Message
Displayed
- The Perimeter Wire is too close to the edge.
- The lawn slope is too big.
- The unit does not succeed to turn in place at
Cross Outside
the edge and it causes the mower to slip out of
the area.
- The unit has slipped out of the Perimeter Wire
lope because of slopping area or wet grass.
Drive Overheat
- The drive motors have been working under a
Cooling... severe load for too long.
- The Front Wheel has left the ground for too
Front Wheel
long time during operation.
Problem
- The handle is lifted while trying to start the
Handle Lifted
operation
- One of the operating panel buttons is
Key Pressed
constantly pressed.
Keys Locked
- Child Lock feature has been activated.
Mow Overheat
- The mowing motor has been working under a
cooling... severe load for too long of a time.
- Power Box / Perimeter Switch is not turned on
or not connected to the zone intended to mow.
No wire signal
- The Perimeter Wire is not connected to the
Base Station / Perimeter Switch.
- The Perimeter Wire is cut.
- The operation is delayed as the unit detects
Rain detected
rain on the scheduled time it should start the
automatic operation from the Base Station.
- The maximum operating time has been
reached (displayed in non-Base Station zone).
Recharge battery
- Mower is searching for the Base Station but
the battery voltage is too low to continue the
searching process.
44
Probable Cause/Event Corrective/User Action
- Remove the wire towards the inner side of the lawn.
- Do not include area with very steep slopes.
- Fill holes and pits in the ground.
- Increase the cutting height.
- No need to do anything.
- The unit will renew the operation automatically as soon
as the drive motor will cool down.
- If the unit has driven onto an obstacle, raising the front
end:
Remove or exclude the object from the mowing area.
- If the unit is being used on a slope too steep for safe
mowing:
Exclude this from the mowing area.
- If High grass is preventing the front wheel from fully
riding on the ground:
Raise the cutting height.
- If the ground contains large holes or indentations where
the front wheel can drop into when passing across:
Fill these areas with dirt and level off.
- Push the carrying handle down back to its position to
enable automatic operation.
- Press to confirm the message and to continue
operation. This message is displayed to inform only.
- Press the button and then press the
Child Lock can be deactivated under the Settings
menu.
- No need for action – the unit will renew automatically the
operation, as the mowing motor will cool down.
- Make sure the Base Station is connected to the mains
supply.
- Disconnect the Power Box from the mains power and
reconnect after 10 seconds.
- Check the Perimeter Switch is connected to the correct
zone and is turned on.
- Check the connection of the Perimeter Wire to the Base
Station / Perimeter Switch.
- Check for cut in the Perimeter Wire.
- No need for action-
the message is displayed until the the unit will not detect
rain and will start mowing.
- Connect the charger to the mower or place it in the Base
Station for charging.
- Drive the mower manually using the remote control or
carry it by hand for charging in the Base Station.
36
Troubleshooting
button.
