1 Introduction
The information in this manual provides quick installation and setup procedures for the
SN680D-A-WNIR Camera Dome. This unit should only be installed by a qualified techni-
cian using approved materials in conformance with federal, state, and local codes. Read
these instructions thoroughly before beginning an installation. Always refer to Vicon's web-
site to assure you have the most up-todate manual, www.vicon-security.com.
Vicons SN680D-A-WNIR HD Network Dome Camera is designed for performance in the
most demanding security installations. The 1080P megapixel pan, tilt, zoom (PTZ) camera
series has an integrated 30x optical zoom lens (4.3 mm to 129 mm); integrated IR LEDs
provide illumination up to a range of 492 ft (150 m).
The SN680D-A-WNIR provides triple-streaming video and supports H.264 compression
technology, drastically reducing file sizes and conserving valuable network bandwidth. Users
can receive multiple streams simultaneously in different resolutions, frame rates and image
qualities for viewing on different platforms.
The PoE/12 VDC camera dome is designed for easy installation. The SN680D-A-WNIR can
be mounted on a wall or ceiling. Additional accessories allow the unit to be pendant mounted
on a wall mount or in-ceiling. The camera can be tilted to 10 degrees above the horizon.
1.1 Components
This system comes with the following components;
Dome Camera
Installation Guide/CD
RJ-45 Coupler
2P screw type Connector
5P screw type Connector
12VDC Adaptor
PoE Injector
Install Adaptor
1
1
1
1
1
1 (Optional)
1 (Optional)
1
2
