CHAPTER 6: QUICKFLY RIGGING
Pole-Mounting with the MUB-UPJunior
You can use the MUB-UPJunior U-bracket to pole-mount a
single UPJunior with a third-party pole adapter. This combi-
nation allows the UPJunior's angle to be adjusted. The U-
bracket can also be used to pole-mount a vertical array of
up to two UPJuniors with an MAAM-UPJunior array adapter.
MUB-UPJunior with MAAM-UPJunior Array, Pole-Mounted
The MUB-UPJunior U-bracket should be secured to the
pole adapter with the bracket's two 1/4" center holes.
CAUTION:
When pole-mounting UPJuniors (up
!
to two) with the MUB-UPJunior U-bracket,
make sure the third-party pole and pole adapter have
been rated to support the total weight of the loud-
speakers. Observe all safety precautions specified by
the manufacturers.
26
THE MYA-UPJUNIOR MOUNTING YOKE
The MYA-UPJunior mounting yoke suspends a single
UPJunior loudspeaker and allows a wide range of horizontal
and vertical adjustment. The mounting yoke's bottom bar
attaches to the bottom plate of the UPJunior with two M8
mounting screws (included). A "C" or "G" hanging clamp
and steel safety cable (not included) are required to suspend
the MYA-UPJunior mounting yoke.
MYA-UPJunior Mounting Yoke
NOTE:
The top bar of MYA-UPJunior mounting yoke
accommodates hanging clamps with standard 1/2-
inch or 12 mm bolts.
