- Page 1 5G ODU User Manual V 1.0.0 Xiamen Four-Faith Communication Technology Co., Ltd. https://www.fourfaith.com...
-
Page 2: Revision History
Revision History Date Version Declaration Author 2023-11-24 V1.0.0 Initial version... - Page 3 All materials or content contained in this document are protected by copyright law. All copyrights are owned by Xiamen Four-Faith Communication Technology Co., Ltd., except for content attributed to other parties. Without written permission from Four-Faith, no one may copy, distribute, reprint, link, transmit, or use any content on this document for any commercial purpose.
- Page 4 4. The plug considered as disconnect device of adapter. 5. The device complies with RF specifications when the device used at 20cm from the body. Hereby, Xiamen Four-Faith Communication Technology Co.,Ltd declares that this product is in compliance with essential requirements and other relevant provisions of Directive 2014/53/EU.
-
Page 5: Table Of Contents
5G ODU FNB600 User Manual Contents Chapter 1 Product Introduction .......................... 1 Product Overview ........................1 Product Features .......................... 1 Product Appearance Overview ..................... 2 Product Specifications ........................3 Interface Figure ..........................5 Chapter 2 Install Internet Configuration ......................6 Configure SIM card for Internet Access .................. -
Page 6: Chapter 1 Product Introduction
Chapter 1 Product Introduction 1.1 Product Overview The FNB600 is a high-performance 5G outdoor unit (ODU) that supports NR (SA&NSA), TDD-LTE, and FDD-LTE. It can convert cellular network data into wired Ethernet data. Equipped with a high-speed 2.5G LAN interface, it supports PoE power supply, a metal heat dissipation base, and an IP68 waterproof shell. -
Page 7: Product Appearance Overview
5G ODU FNB600 User Manual ◆ It operates on a commercial router operating system. ◆ It includes features like frequency locking, cell locking, bridge mode, TR069, DDNS, firewall, QoS, and traffic statistics. 1.3 Product Appearance Overview Indicator Name Definition Explanation... -
Page 8: Product Specifications
5G ODU FNB600 User Manual If it is not lit, it means there is no network connection. Blinking indicates dialing; the frequency of blinking is 500ms per cycle. Solid blue indicates a strong signal, defined as RSRP > -95dBm or RSCP > -80. - Page 9 5G ODU FNB600 User Manual WIFI Parameters WIFI Protocol IEEE802.11 a/b/g/n Frequency 2.4GHz(only for Configuration) Band Power Supply Standard POE: 802.3af / DC: 12V 1.5A Power Supply Interface Parameters Ethernet 1 x 2.5G Ethernet port (RJ45),, adaptive MDI/MDIX Interface LAN...
-
Page 10: Interface Figure
5G ODU FNB600 User Manual 1.5 Interface Figure Dual Nano-SIM Card Slots DC Port Type C Interface(for Debugging) LAN Port Interface Name Definition Explanation DC Port POE Interface POE: 802.3af / DC: 12V 1.5A LAN Port 1 x 2.5G Ethernet port (RJ45),, adaptive MDI/MDIX... -
Page 11: Chapter 2 Install Internet
5G ODU FNB600 User Manual Chapter 2 Install Internet Configuration 2.1 Configure SIM card for Internet Access 2.1.1 Configure SIM card for Internet Access(POE Supply) Step 1: Unscrew the two screws on the device cover and remove the cover. Step 2: Insert the SIM card according to the direction indicated by the SIM card slot (the left side of the slot is for the secondary card, and the right side is for the main card). -
Page 12: Configure Sim Card For Internet Access(Dc Supply)
5G ODU FNB600 User Manual Step 4: Follow the steps from left to right in the picture to thread the Ethernet cable into the waterproof connector. Tighten the waterproof connector, insert it into the device LAN port, and securely fasten the waterproof connector to the device. Note: It is recommended to use a wrench to tighten;... -
Page 13: Mobile Network For Internet Access
5G ODU FNB600 User Manual other network devices. 2.2 Mobile Network for Internet Access Step 1: After inserting the SIM card and powering on the device, open a browser and manually enter: 192.168.1.1. The initial login credentials are: admin (username) and admin (password). - Page 14 5G ODU FNB600 User Manual Select IP Type Select RAT Type SIM2 dial-up settings are the same. Click “Save” www.fourfaith.com Copyright @ Four-Faith 2023...
