Manitowoc K00175 Installation Instructions

1. Water filter bin bracket can be used to mount all Tri-liminator water filter assemblies on either side or back of any Manitowoc ice
bin.
2. Remove foam tape from area where bracket is to be mounted, hang bracket, and install foam tape, provided with kit, over top of
bracket. Locate ice machine, per installation instructions.
3. Using screws and flatwashers provided, fasten Tri-liminator assembly to bracket.
4. Using two grommets, insert into holes in bracket.
Ice Bin
Grommet
Manitowoc Ice, Inc.
th
2110 South 26 Street, P.O. Box 1720, Manitowoc, WI 54221-1720 USA
Telephone 920-682-0161, Fax - Sales: 920-683-7589, Service/Parts: 920-683-7585, Other: 920-683-7879
Web Site - www.manitowocice.com
K00175 WATER FILTER BIN BRACKET
Foam Tape
Installation Instructions
Water Filter Bin Bracket
#10-24 x 1/2 lg. screw
and flatwasher
Tri-liminator Assembly
8005473
Rev. 06/11/03
