disable the DMZ, keep the default setting ： Disable Check all values and click Save Settings to save your settings. Click the Cancel changes button to cancel your unsaved changes. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 72 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 73: Qos Setting

    3.3.9.1 Serial Applications There is a console port on Four-Faith router. Normally, this port is used to debug the router. This port can also be used as a serial port. The router has embedded a serial to TCP program. The data sent to the serial port is encapsulated by TCP/IP protocol stack and then is sent to the destination server.

  • Page 74: Gps Settings

    Enable Serial TCP Function: Enable the serial to TCP function Protocol Type: The protocol type to transmit data. UDP(DTU) – Data transmit with UDP protocol , work as a Four-Faith DTU which has application protocol and hear beat mechanism. Pure UDP – Data transmit with standard UDP protocol.

  • Page 75: Upload Log

    Append the device ID to the tail of gps information: Whether append the ID to the GPS information GPS Information Contents：GPS contents selection When GPS output interface is serial port, we should set the following serial port settings: 3.3.9.3 Upload Log Xiamen Four-Faith Communication Technology Co.,Ltd. Page 75 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：...

  • Page 76: Administration

    All users who try to access the router's web-based utility or Setup Wizard will be prompted for the router's password. Web Access This feature allows you to manage the router using either HTTP protocol or the HTTPS protocol. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 76 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
  • Page 77 If the Remote Router Access feature is enabled, anyone who knows the router's Internet IP address and password will be able to alter the router's settings. Telnet Management：Enable or disable remote Telnet function Xiamen Four-Faith Communication Technology Co.,Ltd. Page 77 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
  • Page 78 Language：Set up the router page shows the type of language, including simplified Chinese and English. Remote Upgrade: custom-developed remote management server for this station router monitoring and management, configuration parameters, WIFI advertising updates. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 78 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 79: Keep Alive

    Consider using these: Maximum Ports: 4096 TCP Timeout: 3600 sec UDP Timeout: 120 sec 3.3.10.2 Keep Alive Schedule Reboot Xiamen Four-Faith Communication Technology Co.,Ltd. Page 79 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324...

  • Page 80: Commands

    3.3.10.4 Factory Defaults Reset router settings：Click the Yes button to reset all configuration settings to their default values. Then click the Apply Settings button. Note： Xiamen Four-Faith Communication Technology Co.,Ltd. Page 80 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：...

  • Page 81: Firmware Upgrade

    3.3.10.5 Firmware Upgrade Firmware Upgrade：New firmware versions are posted at www.four-faith.com and can be downloaded. If the Router is not experiencing difficulties, then there is no need to download a more recent firmware version, unless that version has a new feature that you want to use.

  • Page 82: Status

    Only restore configurations with files backed up using the same firmware and the same model of router. 3.3.11 Status 3.3.11.1 Router Xiamen Four-Faith Communication Technology Co.,Ltd. Page 82 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324...
  • Page 83 Cached: the memory used by high-speed cache memory Active: active use of buffer or cache memory page file size Inactive: not often used in a buffer or cache memory page file size Xiamen Four-Faith Communication Technology Co.,Ltd. Page 83 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...

  • Page 84: Wan

    Service Name: connecting service port Status: displayed status 3.3.11.2 Connection Type: disabled, static IP, automatic configuration-DHCP, PPPOE, 3G/UMTS Connection Uptime: connecting uptime; If disconnect, display Not available Xiamen Four-Faith Communication Technology Co.,Ltd. Page 84 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：...
  • Page 85 Module Type: module type in 3G/UMTS way Signal Status: signal intensity of the module in 3G/UMTS way Network: network type of the module in 3G/UMTS way Xiamen Four-Faith Communication Technology Co.,Ltd. Page 85 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 86: Lan

    Next Month: the flow of next month Backup: backup data administration Restore: restore data administration Delete: delete data administration 3.3.11.3 Xiamen Four-Faith Communication Technology Co.,Ltd. Page 86 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324...
  • Page 87 Starting IP Address: the starting IP Address of the DHCP server’s Address pool Ending IP Address: the ending IP Address of the DHCP server’s Address pool Client Lease Time: the lease time of DHCP client Xiamen Four-Faith Communication Technology Co.,Ltd. Page 87 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
  • Page 88 Interface: the interface assigned by dial-up system Local IP: tunnel IP address of local PPTP Remote IP: tunnel IP address of PPTP server Delete: click to disconnect PPTP Xiamen Four-Faith Communication Technology Co.,Ltd. Page 88 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 89: Wireless

    TX Power: reflection power of wireless network Rate: reflection rate of wireless network Encryption-Interface wl0: enable or diasbal Encryption-Interface wl0 PPTP Status: show wireless pptp status Received (RX): received data packet Xiamen Four-Faith Communication Technology Co.,Ltd. Page 89 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：...

  • Page 90: Bandwidth

    Dtim: delivery traffic indication message of the wireless nearby Rate: speed rate of the wireless nearby Join Site: click to join wireless network nearby 3.3.11.5 Bandwidth Xiamen Four-Faith Communication Technology Co.,Ltd. Page 90 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：...
  • Page 91 Bandwidth Monitoring-LAN Graph abscissa axis: time vertical axis: speed rate Bandwidth Monitoring-WAN Graph abscissa axis: time vertical axis: speed rate Xiamen Four-Faith Communication Technology Co.,Ltd. Page 91 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324...

  • Page 92: Sys-Info

    WAN MAC: MAC address of WAN port Wireless MAC: MAC address of the wireless WAN IP: IP address of WAN port LAN IP: IP address of LAN port Xiamen Four-Faith Communication Technology Co.,Ltd. Page 92 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
  • Page 93 Signal: the signal of wireless client Noise: the noise of wireless client SNR: the signal to noise ratio of wireless client Signal Quality: signal quality of wireless client Xiamen Four-Faith Communication Technology Co.,Ltd. Page 93 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
  • Page 94 Host Name: host name of LAN client IP Address: IP address of the client MAC Address: MAC address of he client Expires: the expiry the client rents the IP address Xiamen Four-Faith Communication Technology Co.,Ltd. Page 94 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 95: Appendix

    3. Choose the correct COM port which connects to modem, choose “OK” 4. Configure the serial port parameters as following, choose “OK” Bits per second: 115200 Xiamen Four-Faith Communication Technology Co.,Ltd. Page 95 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...

  • Page 96: Xiamen Four-Faith Communication Technology Co.,Ltd

    Data bits: 8 Parity: None Stop bits: 1 Flow control: None 5. Complete Hyper Terminal operation, It runs as following Xiamen Four-Faith Communication Technology Co.,Ltd. Page 96 of 96 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324...