-
Page 15: Dual Sim Card Settings
5G ODU FNB600 User Manual Step 3: Select the “Home” page of the Configuration page, and check the “Network Status” 2.3 Dual SIM Card Settings The WEB configuration page allows you to set the priority between two SIM Cards, with “SIM1 First”being the default priority (i.e., SIM card network). - Page 16 5G ODU FNB600 User Manual Only SIM2: Using SIM2 only www.fourfaith.com Copyright @ Four-Faith 2023...
-
Page 17: Chapter 3 Configuration Of Related
5G ODU FNB600 User Manual Chapter 3 Configuration of Related Features 3.1 WLAN Configuration The WLAN settings are divided into basic settings and advanced settings. Basic settings allow you to configure the SSID, security mode, password, connection limit, broadcast hiding. Select “WLAN Settings”- “Basic Setting”- “WLAN Settings”, then Enable it. - Page 18 5G ODU FNB600 User Manual In the WI-FI advanced Settings page, you can find the option for Area code, allowing you to make more detailed wireless network settings. In the WI-FI Advanced Settings page, you will find the channel options, providing you with the ability to customize and optimize your wireless network settings further.
-
Page 19: Lock Network Settings
5G ODU FNB600 User Manual In the WI-FI Advanced Settings page, you'll discover signal mode options that empower you to customize and optimize your wireless network settings, ensuring seamless connectivity tailored to your preferences. Signal Mode includes “Sleep”， “Standard“ and “Through Walls” Mode. -
Page 20: Ethernet Configuration
5G ODU FNB600 User Manual 3.3 Ethernet Configuration Connect one end of the Ethernet cable to the LAN port of the ODU device and the other end to the IDU device or CPE device, providing wired and wireless network access for these devices. -
Page 21: Traffic Usage Monitoring Configuration
5G ODU FNB600 User Manual 3.5 Traffic Usage Monitoring Configuration Traffic Usage Monitoring is only applicable to mobile networks. The traffic usage monitoring page displays the total data usage for the current day and month. It also allows you to set up actions for exceeding data package limits and data flow restrictions. - Page 22 5G ODU FNB600 User Manual Restart Mobile Network: Check this option and save to enable automatic redialing of the mobile network. Step 2: Restoring Mobile Network After Data Exceedance After data usage exceeds the limit and the mobile network disconnects, you will need to manually enable mobile data.
- Page 23 5G ODU FNB600 User Manual www.fourfaith.com Copyright @ Four-Faith 2023...
-
Page 24: Statistics Reports
5G ODU FNB600 User Manual 3.6 Statistics Reports Select “Toolbox” - “Traffic Statistics” - “Statistics Reports”. The statistical reports summarize the monthly traffic usage of the ODU, presenting a graphical representation of the daily traffic usage throughout the month. This feature offers a comprehensive overview of the ODU's data consumption patterns, aiding users in analyzing and understanding the network traffic dynamics on a day-to-day basis. -
Page 25: Parental Control
5G ODU FNB600 User Manual SIM Card Option: 3.7 Parental Control The parental control feature allows you to set the internet access time for family members, promoting healthy online habits, especially for minors. The configuration for child internet protection includes setting a name, selecting the Source MAC address, and defining the times for enabling and disabling the protection. -
Page 26: Qos Configuration
5G ODU FNB600 User Manual 3.8 QOS Configuration Select “Toolbox” – “QOS Settings” – “Basic Setting”. Users can select different QoS bandwidth rule settings for Mobile Network. They are “Priority”, “Express”, “Normal”, “Bulk”. The QoS (Quality of Service) function allows you to limit the bandwidth for mobile networks connections. - Page 27 5G ODU FNB600 User Manual Select “Toolbox”- “QoS Settings”- “Advanced Settings”. QoS Advance Settings allows users to finely tune the QoS by configuring MAC or IP QoS settings. This feature enables users to prioritize specific devices or IP addresses, ensuring a more optimized and efficient network experience based on users' preferences.
-
Page 28: Pin Management
5G ODU FNB600 User Manual 3.9 PIN Management Select “Toolbox” – “PIN Management” – “PIN Management”. The ODU Configuration page encompasses comprehensive PIN management, providing you with the ability to securely manage and customize personal identification numbers (PINs). This feature adds an extra layer of protection and control over access to your ODU device, ensuring the security of your network infrastructure. - Page 29 5G ODU FNB600 User Manual Users input number and content, then send SMS. www.fourfaith.com Copyright @ Four-Faith 2023...
