Accessories

For this model you can have the following accessories:
• Large grill
• Steel floor plate
Data for calculation of the chimney
Stove Connecting
adaptor
model
mm
SCAN
4 150
Column 2 and 5 show the flue gas temperature in the connecting adaptor
Column 3 and 6 show the lowest/minimum draft in Pa by rated value
Column 7 shows the lowest/minimum draft in Pa by 0.8 x rated value
SCAN 4
With open doors
1 2
Density of Flue gas Minimum
flue gas tempera- draft
flow ture
o C
g/s
- -

Adjustment of the handle

If the handle is not in the vertical position, you
can adjust as follows: loosen the screw (see
illustration), put the handle in the vertical posi-
tion and tighten the screw.

Handle

The door is opened by turning the handle
counter-clockwise.

Self-closing door (BA 1)

The door is prepared with a self-closing function at the fac-
tory. If you tighten the spring with the hexagon spanner, the
door will close automatically when you let go of it.
With closed doors
3 4 5
Density of Flue gas
flue gas temperature
flow
Pa o C
g/s
- 6 320
6 7
Minimum 0,8
draft Minimum
draft
Pa Pa
14 11
