Group setup
G R O U P S E T U P
- - - - - - - - - - - - - - - - - - - - - - - - - - - - -
1 / 8
G R O U P N O .
C A N C E L
S A V E G R O U P
C A N C E L
C L E A R G R O U P
R U N G R O U P
< E D I T G R O U P >
B A C K
E X I T
From the dome camera setup menu, use the
joystick to highlight GROUP SETUP and key:
NEAR
GROUP NO. (1-8) - shows the group number
currently being modified.
CLEAR GROUP - the currently selected group
can be deleted
RUN GROUP - runs the currently selected
group for testing purposes
<EDIT GROUP> - allows the operator to
program the group functions. operator can edit
new nesting group action in each group
Highlight the item to modify and key: NEAR
Use the joystick to change the setting and key:
NEAR to save or: FAR to cancel.

Edit group

E D I T G R O U P 1
- - - - - - - - - - - - - - - - - - - - - - - - - - - - -
N O A C T I O N A A A D W E L L O P T
- - - - - - - - - - - - - - - - - - - - - - - - - - - - -
1 P R E S E T 0 0 1 0 0 : 0 3 3 6 0
2 N O N E
3 N O N E
4 N O N E
5 N O N E
- - - - - - - - - - - - - - - - - - - - - - - - - - - - -
B A C K
C A N C E L
From the group setup menu, use the joystick
to highlight EDIT GROUP and key: NEAR
To edit the group, key: NEAR again
Header explanation:
NO - the item number (between 1 & 20)
ACTION - the specific action for this item
AAA - the action number (eg if ACTION is set
to PRESET, this value can be between 1 &128
DWELL - the amount of time before the next
action in the list is called
OPT - for PRESET actions, this value is the
speed at which the dome moves to the preset.
For SCAN and PATTERN, this value is the
number of times the action is repeated before
the next action is called
Move the joystick up and down to choose the
group item to modify and key: NEAR. The
ACTION is highlighted in white
Move the joystick up and down to change the
action type between NONE, PRESET, SCAN
and PATTERN.
Move the joystick left and right to select and
edit values for AAA, DWELL & OPT.
Edit group
E D I T G R O U P 1
- - - - - - - - - - - - - - - - - - - - - - - - - - - - -
N O A C T I O N A A A D W E L L O P T
- - - - - - - - - - - - - - - - - - - - - - - - - - - - -
1 P A T T E R N 1 0 0 : 0 3 1
2 P R E S E T 5 0 0 : 0 8 3 6 0
3 S C A N 3 0 0 : 0 3 8
4 P R E S E T 1 0 0 0 : 1 5 1 1 0
5 P R E S E T 4 0 1 : 3 0 5 5
- - - - - - - - - - - - - - - - - - - - - - - - - - - - -
B A C K
C A N C E L [ N E A R : E D I T ]
Key NEAR to save this item and continue
adding more items as necessary, or key
to exit.
14

Pattern setup

P A T T E R N S E T U P
- - - - - - - - - - - - - - - - - - - - - - - - - - - - -
P A T T E R N N O .
1 / 4
C L E A R P A T T E R N
C A N C E L
R U N P A T T E R N
< E D I T P A T T E R N >
B A C K
E X I T
From the dome camera setup menu, use the
joystick to highlight PATTERN SETUP
FAR
key: NEAR
PATTERN NO. (1 - 4) - The pattern number
currently being modified.
CLEAR PATTERN - the currently selected
pattern can be deleted
RUN PATTERN - runs the currently selected
pattern for testing purposes
<EDIT PATTERN> - allows the operator to
program a patten tour
Highlight the item to modify and key:
Use the joystick to change the setting and key:
NEAR to save or: FAR to cancel.
and
NEAR
